P5253 JS F 67580 Mertzwiller
EN
1. Precautions to be taken when handling
The following precautions are necessary whenever handling the appliance:
- Handle the appliance with gloves
- Pay special attention to the façade: the painting is very fragile, it will harden completely at the first commissioning.
The painting process will be corrected from June 2014.
Avoid contact between the façade and metal clothing parts (metallic button, belt loop, wristwatch...)
The following label is attached to the device:
QM
N° IT2609
1 / 6
Technical information
Heading No 10
Pellet stove
QUADRALIS
Product evolution
Precautions for handling
Use gloves when
handling. Paint
dry after first
commissioning
T
03/06/2014
IT2609
Advertisement
Table of Contents
Summary of Contents for De Dietrich Thermique QUADRALIS PPA 8
- Page 1 Technical Sales Technical information Documentation Department Heading No 10 Pellet stove QUADRALIS Product evolution Precautions for handling P5253 JS F 67580 Mertzwiller N° IT2609 03/06/2014 1. Precautions to be taken when handling The following precautions are necessary whenever handling the appliance: - Handle the appliance with gloves - Pay special attention to the façade: the painting is very fragile, it will harden completely at the first commissioning.
- Page 2 2. New combustion pot A new combustion pot with a convex bottom, more resistant, has been introduced in production since May 2013. The reference to be ordered in spare parts is unchanged: 300028849. Important: In case of replacement of the combustion pot, also upgrade parameter TRG soll max as described below.
- Page 3 3. New charging screw motor and motor fixing improvement A new charging screw motor and an improved motor fixing are applied in factory since january 2014, providing quieter operation of the device. If operating is noisy, replace the motor by the current version. If the noise persists, use the motor fastening kit described below.
- Page 4 4. New pellet ramp Pellet ramp - Width 42 mm The opening of the pellet ramp changes from 35 mm to 42 mm, to optimize the pellet flow. Application date in production: March 2014 The reference to be ordered in spare parts is unchanged: 300028851. The new pellet ramp width 42 is available at the Spare Part Centre since: April 2014.
- Page 5 APPENDIX 1: SERIAL NO. OF THE APPLIANCE - EVOLUTIONS Appliance reference Serial number: 37 = Week 2012 = Year The serial number is indicated on the nameplate at the back of the appliance. Product evolution - Application date in production Application in factory, since: New pellet charging screw Appliance type...
- Page 6 APPENDIX 2: REPLACEMENT OF THE CHARGING SCREW MOTOR Before any work, switch off the mains supply to the appliance. 1. Remove the left hand side panel Dismantle the lower rear panel Charging screw motor 3. Replace the charging screw motor 4.
