ASI EZ FILL 0393-R Manual

EZ FILL™ Remote Control to adjust dispensing settings on FOAM SOAP Dispenser
Soap Dispensers
MasterFormat Section 10 28 13
Scan for
Information
S /lEED
uStainability
P o
roduct verview
Allows programming of all individual dispenser units from one hand held remote. Adjusts the soap dispenser setting from one
of four presets. Temporarily shuts off auto dispensation function to perform cleaning or filling. Can reset to factory settings. One
Remote Control per order will be provided at no charge, IF you order the 6 Pack SKU – (Foam and Liquid dispensers have different
remotes)
K F & s
ey eatures
• Remote for Foam Soap Dispensers
• Included at no charge with a 6 pack
• Available seperately as well
• Controls flow, and turns off unit during maintainence
• Hand Held
American Specialties, Inc. | 441 Saw Mill River Road, Yonkers, NY 10701 | (914) 476-9000 | www.americanspecialties.com
Model: #0393-R
CSI:10 28 13 Toilet Accessories
EZ Fill
2-3/16"
[56]
peciFications
1/2"
[13]
3/8"
SOAP VOLUME
[10]
ADJUSTMENT
2-3/8"
[60]
1"
[25]
3/4" DIA [Ø20]
NOTE:
ALL DIM'S INCH [MM]
ILLUSTRATION FOR REF ONLY AND NTS
SEE SOAP DISPENSER CARE & MAINTENANCE
DOCUMENT ONLINE FOR CLEANING
Revision: R1
Model #0393-R
Technical Data Sheet
1-7/16" [36]
LED
AIR VOLUME
ADJUSTMENT
ON / OFF
TEMPORARY
RESET TO
FACTORY DEFAULT
REMOTE PUMP FILL
ACTIVITION
KEY FOB
Issued: 11/1/2021 Revised: 3/10/2023
Page: 1 of 2
