CS412
Thank you for choosing this furniture.
PLEASE RETAIN PACKAGING UNTIL YOU HAVE COMPLETED ASSEMBLY.

Information about your furniture.

Our furniture ranges have been carefully crafted from solid wood and natural wood veneers. Each piece of furniture has unique
characteristics such as knots, variances and granning. These are part of the natural character of the furniture itself.

Caring for your furniture.

Extreme temperature can cause slight movements in the wood itself so please avoid placing your furniture close to radiators or other direct
sources of heat. Humidity should also be avoided. Please avoid exposing your furniture to continued bright sunlight as it can affect the colour.
Any fluid should be removed as quickly as possible. Always lift your furniture when moving, as dragging can cause damage to your furniture or
flooring. Extreme changes in temperature & humidity during transit may result in a powder residue forming so silica gel bags have been included
to alleviate this natural occurrence. This residue is harmless and can easily be removed before assembly with a damp cloth and mild detergent.

After care.

Wipe the surfaces with a dry cloth and an occasional use of normal household polish. We also recommend you use household spray
polish occasionally on the drawer grooves and runners as this will aid use. Please do not use detergents or chemicals on your furniture.

Before you start assembly.

Please check that you have all the correct parts and fittings as detailed above. In the unlikely event of a part being damaged or
missing please mark the component or part on the diagrams above and email to
Please provide the following information so that your request can be dealt with ASAP
* Name * Address * Post Code * Telephone number * Batch number (to be found at the bottom left of this page)
BATCH No.
arisesunltd@gmail.com
J = x4
H = x8
Mag. Catch
15mm screw
90 min
A = x37
Dowel
B = x21
40mm Screw
C = x24
30mm Screw
D = x45
Nail
F = x8
Bolt
G = x8
Handle
M = 4x
Hinge Pair Set
N = 24x
Hinge screw

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS412 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BIG FURNITURE WAREHOUSE CS412

  • Page 1 CS412 90 min Thank you for choosing this furniture. PLEASE RETAIN PACKAGING UNTIL YOU HAVE COMPLETED ASSEMBLY. Information about your furniture. Our furniture ranges have been carefully crafted from solid wood and natural wood veneers. Each piece of furniture has unique characteristics such as knots, variances and granning.
  • Page 2 A = x20 Dowel A = x13 Dowel B = x3 40mm Screw B = x5 B = x4 40mm Screw 40mm Screw...
  • Page 3 B = x1 40mm Screw B = x8 40mm Screw C = x8 30mm Screw D = x45 Nail...
  • Page 4 J = x4 Mag. Catch H = x8 15mm screw N = 6x Hinge screw M = 1x Hinge Pair Set...
  • Page 5 N = 3x Hinge screw M = 1x Hinge REPEAT STEPS 13 & 14 TO FIT REMAINING DOORS IF A DOOR NEEDS ADJUSTING ITS POSITION, SIMPLY LOOSEN THE HINGE SCREWS AND REPOSITION DOOR AS REQUIRED F = x4 Bolt G = x4 Handle C = x16 30mm Screw...
  • Page 6 Tip: insert dowels from the inside of the drawers, pushing through once the drawer is in place A = x4 Dowel WARNING! TIPPING HAZARD – Unanchored furniture can tip over WARNING: CHECK FOR HIDDEN PIPES AND CABLES BEFORE DRILLING. IMPORTANT: IF YOUR WALLS ARE NOT SOLID LIKE BRICK OR STONE, YOU WILL REQUIRE SPECIALIST FITTINGS (NOT SUPPLIED) - Place fixing strip against the wall and mark position for drilling hole.
