The Pathway Connectivity Pathport® model 6182 Touring Edition is a one-port DMX-
over-Ethernet node, intended for use in entertainment and architectural lighting systems
employing DMX512 as the control protocol. The TE can either output or input 512
channels of DMX.
The Touring Edition (TE) node may be configured using Pathport Manager software (freely
downloadable from the Pathway Connectivity website) or by using the three-button/LCD
screen interface on its front. Certain signal testing and RDM tools are only available from
the three-button/LCD interface.
This manual describes the three-button/LCD interface. Please refer to the Pathport
Manager manual for instructions on configuring the Touring Edition via software.
Pathport Model 6182 Touring Edition
User Manual
Version 1
May 2009
Updated September 2010
Pathway Connectivity Solutions
#103 – 1439 17 Ave SE Calgary AB T2G 1J9
P: +1 403-243-8110 F: +1 403-287-1281
www.pathwayconnect.com
1
Page
2
2
3
3
4
5
5
6
6
6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for pathway 6182
Summary of Contents for pathway 6182
- Page 1 Updated September 2010 Product Description The Pathway Connectivity Pathport® model 6182 Touring Edition is a one-port DMX- over-Ethernet node, intended for use in entertainment and architectural lighting systems employing DMX512 as the control protocol. The TE can either output or input 512 channels of DMX.
- Page 2 90 degree increments. The TE has an IP54 enclosure rating when mounted so that the cable connections point straight down. Pathway Connectivity Solutions #103 – 1439 17 Ave SE Calgary AB T2G 1J9 P: +1 403-243-8110 F: +1 403-287-1281...
- Page 3 Configuration changes must be explicitly saved (by pressing a SAVE button) to take effect. The ESC button or a battery time out will cause changes to be lost. Pathway Connectivity Solutions #103 – 1439 17 Ave SE Calgary AB T2G 1J9 P: +1 403-243-8110 F: +1 403-287-1281 www.pathwayconnect.com...
- Page 4 Press EDIT, then use the UP/DOWN buttons to scroll through the choices. Pressing NEXT allows the displayed choice to be saved. Pathway Connectivity Solutions #103 – 1439 17 Ave SE Calgary AB T2G 1J9 P: +1 403-243-8110 F: +1 403-287-1281 www.pathwayconnect.com...
- Page 5 Press UP/DOWN to change the DMX start channel. Level information is shown as a percentage. Pathway Connectivity Solutions #103 – 1439 17 Ave SE Calgary AB T2G 1J9 P: +1 403-243-8110 F: +1 403-287-1281...
- Page 6 DMX values are shown between 0 and 255. Press ESC to return to the top menu. Changing the Battery Using a small Phillips screwdriver, remove the two screws next to the Pathway label on the rear of the TE. Gently remove the battery cover plate. Carefully remove the old battery from the connector and replace with a new 9V battery.
