Assembly instructions for wooden shelving system HW45
Basic shelf HW 45
The diagonal cross is already pre-assembled.
•
Wooden support frames are marked with a cross on the underside (cross is below)
•
The diagonal cross is attached to the two wooden support frames with the supplied screws on the
•
back.
TIP: This works best when one person holds a wooden support frame and another person holds the
diagonal cross on the two support frames ¬men confirmed.
The split pins are placed at the desired height.
•
Inserting the shelves
•
Tip: put in at the back and then put in front.
Add-on shelf HW 45
A person holds the support frame next to the basic shelf
•
The split pins are placed at the desired height.
•
Inserting the shelves
•
Tip: put in at the back and put in front.
•
A diagonal cross is required on every 3rd field!
If the shelf height exceeds 5 times the shelf depth, wall mounting is necessary
•
FoodBin
Tel.: +49 (0) 9443 / 90045
Franz Brummer
Am Hang 2
E-Mail f_brummer@foodbin.de
D-93326 Abensberg
Internet: www.foodbin.de
Geschäftsführung:
Dipl. Ing. (FH)
Franz Brummer
Informationsorganisator IHK
Bank:
Fidor Bank AG / München
BIC
FDDODEMMXXX
IBAN
DE11 7002 2200 0020 3551 07
UstIdNr.:
DE192114144
