DVB Modulator Quick Start Guide
1. Unpacking
Check that all these accessories are present:
1 power supply cable
2 straight ethernet cable
1 quick start notice
2. Connecting to the embedded Web site
3. Add new Rx IP streams
•
On the embedded web site home page, click "Device Status > Add item -> Add IP
Stream " to install new RX streams.
•
Enter the new IP stream URL
•
Click the "Add" button, and the new carrier or stream will be monitored
•
Selecting a stream from this page will send you to the "Details" tab for that specific stream
www.kvarta.net
DVB Modulator
Quick Start
1. Connect the Ethernet cable between the RJ45 and the network.
2. The default STREAMING port is ETHERNET 0 with IP address
192.168.3.3.
3. The default MANAGEMENT port is ETHERNET 1 with IP address
192.168.2.3.
NOTE: Your computer should be in the same network.
4. Open a Web browser (Internet Explorer, Mozilla...) and enter the
device IP address. Login with the default username and password -
(admin/admin). The home page of the embedded web site is displayed.
Advertisement
Table of Contents
Summary of Contents for Kvarta DVB Modulator
- Page 1 DVB Modulator Quick Start Guide DVB Modulator Quick Start 1. Unpacking Check that all these accessories are present: 1 power supply cable 2 straight ethernet cable 1 quick start notice 2. Connecting to the embedded Web site 1. Connect the Ethernet cable between the RJ45 and the network.
- Page 2 DVB Modulator Quick Start Guide 4. Configure Modulator MUX (MPTS) • Click “Device Status” and then select the Modulator mux you would like to configure • Click on Mux -> Config -> TS Config • Enable the mux (TS Multiplex: ON) •...
