Avago HDJD-JD04 Hardware Manual

HDJD-JD04
Development Kit
Operating Hardware Manual

Introduction

Thank you for purchasing the HDJD-JD04 Development
Kit from Avago Technologies. The HDJD-JD04 Kit is a
simple development board, which demonstrates the
capabilities of the 20-pin ADJD-J823 color management
controller device with integrated RGB photosensors
as feedback device of an RGB LED-based backlighting
system.
The development kit can be used stand-alone with an
Autoload feature enabled, or connect direct to an IBM-PC
computer (using USB port).
Sample programs are provided to demonstrate the
unique features of the device.
ESD WARNING: Standard CMOS handling precautions should be observed to avoid static discharge.
AVAGO TECHNOLOGIES' PRODUCTS AND SOFTWARE ARE NOT SPECIFICALLY DESIGNED, MANUFACTURED OR AUTHORIZED FOR SALE AS
PARTS, COMPONENTS OR ASSEMBLIES FOR THE PLANNING, CONSTRUCTION, MAINTENANCE OR DIRECT OPERATION OF A NUCLEAR FACILITY
OR FOR USE IN MEDICAL DEVICES OR APPLICATIONS. CUSTOMER IS SOLELY RESPONSIBLE, AND WAIVES ALL RIGHTS TO MAKE CLAIMS
AGAINST AVAGO TECHNOLOGIES OR ITS SUPPLIERS, FOR ALL LOSS, DAMAGE, EXPENSE OR LIABILITY IN CONNECTION WITH SUCH USE.
WARNING: This product is non RoHS compliant
The HDJD-JD04 Development Kit comes with the fol-
lowing:
• HDJD-JD04 Development Board (Figure 1-1)
• HDJD-JD04 FPC Board (Figure 1- 2)
• CD-ROM, which contains:
• HDJD-JD04 Development Kit Hardware User Guide
• ICMv2 Operating Software Manual
• Application Notes
• Datasheets
If you are missing any part of the kit, please contact your
nearest Avago Technologies sales office listed in the back
of this publication for help.
