MALUX funkwerk focX Instruction Manual

focX - Handheld GSM-R
®
Document No:
Version:
Date created:
User Interface
Emergency Button
|| Bouton
Initiating a GSM-R emergency call.
Rotary Knob
- serial jumping through the menus
- menu selection function by pressing
- high-low volume function
LAS Transmitter
Press to activate transmission of the link
assurance signal.
High / Low Volume Rocker Switch
For adjusting the loudness separately for the
handset (earphone) and hands-free function.
PTT (Push-to-Talk Button)
Press and hold to send. Release to receive.
PTT is only available if you use semi-duplex
in GSM-R or FM mode. (dualfocX®).
Accept-/ Send Button
Iinitiating or accepting a call.
Open the „fixed" submenu.
Softkey Function
Default settings:
Phonebook
Group Call
1405.110.20001.BA.EN.8
1.0.1
2015-06-09
Menu
Registration
Broadcast Call
Inbox
Antenna 450 - 470 MHz
(dualfocX )
®
2-line Status Display
power indicator | battery status | selected
menu | Time
Footer
Softkey function | selection button left and
right-hand
Exit Button
To end or rejecting a call. To switch on and
off (keep button pressed for 3-4 seconds).
In the menu :
- return to the initial state
- delete button for the last entered number
»
To change the assignment of the
softkeys open the menu Settings >
General > Chg. SK Funct..
