Summary of Contents for Filamos DC 50
- Page 1 Dosing pump DC 50 / DC 200 User manual Dosing pump DC 50 / DC 200 VÝROBCE: FILAMOS, s.r.o. Hatě 546, 261 01 Příbram, Česká republika Tel.: + 420 318 637 763, Fax: + 420 318 624 181 www.filamos.cz...
-
Page 2: Table Of Contents
Dávkovací čerpadlo DC 50 / DC 200 Obsah Strana USE ....................2 III. SAFETY ..................3 TECHNICAL DATA ............... 3 OPERATION AND MAINTENANCE INSTRUCTIONS ....4 APPENDICES ................5... -
Page 3: Use
Dávkovací čerpadlo DC 50 / DC 200 I. USE Dosing pump, series DC, is used for dosing liquid additives to a concrete flow at realisation of dry-sprayed or wet-sprayed concrete technology. The additive is used for increasing speed of the concrete hardening process, increasing the resistance at low temperatures, etc. -
Page 4: Safety
3 NPE ~ 50 Hz Weight (kg) Length 80 cm Width 70 cm Height 65 cm The DC 50 type is fitted for the shotcreting machine SSB 14 or SSB 05, DC 200 type for the machines SSB 24 and SSB 02. -
Page 5: Operation And Maintenance Instructions
Dávkovací čerpadlo DC 50 / DC 200 The whole equipment is situated in a protective frame and covered with metal sheets and one rubber wall. The connecting and controlling elements are accessible from the equipment face side, a display showing the supplied quantity is covered up with a lifting rubber cap. -
Page 6: Appendices
Dávkovací čerpadlo DC 50 / DC 200 Operation: A) Dry-spraying upon agreement with the nozzle operator, the pressured water is released into the distribution after the hose is filled, the pump is switched on to suck in the liquid additive to be... - Page 7 Dávkovací čerpadlo DC 50 / DC 200 ANNEX 1. DESCRIPTION OF THE DOSING PUMP (chapter 2)
- Page 8 Dávkovací čerpadlo DC 50 / DC 200 ANNEX 2. DESCRIPTION OF THE DOSING PUMP (chapter 2)
- Page 9 Dávkovací čerpadlo DC 50 / DC 200 ANNEX 3. List of Spare Parts Ball cock ¾“ 1, 11, 12 Quick coupler ¾“ 2, 10 Reduction valve D06F ¾ B Reverse valve PN 16 – ¾“ Safety valve PV KB ½“ x ¾“ KB 15 Hose pump Manometer G1/4“, 0 –...
