- Page 1 DAM-3015D User’s Manual Beijing ART Technology Development Co., Ltd.
-
Page 2: Wiring And Installation
Power Supply: unregulated +10～+30V Power Consumption: 0.7W@24V Industrial Design DAM-3015D was designed to use in industrial environment. It can be installed in standard DIN rail inside the cabinet. And it can be powered by unregulated 10V ~30V to meet the various power supplied ℃... - Page 3 DAM-3015D User’s Manual V6.13 According to the label directs color to wiring: +Vs （R） Red DATA+ （Y） Yellow DATA- （G） Green GND（B） Black It can connect with DAM-3212, show as the following:...
- Page 4 DAM-3015D User’s Manual V6.13 DAM-3015D Fig. 1 DAM-3015D Drawing DAM-3015D can be installed in standard DIN rail inside the cabinet, it also can be installed by stacking mode. Fig.2 standard DIN installation...
- Page 5 DAM-3015D User’s Manual V6.13 Fig.3 stack installation Wiring Application Reset Connection: Shorted the INIT * and GND shorted, add +10 ~ +30 VDC between +Vs and GND, power on, the module indicator quickly flashes three times, power off until the indicator stops flashing, disconnect the INIT * and GND, then reset the module has been completed.
-
Page 6: Operation Interface
DAM-3015D User’s Manual V6.13 Operation Interface Open the DAM-3000 Software, clicking the “COM1” in the system tree of left dialog block... - Page 7 DAM-3015D User’s Manual V6.13 Clicking the “Addr: 001 (DAM-3015D)” in the system tree of left dialog block to go to DAM-3015D configuration page. In this page, user can configure the output channel. Ddblclicking the “Addr: 001 (DAM-3015D)” in the system tree of left dialog block to get “Module Information” box, in...
-
Page 8: Default Setting
DAM-3015D User’s Manual V6.13 Default Setting If the module’s address or baud rate is wrong, or forget the last modified value, the module can be reverted to default settings. Steps: Short-circuit the “INIT*” and “GND” when there is no power; power-on for 3 seconds, power off, disconnect “INIT*”... -
Page 9: Pin Definition
DAM-3015D User’s Manual V6.13 Pin Definition Name Function OUT13 Digital output 13-ch OUT14 Digital output 14-ch OUT15 Digital output 15-ch INIT* reset pin, connect with(B)GND, then power-on to reset (Y)DATA+ RS-485 positive (G)DATA- RS-485 negative (R)+Vs DC Power Supply (+),+10~+30V...
