Able 2 SHO-ME 12.5064 Quick Start Manual

General Information:
The Luminator LED Trio Light is equipped with an internal flasher. It comes from the factory in a random flash mode.
Wiring Instructions:
When wiring, always connect ground wire first and power wire last.
Flash Pattern Selection:
To change flash patterns, momentarily apply +12v to the Yellow "Sync-Mode" Wire for less than 5 seconds.
To reset to factory default pattern, apply +12v to the Yellow "Sync-Mode" Wire for more than 5 seconds.*
When changing flash patterns, you may have to re-start before patterns will synchronize.
*Do Not ground YELLOW Wire
1.
2.
3.
4.
5.
Synchronization:
Connect all yellow wires together to synchronize. When wired as shown, the Luminator LED Trio Light will be
synchronized.
Group Selection:
The White "Group Selection" Wire will determine which lights flash at the same time when you have 2 or more lights.
For Group 1, connect White "Group Selection" wire with Red Power wire.
For Group 2, DO NOT connect White "Group Selection" wire to anything.
Group 1 & Group 2 will alternate.
*Do Not use White wire if using only one light.*
Product Specifications:
Optimum Operation Voltage:
Operating Current:
Recommended Fuse:
Luminator LED Trio Light Kit
Model 12.5064
Flash Patterns
Single Flash - 134 FPM
Double Flash - 268 FPM
Quad Flash - 536 FPM
Super Flash - 1070 FPM
Single-On - 134 FPM
+13.8 VDC
1.5 - 3 amps
5 amp
Quad-On - 536 FPM
6.
Triple Flash - 401 FPM
7.
Hyper Flash - 1873 FPM
8.
9. Steady
10. Random 1-8 (Default)
09-10-08
