Summary of Contents for WinSystems PX1-I440-ADC
- Page 1 PX1-I440-ADC Industrial Analog to Digital Data Acquisition Module Product Manual WINSYSTEMS, Inc. | 2890 112th Street, Grand Prairie, Texas 75050 | 817-274-7553 | info@winsystems.com | www.winsystems.com...
- Page 2 Copyright 2020, WINSYSTEMS, Inc. No part of this document may be copied or reproduced in any form or by any means without the prior written consent of WINSYSTEMS, Inc. The information in the document is subject to change without notice. The information furnished by WINSYSTEMS, Inc.
-
Page 3: Table Of Contents
PX1-I440-ADC Table of Contents Before You Begin........... 4 1.1 Warnings . -
Page 4: Before You Begin
(including cable drawings and pinouts) that can be used with your PX1-I440-ADC. Functionality The PX1-I440-ADC is an industrial data acquisition module for embedded systems with PCIe/104 OneBank™ expansion. This module features eight differential analog-to-digital converter (ADC) inputs based on Analog Devices’... -
Page 5: Features
PX1-I440-ADC/Features Customized populations are available for OEM clients that need a mix of 4-20 mA and voltage inputs. Features The PX1-I440-ADC provides the following features. Analog Inputs (ADC) • 16-bit, Linear Technology LTC2335-16 analog-to-digital converter PX1-I440-ADC – 8x single-ended inputs or differential inputs with following ranges: 0 V to 5 V 0 V to 5.12 V... -
Page 6: Specifications
PX1-I440-ADC/Specifications Specifications The PX1-I440-ADC adheres to the following specifications and requirements. Table 1: PX1-I440-ADC specifications Feature Specification Electrical +5 V via OneBank connector Models PX1-I440-ADC, PX1-I440-ADC-420 Mechanical Dimensions 3.55 x 3.775 in. (90 x 96 mm) Weight 0.1 oz (100 g) PCB thickness 0.078 in. -
Page 7: Configuration
PX1-I440-ADC/Configuration Configuration This section describes the PX1-I440-ADC components and configuration. Component Layout ADC input PCIe/104 One Bank Item Description Reference ADC Input page 8 PCIe/104 One Bank Top Connector page 9 J101 PCIe/104 One Bank Bottom Connector page 10 JP1, JP2... -
Page 8: Connectors
PX1-I440-ADC/Configuration Connectors 6.2.1 J2 - ADC Input Header The ADC Input header provides eight channels of analog to digital inputs as well as a a sample clock rate. This clock is free running, but does reset at the start of a conversion command. -
Page 9: J6 - Onebank Top Connector
PX1-I440-ADC/Configuration 6.2.3 J6 - OneBank Top Connector Purpose: OneBank expansion interface top connection to additional expansion modules. Layout and Pin Reference Diagram Name Name USB_0C# PR_RST# 3.3 V 3.3 V USB_1p USB_0p USB_1n USB_0n PEx1_1Tp PEx1_0Tp PEx1_1Tn PEx1_0Tn PEx1_2Tp PEx1_3Tp... -
Page 10: J101 - Onebank Bottom Connector
PX1-I440-ADC/Software Drivers 6.2.4 J101 - OneBank Bottom Connector Purpose: OneBank expansion interface bottom connection to host computer. Layout and Pin Reference Diagram Name Name USB_0C# PR_RST# 3.3 V 3.3 V USB_1p USB_0p USB_1n USB_0n PEx1_1Tp PEx1_0Tp PEx1_1Tn PEx1_0Tn PEx1_2Tp PEx1_3Tp... -
Page 11: Best Practices
ADC. Measuring it at the power supply does not account for voltage drop through the wire and connectors. The PX1-I440-ADC requires 5 V to operate. Verify the power connections. Incorrect voltages can cause catastrophic damage. The PX1-I440-ADC accepts 5 V via the PCIe OneBank connector. - Page 12 Power Supply OFF—Always turn off the power supply before connecting to the I/O Module. Do not hot-plug the PX1-I440-ADC on a host platform that is already powered. I/O Connections OFF—Turn off all I/O connections before connecting them to the PX1-I440-ADC or any other I/O cards.
- Page 13 Conformal Coating Applying conformal coating to a WINSYSTEMS product does not in itself void the product warranty, if it is properly removed prior to return. Coating can change thermal characteristics and impedes our ability to v1.0...
- Page 14 PX1-I440-ADC/Best Practices test, diagnose, and repair products. Any coated product sent to WINSYSTEMS for repair will be returned at customer expense and no service will be performed. Operations/Product Manuals Every WINSYSTEMS product has an Operations manual or Product manual. Periodic updates—Operations/product manuals are updated often.
-
Page 15: Mechanical Drawings
PX1-I440-ADC/Mechanical Drawings Appendix B. Mechanical Drawings The mechanical drawings for the PX1-I440-ADC are shown below. v1.0 www.winsystems.com Page 15... -
Page 16: Warranty Information
Customer for the purchase of Products or licensing of Software hereunder. In the event this Order is placed in the hands of an attorney or collection agency by WINSYSTEMS to collect any sums due hereunder to WINSYSTEMS, Customer shall pay all reasonable attorney's fees, expenses, collection and court costs incurred by WINSYSTEMS.
