U.S. General 70381 Owner's Manual & Safety Instructions

72" triple bank roller cabinet
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
72"
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2022 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
TRIPLE BANK
ROLLER CABINET
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
70381 58710 70382 70314 70315 70316 70318 70319
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
23e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 70381 and is the answer not in the manual?

Questions and answers

Summary of Contents for U.S. General 70381

  • Page 1 Keep this manual and the receipt in a safe and dry place for future reference. 72" TRIPLE BANK ROLLER CABINET 70381 58710 70382 70314 70315 70316 70318 70319 Visit our website at: http://www.harborfreight.com Email our technical support at: productsupport@harborfreight.com When unpacking, make sure that the product is intact and undamaged.

  • Page 2: Specifications

    Specifications Input: 15A, 100-125V, 60Hz, 1875W Max AC Output: 15A, 100-125V, 60Hz, 1875W Max USB Output: 5VDC 3A/9VDC Electrical Rating 2.22A/12VDC 1.67A Type-C Output: 5VDC 3A/9VDC 2.22A/12VDC 1.67A Total USB Output: 20 W (max) Total Combined Weight Capacity 6600 lb (Evenly distributed from bottom up.) Drawer Capacity (per connected pair of slides) 120 lb...
  • Page 3 17. To reduce the risk of electric shock or fire, 25. Keep hair, loose clothing, fingers, and all never overload receptacles. Refer to markings parts of body away from moving parts. for the proper load on receptacles. 26. Use only as described in this manual. Use only 18.
  • Page 4 Assembly Instructions Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document including all text under subheadings therein before set up or use of this product. 1. Assemble on a flat, level, hard and smooth surface 2. Attach Side Handles (2) using Handle Screws (3). capable of safely supporting a fully loaded unit.

  • Page 5: Connecting Cabinets

    Connecting Cabinets Cabinet A Cabinet B 1. Unplug Cabinets from outlet. 2. Empty all Drawers from Cabinets. 3. Remove all attachments from Cabinets install Bolts 4. Assemble on solid flat surface. here 5. Remove Top Drawers from Cabinets. 6. Remove two Handle Screws (3) from Handle (2) from Cabinet A.
  • Page 6 11. Place two M8x40 Bolts (28) through holes underneath 12. With Cabinets connected, remove eight Bolts (29) Cabinets from one Cabinet to the other Cabinet. from two Fixed Casters (21) on Cabinet B. Secure Bolts with M8x40 Nuts (27) and tighten. 13.
  • Page 7 Operation Instructions Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document including all text under subheadings therein before set up or use of this product. 1. Empty all Drawers. 7. Plug devices into the Power Strip inside Drawer on the right-hand side.

  • Page 8: Maintenance And Servicing

    Maintenance and Servicing Procedures not specifically explained in this manual must be performed only by a qualified technician. TO PREVENT SERIOUS INJURY FROM TOOL FAILURE: Do not use damaged equipment. If any part becomes damaged, have the problem corrected before further use. TO PREVENT SERIOUS INJURY FROM ELECTRIC SHOCK: Disconnect the Power Cord from the Cabinet before maintenance and servicing.

  • Page 9: Please Read The Following Carefully

    Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Parts may not be interchangeable. Specify UPC when ordering parts: Black: 70381; UPC 193175496454 Red: 58710; UPC 193175444998 Blue: 70382;...

  • Page 10: Parts List

    Parts List and Diagram Parts List Part Description Part Description Rubber Mat 6″x2″ Swivel Caster with Brake Side Handle Power Strip Mounting Plate Handle Screw (M6X55) Power Strip Drawer Trim M6x25 Nut Drawer Latch M6x25 Bolt Trim Screw (ST4.8X7.2) M8x40 Nut Drawer Trim M8x40 Bolt Drawer Latch...

  • Page 11: Assembly Diagram

    Assembly Diagram Roller Cabinet For technical questions, please call 1-888-866-5797. Page 11...

  • Page 12: Limited 90-Day Warranty

    Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
