  • Page 2 J ungle 1 - 3 years Jungle 2 Jungle 1 Slide 1 - 5 years Slide 3 Slide 4 Slide 1 Slide 2...
  • Page 3 Furniture 1 & up Furniture 1 Furniture 4 The storage bag is not included. You may use laundry bag or poly bag for it. Furniture 3 Furniture 2...
  • Page 4 CATEGORY Parts List........4 Assembly & Disassembly..5-6 Assembly Illustration Jungle........7-10 Slide........11-18 Furniture......19-26...
  • Page 5 1139 PARTS LIST PARTS NAME Q'TY Corner Connector 3-Way Connector T-Connector 4-Way Connector Cross Connector 5-Way Connector Tube (105mm / Blue ) Tube (143mm / Green ) Tube (300mm / Red ) Tube (300mm / Blue ) Tube (300mm / Green ) Tube (550mm / Red ) Single Locking Tube (95mm / Red ) Single Locking Tube (300mm / Red )
  • Page 6 1139 ASSEMBLY & DISASSEMBLY 1 How to Assemble & Disassemble Tube and Connector Note: ( 1 ) Push the connector into tube and turn the tube until a Do not hold tube and connectors where you insert "click" is heard. each piece as finger may be pinched.

  • Page 7: Assembly And Disassembly

    ASSEMBLY & DISASSEMBLY 2 How to Fasten the Slide ( 1 ) After the model is constructed make sure to fasten all the ends of slide to the tubes with the tube screws and screw driver as Fig. 6-1 shows or double screw driver as Fig. 6-2 shows. Fig.
  • Page 8 1139 ASSEMBLY ILLUSTRATION Jungle 1 COMPLETED 716mm W x 716mm D x 716mm H Square Flat / Red x1 Square Flat / Green x1 Fixture x8 Screw x8...
  • Page 9 ASSEMBLY ILLUSTRATION 300mm 300mm 300mm Tube (300mm / Red) x4 300mm Tube (300mm / Blue) x4 300mm 300mm 300mm 300mm 300mm 300mm 300mm 300mm 300mm 300mm 105mm 300mm 300mm 105mm 300mm 105mm Tube (105mm / Blue) x4 105mm 300mm 300mm Tube (300mm / Red) x4 Tube (300mm / Blue) x3 300mm...
  • Page 10 1139 ASSEMBLY ILLUSTRATION Jungle 2 COMPLETED 1068mm W x 716mm D x 716mm H Square Flat / Red x1 Square Flat / Green x1 Fixture x8 Screw x8...
  • Page 11 ASSEMBLY ILLUSTRATION 300mm 300mm 300mm Tube (300mm / Red) x1 300mm 300mm Tube (300mm / Blue) x3 300mm Tube (300mm / Green) x4 300mm 300mm Tube (105mm / Blue) x1 Tube (143mm / Green) x2 Tube (300mm / Red) x5 Tube (300mm / Blue) x5 Tube (300mm / Green) x2 Single Locking Tube (300mm / Red) X1...
  • Page 12 1139 ASSEMBLY ILLUSTRATION Slide 1 364mm W x 364mm D x 364mm H COMPLETED 966mm W x 364mm D x 716mm H Square Flat / Red x1 Square Flat / Green x1 Fixture x8 Screw x8 Tube Screw x6...
  • Page 13 ASSEMBLY ILLUSTRATION 105mm 105mm Tube (105mm / Blue) x2 300mm 300mm Tube (300mm / Green) x2 Single Locking Tube Single Locking Tube (300mm / Red) x2 Single Locking Tube Tube (105mm / Blue) x4 Tube (143mm / Green) x2 Tube (300mm / Red) x1 Slide x1 Tube (143mm / Green) x4 Tube (300mm / Blue) x3...
  • Page 14 1139 ASSEMBLY ILLUSTRATION Slide 2 COMPLETED 1318mm W x 364mm D x 716mm H Square Flat / Red x1 Square Flat / Green x1 Fixture x8 Screw x8 Tube Screw x6...
  • Page 15 ASSEMBLY ILLUSTRATION 300mm 300mm 105mm 105mm 300mm 300mm Tube (105mm / Blue) x2 300mm 300mm Tube (300mm / Red) x4 Tube (300mm / Green) x2 Single Locking Tube Single Locking Tube Single Locking Tube (300mm / Red) X2 Tube (105mm / Blue) x2 Tube (143mm / Green) x2 Tube (300mm / Red) x3 Tube (300mm / Blue) x3...
  • Page 16 1139 ASSEMBLY ILLUSTRATION Slide 3 COMPLETED 966mm W x 716mm D x 716mm H Square Flat / Red x1 Square Flat / Green x1 Fixture x8 Screw x8 Tube Screw x6...
  • Page 17 ASSEMBLY ILLUSTRATION 105mm 300mm 105mm 300mm Single Locking Tube 300mm 300mm Single Locking Tube 300mm 143mm Tube (105mm / Blue) x2 Tube (143mm / Green) x3 Tube (300mm / Blue) x3 143mm 143mm Tube (300mm / Green) x4 300mm 300mm Single Locking Tube (300mm / Red) X2 Tube (143mm / Green) x2 Tube (300mm / Red) x3...
  • Page 18 1139 ASSEMBLY ILLUSTRATION Slide 4 COMPLETED 966mm W x 716mm D x 716mm H Square Flat / Red x1 Square Flat / Green x1 Fixture x8 Screw x8 Tube Screw x6...
  • Page 19 ASSEMBLY ILLUSTRATION 300mm 300mm 300mm 300mm 300mm Single Locking Tube Tube (300mm / Red) x3 300mm 300mm Single Locking Tube Tube (300mm / Blue) x5 300mm Tube (300mm / Green) x1 300mm Single Locking Tube (300mm / Red) X2 Tube (143mm / Green) x4 Tube (105mm / Blue) x4 Tube (300mm / Red) x4 Tube (300mm / Green) x3...
  • Page 20 1139 ASSEMBLY ILLUSTRATION Furniture 1 COMPLETED 716mm W x 364mm D x 559mm H Square Flat / Red x1 Square Flat / Green x1 Fixture x8 Screw x8...
  • Page 21 ASSEMBLY ILLUSTRATION 300mm 300mm 143mm Tube (143mm / Green) x3 Tube (300mm / Blue) x1 Tube (300mm / Green) x1 143mm 143mm 300mm 300mm 300mm 300mm 105mm 300mm Tube (105mm / Blue) x4 300mm 105mm 105mm 300mm Tube (300mm / Red) x2 Tube (300mm / Blue) x5 105mm Tube (300mm / Green) x1...
  • Page 22 1139 ASSEMBLY ILLUSTRATION Furniture 2 COMPLETED 716mm W x 364mm D x 559mm H Square Flat / Red x1 Square Flat / Green x1 Fixture x8 Screw x8...
  • Page 23 ASSEMBLY ILLUSTRATION 300mm 300mm 300mm 143mm 300mm 143mm Tube (143mm / Green) x5 143mm Tube (300mm / Red) x1 143mm Tube (300mm / Blue) x2 Tube (300mm / Green) x1 143mm 300mm 300mm 300mm 300mm 300mm Tube (300mm / Red) x3 300mm 300mm Tube (300mm / Blue) x4...
  • Page 24 1139 ASSEMBLY ILLUSTRATION Furniture 3 678mm W x 364mm D x 364mm H 364mm W x 364mm D x 559mm H COMPLETED Square Flat / Red x1 Square Flat / Green x1 Fixture x8 Screw x8...
  • Page 25 ASSEMBLY ILLUSTRATION 105mm 300mm 300mm 300mm 105mm 300mm 300mm 105mm Tube (105mm / Blue) x4 Tube (300mm / Red) x4 300mm 300mm Tube (300mm / Blue) x2 300mm Tube (300mm / Green) x4 300mm 105mm 300mm Tube (300mm / Red) x2 Tube (300mm / Blue) x2 Tube (143mm / Green) x4 Tube (300mm / Blue) x2...
  • Page 26 1139 ASSEMBLY ILLUSTRATION Furniture 4 COMPLETED 831mm W x 364mm D x 873mm H 207mm W x 207mm D x 364mm H Square Flat / Red x1 Square Flat / Green x1 Fixture x8 Screw x8...
  • Page 27 ASSEMBLY ILLUSTRATION 300mm 300mm Single Locking Tube (95mm) 105mm Tube (105mm / Blue) x4 300mm 105mm 300mm Tube (300mm / Blue) x4 Single Locking Tube (95mm / Red) X1 105mm 105mm Tube (143mm / Green) x2 Tube (300mm / Blue) x6 Single Locking Tube (95mm) Single Locking Tube (95mm / Red) X1 Tube (105mm / Blue) x3...
