TEKTINO
1.Equipment description.....................................................................................................................................................1
Part description...........................................................................................................................................................1
Component layout on manifold..................................................................................................................................2
Pipeline diagram.........................................................................................................................................................3
PCA............................................................................................................................................................................ 4
2.Routine maintenance....................................................................................................................................................... 5
Maintenance of vacuum pump................................................................................................................................... 5
Change drier filter, evacuate drier filter and reset service interval time....................................................................7
Leak test......................................................................................................................................................................8
3.Troubleshooting...............................................................................................................................................................9
INDEX
i
RCC-9A maintenance manual V2.0
Advertisement
Table of Contents
Related Manuals for Tektino RCC-9A
Summary of Contents for Tektino RCC-9A
-
Page 1: Table Of Contents
RCC-9A maintenance manual V2.0 TEKTINO INDEX 1.Equipment description..............................1 Part description................................1 Component layout on manifold..........................2 Pipeline diagram.................................3 PCA.................................... 4 2.Routine maintenance............................... 5 Maintenance of vacuum pump........................... 5 Change drier filter, evacuate drier filter and reset service interval time..............7 Leak test..................................8 3.Troubleshooting................................9... -
Page 3: Equipment Description
TEKTINO RCC-9A maintenance manual V2.0 1. Equipment description Part description 3) Gas cylinder load cell 1）Refrigerant gas cylinder 2）Gas cylinder support plate 4）Oil bottle load cell 5）Oil bottle support 6）Oil bottles 7）Assembly of solenoid valve and 8）Manifold assembly 1 9）front cover (plastic) -
Page 4: Component Layout On Manifold
TEKTINO RCC-9A maintenance manual Component layout on manifold MANIFOLD ASSEMBLY 1 MANIFOLD ASSEMBLY2... -
Page 5: Pipeline Diagram
TEKTINO RCC-9A maintenance manual V2.0 Pipeline diagram EV: Solenoid LP: Low pressure switch (or pressure sensor, if machine has vacuum leak test function) HP: High pressure switch CV: non-return valve... -
Page 6: Pca
TEKTINO RCC-9A maintenance manual PCA... -
Page 7: Routine Maintenance
TEKTINO RCC-9A maintenance manual V2.0 2. Routine maintenance Maintenance of vacuum pump 1) Vacuum pump description 1. Exhaust emission port 2. Suction port 3. Pump oil adding port 4. Oil level vision window 5 Oil discharge port 2) Change vacuum pump oil or add vacuum pump oil The pump works over 100 hours, or turbidity or emulsion is found, the oil should be changed. -
Page 8: Change Drier Filter, Evacuate Drier Filter And Reset Service Interval Time
TEKTINO RCC-9A maintenance manual Change drier filter, evacuate drier filter and reset service interval time When a drier filter is replaced, the moisture may enter into equipment pipeline and affects quality of refrigerant in the equipment tank. Thus it is mandatory to evacuate the drier filter each time a drier filter is replaced. -
Page 9: Leak Test
RCC-9A maintenance manual V2.0 TEKTINO LEAK TEST Under the following situations, it is possible that the machine has leakage in pipeline connections, thus need to make leakage test: 1. The refrigerant volume in equipment tank reduces, without operations; 2. Compressor and Solenoids work well, while recovery works too slow or can not work normally;... - Page 10 TEKTINO RCC-9A maintenance manual d) Write down the pressure of each gauge, shut down the equipment. After 4 hours, check pressure of the three gauges. If any gauge shows more than 0.1 BAR pressure down, means the pipeline related to that pressure gauge has leakage (refer to pipeline diagram of this manual).
-
Page 11: Troubleshooting
TEKTINO RCC-9A maintenance manual V2.0 3. Main troubleshooting Ma lf uncti on Reason s So lut ion 1. Insufficient vacuum pump oil. 1. Add oil to central line 2. Pump oil emulsion, dirty 2. Put new oil Low vacuum degree 3. - Page 12 TEKTINO RCC-9A maintenance manual During recovery, vacuum pump The contact between solenoid valve No.4 and valve base is not well pressurized. After period too much oil sealed. in vacuum pump Remove solenoid No.4 from valve base, clean the solenoid valve and valve base.
