TB11E/TB11G TuffTruk Walk-Behind Power Buggy
Assembly Instructions
The following instructions are intended to assist the user in the assembly of the TB11E or TB11G TuffTruk Walk-Behind
Power Buggy. They are not intended to take the place of the Operation manual shipped with the unit. Refer to the
Operation manual for safety, operation, and maintenance information. If you did not receive a manual with your power
buggy, contact Multiquip at (800) 421-1244 for a replacement.
REQUIRED TOOLS
„ 17 mm wrench or socket
PARTS
Verify that all parts are accounted for. See Figure 1 and
Table 1.
ASSEMBLY
INSTRUCTIONS
OPERATION MANUAL
Figure 1. TuffTruk Packaging Contents
TB11E/TB11G WALK-BEHIND POWER BUGGY — ASSEMBLY INSTRUCTIONS — REV. #0 (06/18/18) — PAGE 1
Table 1. TuffTruk Packaging Contents
Item Description
1 Packaging Contents, TuffTruk
2 Instructions, Assembly
3 Operation Manual, TuffTruk
4 Assembly, TuffTruk
5 Assembly, Handlebar
6 Pin, Cross Location
7 Tub
8 Tipping Frame, Tub
9 Nut, Nyloc
10 Bolt, Hex Head
11 Washer, Flat
WORK SAFELY!
Only a qualified service technician with proper training
should perform this assembly. Follow all shop safety rules
when performing this assembly.
GENERAL SAFETY
NOTICE
„ Manufacturer does not assume responsibility for any
accident due to equipment modifications. Unauthorized
equipment modification will void all warranties.
„ DO NOT use accessories or attachments that are not
recommended by Multiquip for this equipment. Damage
to the equipment and/or injury to the user may result.
POWER BUGGY SAFETY
WARNING
„ NEVER disconnect any emergency or safety devices.
These devices are intended for operator safety.
Disconnection of these devices can cause severe injury,
bodily harm, or even death. Disconnection of any of
these devices will void all warranties.
Qty. Remarks
Includes
1
items 2–11
1
1
Includes
1
items 5–8
1
1
1
1
1
1
1
