1.
Locate the drain rough-in along the centerline of the installed sink system. Hair interceptors
need to be aligned straight back to not interfere with the moving shroud when fully assembled.
If the rough-in is not on center and you are installing on a cabinet – correct the offset within the
cabinet bulkhead space.
2.
This unit requires both supply lines installed on the left of the drain connection.
3.
Secure the telescoping drain and verify the full range of vertical motion of the sink FIRST,
then connect the trap between the drain and rough-in. You may need to construct a trap from
components to get the elevations to align.
Your system comes in two boxes, what is
included:
Shampoo Bowl box (left in photo): 24"x26"x15", 36
lbs. Contains the 3050 bowl, bowl, fixtures, spray hose,
and vacuum breaker or backflow preventer.
E140 box: 14" x 28" x 39", 95 lbs. Contains the main
unit lift system, panels and shrouds.
Required Hardware/Supplies Not Included: 1 ½" UPC Listed P-Trap, 90 Degree Supply line shut-off valves,
Lag Bolts and/or 5/16" Bolts-Washers-Nuts (if mounting to cabinet), Plumbing Supplies such as Plumbers Putty,
Sealant, Silicone Caulk, etc.
For replacement part orders or further information please contact Customer Service at: (612) 238-4600
Local Building Codes May Apply. Adjust-a-Sink® is a registered trademark of Accessible Systems, Inc.
Adjust-A-Sink® System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 |
E140 SERIES
**INSTALLATION INSTRUCTIONS**
There are three keys to a successful installation:
1 of 25
www.adjustasink.com
Advertisement
Related Manuals for Adjust-a-Sink E140 Series
Summary of Contents for Adjust-a-Sink E140 Series
- Page 1 For replacement part orders or further information please contact Customer Service at: (612) 238-4600 Local Building Codes May Apply. Adjust-a-Sink® is a registered trademark of Accessible Systems, Inc. Adjust-A-Sink® System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com...
- Page 2 STEP 1: SITE EVALUATION, PLUMBING ROUGH IN, & MOUNTING PANEL PREPARATION The Adjust-a-Sink® System is designed to be mounted directly to the face of a finished interior wall, with the proper rough-in plumbing already installed. The System can also be cabinet or station mounted by a qualified installer.
- Page 3 The following Step-by-Step Instructions reference the following Accessible Systems drawings: E140 Overall Assembly, Sheets 1 through 3 E140 Plumbing Rough-in Drawing (sheet 4) Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 3 of 25...
- Page 4 Temporarily plug in the unit in and use the buttons to raise the front panel to its maximum height, an extension cord may be needed. Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 4 of 25...
-
Page 5: Troubleshooting
The unit will drop with the full weight of the assembly and sink installed. You can push down on the lift to get it back to the bottom position. Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 5 of 25... - Page 6 The buttons are pre-adjusted at the factory to properly engage the switches on the lift unit, but can be field adjusted if needed. Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 6 of 25...
- Page 7 Drain Clamp B r a c k e t to the Drain Support Bracket & the hose clamps are loose enough to make adjustments. Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 7 of 25...
- Page 8 Tighten one hose Pull down - clamp enough so the drain will not slide Mark above for the next step. hose clamps Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 8 of 25...
- Page 9 Using tape, a marker or other means, scribe a line on the drain unit along the bottom of the hose clamp. Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 9 of 25...
- Page 10 Use the included rubber gasket between the tailpiece and basket strainer. Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 10 of 25...
- Page 11 Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 11 of 25...
- Page 12 Check all assembled plumbing joints to verify seals. Take appropriate action to address any leaks. The telescopic drains are pressure tested per ASME standards prior to shipment–they should not leak if installed properly. Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 12 of 25...
-
Page 13: Step 4. Shroud Installation
Attach the Shroud by hanging the shroud keyhole slots on the four 10-32 screws with spacers protruding from the front panel. Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 13 of 25... - Page 14 11.5” to 12.0” above the floor. Adjust the drain for full movement of the sink, reconstruct the trap. Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 14 of 25...
- Page 15 They are not tightened as supplied in the fixture kit. INLET OUTLET (UP Arrow) (DOWN Arrow) Connect to Connect to control valve spray head Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 15 of 25...
- Page 16 ITEM QTY FILE NUMBER TITLE 40550 LIFT UNIT - E140 40340 DRAIN SUPPORT BRACKET 40360 SHROUD - LH 40420 FRONT PANEL 40460 DRAIN CLAMP BRACKET 40480 SHROUD - RH 40560 CONTROL ASSEMBLY 40180 DOUBLE HOSE CLAMP FIXTURE SET VACUUM BREAKER SUPPLIED WITH 650 SPRAY HOSE SUPPLIED WITH 650...
- Page 17 12.3 " 26.4 " REFERENCE WALL SECTION 22.0 " 48.1 " 45.8 " 32.5 " 34.3 " TO TOP 32.1 " OF BACK PLATE NEXT ASSY ACCESSIBLE SYSTEMS, INC. DRAFTER DATE MM(INCH) 04-02-17 25.4MM=1 INCH 9917 13TH AVENUE NORTH - MPLS, MN 55441 PHONE: 612 . 238 . 4600 DESIGNER TOLERANCES EXCEPT AS NOTED DATE...
- Page 18 TRIMWORK OR OTHER ELEMENT WILL INTERFERE. 34 " 34 " CABINET WITH RECESSED AREA FOR SINK MOUNTING THE ADJUST-A-SINK MAY BE MOUNTED FLUSH TO A WALL OR FRONT FACE OF CABINETS. 22.5 " MIN 16 " TYP THE UNIT MAY ALSO BE RECESSED FROM CABINET FACE BY A MAXIMUM OF 6 "...
- Page 19 20.0 " LOCATION FOR E140 19.0 " (REF) MOUNTING PLATE TO E140 MOUNTING PLATE BE INSTALLED (REF) .75 " (TYP) FRONT PANEL (REF) MOUNT BOTH SUPPLIES MAINTAIN CLEARANCE ON THE LEFT SIDE 12.0 " OF THE DRAIN 3.0 " 32.5 " 32.0 "...
-
Page 20: Two Year Limited Warranty
Defects or damage caused by the use of other than genuine Adjust-a-Sink parts are not covered by this warranty. This warranty shall be effective from the date of purchase shown on the purchaser’s receipt. - Page 21 E140 SERIES MAINTENANCE MANUAL BASIC FEATURES: The Adjust-a-Sink® System elevates the Shampoo Bowl a total of 14”. Distance from the floor to the top the of bowl ranges from approximately 32” to 46”. An electric actuator provides the lift capacity needed to raise the shampoo bowl. Components are manufactured from the high-grade materials and should provide years of trouble-free service.
- Page 22 ITEM QTY FILE NUMBER TITLE 40300 BACK PLATE 40320 FRONT PLATE ASSEMBLED LINAK 0237085-0750-A VIEW 40380 RUNNER - BEARING MOTOR CABLE 41450 RA BEARING BLOCK 40440 ACTUATOR BRACKET - LOWER 40520 ACTUATOR BRACKET - UPPER 40620 CONTROL CABLE ASSEMBLY LINAK CA30 CONTROL BOX LINAK LA23-350 LINEAR ACTUATOR...
- Page 23 IMPORTANT: The motor on the E140 has a duty cycle rating of 10% on time, or 2 minutes on max – 18 Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 23 of 25...
- Page 24 We suggest that stylists “be creative” in adjusting the sink to fit their clients, as each person is unique in their body type. The Adjust-A-Sink® can be adjusted to improve the shampoo experience for most everyone with a little thought and experimentation with height adjustments and head and body positions. Note that the foot pedal swivels to allow for stylist preference.
-
Page 25: Care And Cleaning Instructions
Small scratches or dullness can sometimes be buffed out using fine cut rubbing compound, this is best done with an orbital polishing tool. Adjust-A-Sink® E140 System by Accessible Systems Inc. | Minneapolis, MN | 612-238-4600 | www.adjustasink.com 25 of 25...
