Trolla TINE DE-THATCHER Assembly

ASSEMBLY
1. Attach the Spring Tine (#17) to the Frame (#8) by using the Round Head Bolt M8x20 (#16), Hex Nut
M8 (#6) and Lock Washer Ø8 (#7), then tighten.
2. Attach the Lift Handle (#1) to the Frame (#8) by using the Hex Bolt M5x30 (#5) and Hex Nut M5 (#15),
then tighten.
3. Attach the Adjusting Rod (#4) to the Frame (#8) by using the Hex Bolt M8x25 (#3), Hex Nut M8 (#6)
and Lock Washer Ø8 (#7), then tighten.
4. Attach the Adjusting Frame (#14) to the Frame (#8) by using Pin (#9) and Hair Cotter Pin Ø3 (#10).
5. Insert the Plastic Cap (#18) to the Adjusting Frame (#14).
6. Attach the Connector (#11) to the Bracket (#12) by using the Hex Bolt M8x45 (#13), Hex Nut M8 (#6)
and Lock Washer Ø8 (#7), then tighten.
7. Attach the Connector (#11) to the Bracket (#12) by using Pin (#9) and Hair Cotter Pin Ø3 (#10).
8. Connect the Adjusting Steel Block (#2) with the Adjusting Rod (#4), adjust them for working depth.
9. The Hex Bolt M8x25 (#3), Hex Nut M8 (#6) and Lock Washer Ø8 (#7) will use for connecting the rake.
PARTS LIST
Part # Description
1 Lift Handle
2 Adjusting Steel Block
3 Hex Bolt M8x25
4 Adjusting Rod
5 Hex Bolt M5x30
6 Hex Nut M8
7 Lock Washer Ø8
8 Frame
9 Pin
TINE DE-THATCHER
QTY
1
1
6
1
1
22
22
1
2
Part # Description
10 Hair Cotter Pin Ø3
11 Connector
12 Bracket
13 Hex Bolt M8x45
14 Adjusting Frame
15 Hex Nut M5
16 Round Head Bolt M8x20
17 Spring Tine
18 Plastic Cap
QTY
2
1
1
2
1
1
15
15
1
