Ultrathin Touch W heel RF Remote Controller
Model No.: AFR-6 / AFR-6-1
Touch w heel/ W ireless remote 3 0 m distance/ CR2 0 3 2 battery
Features
●A pply to single color LED controller, dimming driver or smart lamp.
●
Ultra sensitive color adjustment touch w heel.
●Each remote can match one or more receiver.
● R
C 2 0 3 2 attery pow ered.
b
●Operate w ith LED indicator light.
Technical Parameters
Input and Output
Output signal
W orking voltage
W orking current
S tandby current
S tandby time
Remote distance
W arranty
W arranty
User Manual Ver 1.0.3
AFR-6
RF 2 .4 GHz
(
)
3 VDC CR2 0 3 2
(
＜5 mA
＜1 0 μA
1 y ear
3 0 m
5 y ears
AFR-6-1
S afety and EM C
EMC standard (EMC)
)
Safety standard(LVD)
Radio Equipment(RED)
Certification
Environment
Operation temperature
Case temperature
IP rating
www.alfaled.sk
EN301 489,EN 62479
EN60950
EN300 328
CE,EMC,LVD,RED
Ta: -30
O
C ~ +55
Max.
(
)
Tc: +85
O
C
IP20
LVD
O
C
Page 1
Advertisement
Summary of Contents for Alfaled AFR-6
- Page 1 Ultrathin Touch W heel RF Remote Controller Model No.: AFR-6 / AFR-6-1 Touch w heel/ W ireless remote 3 0 m distance/ CR2 0 3 2 battery AFR-6 AFR-6-1 Features ●A pply to single color LED controller, dimming driver or smart lamp.
- Page 2 AFR-6, AFR-6-1 Ultrathin Touch Wheel RF Remote Controller Dimension 58.5mm 58.5mm 107mm Operation ●Pull out the plastic battery barrier sheet from the battery compartment located on the bottom of the remote. ●To ex tend battery life, no touch or press key operation after a few seconds, the touch w heel w ill enter sleep state, y ou need press any key to make touch w heel quit sleep state.
- Page 3 3 S cene: S hort press recall the scene,long press 2 s save the current state into the scene. 4 z one recall or save sy nchronously. N ote: The remote AFR-6 can be used as 4 zone dimming remote or single zone 4 channel dimming remote. Operation: Long press "...
- Page 4 AFR-6, AFR-6-1 Ultrathin Touch Wheel RF Remote Controller AFR-6-1 1 zone dimming remote 3 Scene Bright w heel On/ Off Bright- Bright+ 4 Bright On/ Off: Turn on/ off light. Bright w heel: Touch to change brightness. Bright+ / -:Adjust brightness, short press 10 levels, long press 1-5s for continuous 256 levels adjustment.
