New H3C Technologies LSWM116H User Manual

Overview 简介
The
LSWM116H interface module provides 16 QSFP28 ports.
LSWM116H接口模块扩展卡对外提供16个QSFP28口
QSFP28 port LED
QSFP28状态指示灯
Ejector lever
QSFP28 port
QSFP28口
Ports 接口
The QSFP28 ports support QSFP28 transceiver modules, QSFP28 cables, QSFP+
transceiver modules, and QSFP+ cables. QSFP28口可选配QSFP28模块、QSFP28线
缆、QSFP+模块和QSFP+线缆。
As a best practice, use H3C transceiver modules and cables for the QSFP28 ports. 推荐
您使用H3C公司的光模块和线缆。
H3C transceiver modules and cables available for the module are subject to change
over time. For the most recent list of H3C transceiver modules and cables available for
the module, contact H3C Support or marketing staff. 接口模块扩展卡支持的光模块和线
缆的种类随着时间变化有更新的可能性，若您需要准确的选购信息，请咨询H3C公司市
场人员或技术支持人员。
For specifications of H3C transceiver modules and cables, see H3C Transceiver
Modules User Guide at www.h3c.com. 光模块和线缆的具体规格，请您参见H3C网站发
布的《H3C光模块手册》。
钩形按钮
扳手
。
Latch
