Page 1 Smart Monitoring Kingspan Access – Fuel Terminal Technical Documentation and Service Manual kingspanenergymanagement.com...
Page 2: Table Of Contents
Kingspan Access - Service Manual Table of contents Warnings and safety instruction 1. Introduction 2. Technical specification 3. General information 3.1. Power supply 3.2. Refueling 3.3. Logging in cards 3.4. Logging off cards 3.5. Writing notes 3.6. Fuel delivery 3.7. Information about status of the terminal 3.8.
Page 3 Kingspan Access - Service Manual Table of contents 6. Minimum and maximum fuel level in the tank, leak sensor 6.1. Minimum fuel level 6.2. Maximum fuel level 6.3. Leak sensor 7. Detailed information for administrator and service 7.1. Service mode...
Page 4: Warnings And Safety Instruction
Kingspan Access - Service Manual Warnings and safety instructions To avoid problems during operation of the terminal it is recommended to read the manual before using the system. Do not change construction of the device nor carry out unauthorized repairs, in particular with...
Page 5: Introduction
· enter current odometer readings before refueling (option set in terminal setup), All data collected by Kingspan Access terminal is available online via internet. Access is protected by a password, so the data is only available for authorized persons. Thanks to GPS technology it is possible to see position of tanks on a digital map. This is particularly important for companies frequently changing position of tanks and for fuel suppliers.
Page 6: Technical Specification
Kingspan Access - Service Manual 2. Technical specification Terminal casing · length: 190 mm · width: 190 mm · height: 55 mm · material: polycarbonate (PC) · colour: light gray with transparent cover · degree of protection: IP 65 Working parameters ·...
Page 7: General Information
Kingspan Access - Service Manual 3. General information 3.1. Power supply The terminal should be permanently connected The lack of data transfer results in the lack of to power supply. The lack of power supply makes it access to current data and makes it impossible to impossible to send data to and from the terminal.
Page 8: Logging In Cards
Kingspan Access - Service Manual 3.2. Refueling Correct order of operations during refueling. Taking the above into consideration proper refueling should proceed as follows: The tank manufacturer recommends to first of all switch off the pump after refueling and then, 1.
Page 9: Logging Off Cards
Kingspan Access - Service Manual 3.4. Logging off cards To log off USER card press F5 on keyboard. To log off MASTER card press F1 on the After logging off USER card the fuel pump keyboard. power is switched off.
Page 10: Information About Status Of The Terminal
Kingspan Access - Service Manual 3.7. Information about status of the terminal · Information about the last refueling In standby mode before authorizing MASTER card additional information (this information is optional, whether it is may be displayed: available or not depends on the configuration), ·...
Page 11: Minimum And Maximum Fuel Level
Kingspan Access - Service Manual 3.10. Minimum and maximum fuel level If the terminal is connected to fuel probe and the pump from running dry, which could result in minimum level is configured as above zero the damage to the pump!
Page 12: The Screen After Authorizing Master And User Cards
Icons of functions as signed to assigned to F1-F4 buttons F5-F8 buttons Name of the card authorized first Kingspan, 5 Topolowa St., 62-090 Rokietnica Current levelof fuel in the tank (liters) Kingspan Water & Energy Jan Kowalski Driver Name of the card...
Page 13: Optional General Information
Kingspan Access - Service Manual 4.1. Optional general information Probe number Displaying additional information connected with icons described below is optional. On the right side of the icon on a black background the probe number is displayed They can be displayed on the screen or not - it to which fuel level on the left side of the icon depends on hardware and software setup.
Page 14: Fuel Delivery
Kingspan Access - Service Manual 5.2. Fuel delivery In standby mode additional functions are Start refueling. Having finished enter the amount available: of added fuel using the keyboard and press OK. The amount of fuel must be confirmed. F1 -Fuel delivery...
Page 15: Communication With The Server, Information About State Of The Terminal
Kingspan Access - Service Manual 5.3. Communication with the server, information about state of the terminal Caution! The list is downloaded if it has previously been prepared and is available on the server! After pressing F5 the screen looks as below: ·...
Page 16: Logging In Cards
Kingspan Access - Service Manual 5.3. Communication with the server, information about state of the terminal · GPS If the function is available, it displays fuel level Coordinates of the geographical location where in litres on the left side of the icon the terminal is located.
Page 17: Logging In Master Rfid Card
After logging MASTER card, the screen displays data assigned to the card and information to log USER card to start refueling. Kingspan, 5 Topolowa St., 62-090 Rokietnica Below is an example of the terminal screen after logging MASTER card: 5.6. Logging in USER card After logging in USER card a window for entering After entering odometer readings press OK.
Page 18: Writing Notes (F4)
If odometer readings are not correct, press ESC and re-enter the value. If odometer readings are correct, confirm by pressing OK - the pump power Kingspan, 5 Topolowa St., 62-090 Rokietnica is turned on and the screen displays refueling Kingspan Water & Energy window.
Page 19: Minimum And Maximum Fuel Level In The Tank, Leak Sensor
When current fuel level is below the defined minimum MASTER and USER cards can be logged Kingspan, 5 Topolowa St., 62-090 Rokietnica in, but the pump cannot operate! After logging in Kingspan Water & Energy...
Page 20: Maximum Fuel Level
Kingspan Access - Service Manual 6.2. Maximum fuel level If the current fuel level is above the defined maximum, a message and an audible signal are generated. The audible signal can be turned off by pressing the F7 key. The message on the display will remain until the cause of the alarm ceases, i.e.
Page 21: Detailed Information For Administrator And Service
Kingspan, 5 Topolowa St., 62-090 Rokietnica If within 30 seconds after logging ADMIN card Kingspan Water & Energy Kingspan Water & Energy Poznań ul. Topolowa 5 MASTER or USER card is not authorized, ADMIN Jan Kowalski card is logged out.
Page 22: F1 - Closing Service Mode
After pressing F1 all logged in cards are logged out. F3 - Entering settings menu Kingspan Water & Energy, 5 Topolowa St., Rokietnica It allows access to all available service settings. The screen displays information that identifies the terminal and all service data.
Page 23: Menu In Settings Mode
Kingspan Access - Service Manual 7.2. Menu in settings mode Menu structure in settings mode: F5 - Calibration tarin Resetting the current net valu F1 - Return to the previous screen F6 - Calibration of the flow meter F2 - System configuration...
Page 24: F1 - Exit Settings Mode
Kingspan Access - Service Manual 7.2. Menu in settings mode F1 - Return to the previous screen F4 - Change in the size of letters entered F2 - Edit the table F5 - Restore factory settings F3 - Switch between the alphanumeric and numeric F8 - Delete the last „Backspace”...
Page 25: F3 - Displayed Parameters
Kingspan Access - Service Manual 7.2. Menu in settings mode Before refueling [s] – maximum time [in seconds] the user has to start refueling from authorizing USER card. After refueling [s] – maximum idle time [in seconds] from finishing refueling to automatic log out.
Page 26: F4 - Wi-Fi Configuration
Kingspan Access - Service Manual 7.2. Menu in settings mode Factory settings: Parametrer Value Kingspan2 Fuel level in tanks Refueled litres Temperature in tanks TOTAL counter Fuel level in tanks Temperature in tanks Ask for odometer readings Advanced network settings can be configured by...
Page 27: F6 - Flow Meter Calibration
Kingspan Access - Service Manual 7.2. Menu in settings mode F6 - Flow meter calibration Having finished filling the flask with fuel press F2 Defining flow meter coefficient (number and enter how many liters have been poured into of pulses per 1000 litres of fuel).
Page 28: F7 - Fuel Tanks. Fuel Probes And Fuel Tanks Calibration
Kingspan Access - Service Manual 7.2. Menu in settings mode After taking 3 measurements the table might look like this: When you first start the terminal no fuel probes are visible. They must first be addressed. To address the probe connect it to the terminal.
Page 29 Kingspan Access - Service Manual 7.2. Menu in settings mode Maximum level - This is the value above which Setting values of the probe and fuel tank can be edited by pressing F2. the terminal will signal exceeding the defined value with a message and an audible signal.
Page 30 Kingspan Access - Service Manual 7.2. Menu in settings mode After entering the PIN under the F4 key, the You can define your own pressure to liters conversion table. To do this, add a new table by configuration of transmission parameters via the pressing F5 or F6.
Page 31: Operating Multiple Probes
Kingspan Access terminal. functionality to support multiple probes to This additional functionality requires addressing Kingspan Water & Energy Service Team. of all the probes as well as adaptation and 8.1. Minimum fuel level in multiple probes configuration...
Page 32 Kingspan Access - Service Manual 9. Flow meter calibration For example: Calibration with manual determination of the ratio: 34634+34613+34632 1. Log in ADMIN and any other card Calib. ratio = MASTER or USER), 2. Enter settings window (press F3), = 34626 3.
Page 33: Warranty
10. Warranty 1. Kingspan Water & Energy sp. z o. o. with its registered office in Rokietnica, 5 Topolowa St., entered into the Register of Entrepreneurs of the National Court Register kept by the District Court Poznań Nowe Miasto i Wilda in Poznań, IX Commercial Department of the National Court Register under number 0000032871, Tax ID no.
Page 34 Kingspan Access - Service Manual 10. Warranty 7. The Purchaser, in order to exercise the rights arising from the guarantee, should immediately notify about any failure/malfunction of the Guarantor’s device using the XSS system. Other channels can only be used if the XSS system is not available. The implementation of warranty service begins at the moment of submitting the correct service request through the available channels.
Page 35: Electrical Wiring Diagram
Kingspan Access - Service Manual 10. Warranty 15. The warranty excludes defects caused as a result of force majeure, fortuitous events (eg flooding, fire, contamination of the equipment or foreign bodies, mechanical damage). 16. The guarantee expires in the event of any attempts to repair the device by unauthorized entities...
Page 36 Kingspan Access - Service Manual 11. Electrical wiring diagram 1. Standard version of the system: a) Main power supply b) PR36X digital probe c) Fuel pump d) Flow meter Scheme Kingspan Access Terminal...
Page 37 Kingspan Access - Service Manual 11. Electrical wiring diagram 2. Standard version with fuel nozzle sensor: a) Main power supply b) PR36X digital probe c) Fuel pump d) Flow meter e) Fuel nozzle sensor Scheme Kingspan Access Terminal...
Page 38: Installation And Launching - A List Of Actions
Kingspan Access - Service Manual 12. Installation and launching - a list of actions Installation Action Status Attaching the terminal PR36X fuel probe installation Check whether the probe is in the bottom of the tank (lying on the bottom or touching it)
Page 39: Attaching Terminal Casing
Kingspan Access - Service Manual 13. Attaching terminal casing Mounting holes: Terminal is attached with 4 screws and holes in the bottom of the casing. Mounting holes: Handles seen from the bottom of the casing: Alternatively to attach the terminal use 4 extra handles, which prior to installation should be screwed from the bottom of the casing.
