Epoch Helios 980 Operating Instructions

Epoch 980 Helios Operating Instructions
An instructional video is also available from our website
The following safety precautions should be taken:
1. Do not use the Helios on the face or near the eyes
2. Do not use in a wet environment or on wet skin
3. Do not exceed 30 mins of treatment time. Use once or twice a day
4. Do not allow children to use unsupervised by an adult
5. Only use on clean exposed skin, no lotions, and not through clothing
6. Do not store in a hot vehicle
A Power Cord
Figure 1
1. Plug the power cord into a standard US electrical outlet.
2. Locate the power receptacle on the side of the unit as shown below in Figure 2
and plug the connector into the receptacle.
3. Once plugged in the blue light on the opposite side of the Helios will briefly light
up. The four red lights adjacent to the blue light will also light up in quick
succession and then all will go off. (Figure 3)
4. To turn the Helios on press the black button. After doing so the first red light will
illuminate. You can adjust the power setting by pressing the black button again
and illuminating the second red light. Pressing the black button 4 times with
illuminate all four red lights. This indicates the Helios is set in the full power
mode.
®
epochlasers.com
B Epoch® 980 Helios
A
C

Connecting the Infrahelios

C Velcro Straps D
B
D
Cleaning cloth
