- Page 1 9000 Technical Manual Viscosity and temperature blind transducer (to drive one MIVI sensor) Original version REF.: 381/2...
- Page 2 4 screws; power on the device and wait 15 minutes; The MIVI+9000 is a complete digital system that can only communicate with other devices through its serial RS-485 port. Hence, to make the zero adjustment in the air,...
-
Page 3: Table Of Contents
9000 Technical Manual TABLE OF CONTENT TRANSDUCER PRINCIPLE ......................4 TRANSDUCER TECHNICAL CHARACTERISTICS ..............5 DIN- ....................5 RAIL OUNTED ENCLOSURE 2.1.1 Mechanical characteristics ....................5 2.1.2 Safety considerations...................... 5 2.1.3 System connexion ......................6 IP67 E ........................7 NCLOSURE 2.2.1... -
Page 4: Transducer Principle
The measuring chain is composed of three inseparable elements: the sensor, its cable and the 9000 transducer that controls it. The sensor cannot be used with another transducer or another cable type or length because they are all a part of the resonant loop so they are matched together as one vibrating system. -
Page 5: Transducer Technical Characteristics
9000 Technical Manual 2 Transducer technical characteristics DIN-rail Mounted enclosure 2.1.1 Mechanical characteristics Hereunder are the different views of the electronics. The processor must be connected to a stabilized and filtered 24 VDC (± 2.4 VDC) power supply. The polarity of the power supply is highly important, in order to avoid any damage on the elec- tronic board. -
Page 6: System Connexion
9000 Technical Manual In the event of voltage fluctuations or non-conformity to voltage power supply specifications, connect the device to a filtered and stabilized power supply. Double-check all wiring before turning on the power supply. Install at maximum distance from high-voltage cables and power equipment. -
Page 7: Ip67 Enclosure
9000 Technical Manual IP67 Enclosure 2.2.1 Mechanical characteristics Hereunder are the different views of the electronics. The processor must be connected to a stabilized and filtered 24 VDC (± 2.4 VDC) power supply.. The polarity of the power supply is highly important, in order to avoid any damage on the elec- tronic board. -
Page 8: Safety Considerations
All the wiring between the electronic board and the terminal block are not to be touched. Only the link between the sensor and the terminal block has to be operated by the user accord- ing to the following description. Wiring to be done by the user Wiring done by Sofraser (DO NOT TOUCH) REF.: 381/2... - Page 9 9000 Technical Manual The wires at the end of the cable have the following allocations. transducer ter- wire colour item minal block blue receiving coil brown transparent driving coil black yellow Pt100 green metal Earth In case a cable gland is not used, this one has to be sealed with a cap.
-
Page 10: Accessory Devices
The 9510 and 9710 devices have been designed as accessories to the MIVI+9000 sensor. 3.1 9510 The 9510 is an accessory controller that is to be connected to the 9000 transducer of the MIVI sensor in order to add numerous functions to the whole system.
