INSTALLATION and OPERATION MANUAL
Break Away Fitting For Submersible Pumps
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notification.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Models: Without Check Valve
Standard P/N
127300
BAF-1212
127301
BAF-1220
127302
BAF-2020
127306
BAF-2030
127304
BAF-3030
Models: With Check Valve
Standard P/N
127307
BAF-1212CV 127310
127308
BAF-1220CV 127313
127309
BAF-2020CV 127315
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
"NS" P/N
127303
127311
127312
127305
127314
"NS" P/N
Form No. 780988-Rev. H
Advertisement
Summary of Contents for CRANE PUMPS & SYSTEMS BAF-1212
- Page 1 INSTALLATION and OPERATION MANUAL Break Away Fitting For Submersible Pumps Models: Without Check Valve Standard P/N “NS” P/N 127300 BAF-1212 127303 127301 BAF-1220 127311 127302 BAF-2020 127312 127306 BAF-2030 127305 127304 BAF-3030 127314 Models: With Check Valve Standard P/N “NS” P/N...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY FIRST ....................3 SPECIFICATION ....................4 GENERAL INFORMATION ................5 Installation/Dimensions ..................5 BAF-1212, 1220, 2020 ..................6 BAF-1212CV, BAF-1220CV, BAF-2020CV ............7 BAF-2030 ....................8 BAF-3030 ....................9 Sectional & Parts List BAF 1212, 1220, 2020 ..........10 - 11 Sectional & Parts List BAF-CV 2030, BAF-CV 3030........12 - 13 RETURNED GOODS POLICY .................14... -
Page 3: Safety First
SAFETY FIRST! Please Read This Before Installing Or Operating Pump. This information is provided for SAFETY and to PREVENT CAUTION ! Do not block or restrict discharge hose, as EQUIPMENT PROBLEMS. To help recognize this information, discharge hose may whip under pressure. observe the following symbols: IMPORTANT! Warns about hazards that can result WARNING ! Do not wear loose clothing that may... -
Page 4: Specification
Available: Stainless Steel Lifting Chain, Intermediate Pipe or Stainless Steel should be used for guide rails. Support Bracket. Stainless Steel Intermediate Rail Support Must be Ordered Separately Intermediate Model # Rail Support “A” “B” “C” BAF-1212 750940 5.25” 2.75” 1.25” BAF-1220 750941 5.25” 2.75” 1.25” BAF-2020 750941 5.25”... - Page 5 SECTION: B - GENERAL INFORMATION C-2) Design Layout: B-1) Introduction: See the dimensional drawings on the following pages for Crane Pumps & Systems Break Away Fittings (BAF) are the required anchor bolt locations for the stationary elbow precision engineered and manufactured of the highest to be installed with four anchor bolts set in a metal sleeve quality castings.
- Page 6 Model: BAF-1212, 1220, 2020...
- Page 7 Model: BAF-1212CV, 1220CV, 2020CV...
- Page 8 Model: BAF-2030...
- Page 9 Model: BAF-3030...
- Page 10 Series: BAF & BAF-CV, 1¼ & 2” Discharge...
- Page 11 Parts List: BAF Item #18 Part No. Model No. Inlet Discharge Item #10 Item #18 Material 127300 BAF-1212 1¼” 1¼” 300211 780695DI Ductile Iron 127301 BAF-1220 1¼” 2” 300212 780695DI Ductile Iron 127302 BAF-2020 2” 2” 300212 780695DI Ductile Iron...
- Page 12 Series: BAF, 3” Discharge...
- Page 13 Parts List: BAF Item #18 Part No. Model No. Inlet Discharge Item #18 Material 127304 BAF-3030 3” 3” 780696DI Ductile Iron 127305 BAF-2030NS 2” 3” 780696AB Bronze 127306 BAF-2030 2” 3” 780696DI Ductile Iron 127314 BAF-3030NS 3” 3” 780696AB Bronze Parts List Item Qty.
-
Page 14: Returned Goods Policy
IMPORTANT! WARRANTY REGISTRATION IMPORTANT! WARRANTY REGISTRATION Your product is covered by a warranty: Your product is covered by the enclosed Warranty. www.cranepumps.com/downloadables/CATALOGS_OIPMs/Warranty/24MonthWarranty.pdf If you have a claim under the provisions of the warranty, contact your local If you have a claim under the provision of the warranty, contact your local Crane Pumps &... - Page 15 Notes...
