- Page 1 ELS4 ADAPTER User manual Translation of the original ENGLISH operating instructions This manual describes the commissioning and use of the handwheel adapter for the ELS4 controller...
- Page 2 This manual describes the use of the handwheel adapter: An adapter board that allows the construction of a handwheel for the ELS4 Basic and ELS4 Pro cycle controllers. The board must be installed in a handheld housing to obtain a complete handwheel and be protected against chips, dust and moisture.
- Page 3 The colour coding helps here. You can also separate the wires by simply pull- ing them apart. Using a VGA cable, connect the board to the connector on the back of the ELS4: Extension connector Extension connector notes: •...
- Page 4 PARTing ThE fLAT cAbLE Cut the flat cable to get pairs! For a reasonable operation we recommend to use the encoder input with a manual encoder, furthermore the keys XSTEP, ZSTEP, X0, Z0, START, STOP and possibly the fast traverse keys for both axes.
-
Page 5: Pin Assignment
Pin ASSignmEnT Pair of connections Remarks X RIGHT SLOWLY Moves the X-axis to the right, slowly Navigates the cursor up Special function XOFF Switches the X-axis off Z_RIGHT FAST Moves the Z-axis to the right, fast SUBMODE Switches to submode (PRO only) Z LINKS SLOWLY Moves the Z-axis to the left, slowly Sets the currently selected position to 0... - Page 6 ELS4 PRo buTTonS AvAiLAbLE viA ThE ADAPTER Settings PARAMETER SUBMODE RIGHT LINKS Spindle DOWN ZSTEP ZOFF XOFF XSTEP START PAUSE STOP X and Z axis X and Z-Axis FAST JOG SLOW JOG...
- Page 7 X and Z-Axis FAST JOG SLOW JOG Settings In addition to the buttons on the controller, the following buttons are available for the ELS4 Basic, which are only available via the extension • XSTEP - This allows XSTEP to be activated directly.
- Page 8 SETTingS The adapter can be operated with all ELS4 Pro and Basic from software version 6. If the soft- ware is older, an update must be installed first! The rotary encoder on the adapter allows the axes to be moved stepwise but also permanently, so there is a step mode and a move mode.
- Page 9 STEP-moDE (0-3, 0=Standard) In mode 0, when the ENCODER SWITCH key is released, a large step is made with one pulse, and a small step is made with the ENCODER SWITCH key held down. Turning faster switches to the driving mode. With the switch pressed a fast speed is made, with the switch released slow speed Mode 1 is the other way round in terms of step size: without pressing the switch small steps are output, with switch pressed large steps.
- Page 10 EXAmPLE As an example, a handwheel in a Bopla BS 800 hand-held enclosure is shown here: The printed circuit board is mounted in the lower shell and is easy to screw on using 3 spacer bolts 3 mm high. A pushbutton type Schurter MCS 18 and a handheld encoder with 100 pulse revolutions are used here.
- Page 12 This device must not be disposed of with the household waste! conTAcT: Manufacturer is Rocketronics.de Dipl.-Ing (FH) Louis Schreyer Hugo-Grotius-Str. 18 27404 Zeven GERMANY Tel: 04281 50 79 78 2 Mo-Fr. 14:00-18:00 Email: info@rocketronics.de VAT.-IdNr: DE813546414 WEEE-Reg. Nr. DE 35691149...
