POWER PACKAGE FOR
ACCESS CONTROL PANELS
Quick Guide
SSA-X300
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSA-X300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hanwha Vision SSA-X300

  • Page 1 POWER PACKAGE FOR ACCESS CONTROL PANELS Quick Guide SSA-X300...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean the contaminated area on the product surface with a soft, dry cloth or a damp cloth. (Do not use a detergent or cosmetic products that contain alcohol, solvents or surfactants or oil constituents as they may deform or cause damage to the product.) 7.

  • Page 3: Explanation Of Graphical Symbols

    CAUTION CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. EXPLANATION OF GRAPHICAL SYMBOLS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of “dangerous voltage”...

  • Page 4: Installing The Washer

    What’s Included Quick Guide Warranty card (Optional) Hex screw Hex columns Door lock key L Wrench Battery securing band Washer flat Installing the washer...

  • Page 5: Terminal Block Wiring

    Terminal block wiring Turn the AC power off to ensure safety when wiring terminal block for power supply. Make sure to connect to the correct polarity (+ -) when connecting the battery to the power supply. When producing, do not connect the download terminal of the power supply with test terminals. AC FAIL NON BATT CONTROLLER/INTERFACE...
  • Page 6 Allocate the electric current capacity for each terminal block Item Information CONTROLLER/INTERFACE(2Port), 3,200mA LOCK(2Port) STROBE/HORN(2Port) 800mA CHARGE(1Port) 700mA Wiring of case tamper switch Connect to TAMPER terminal of V100, V200, V300, V1000, and V2000. TAMPER AC 12VDC FAIL FAIL Wiring power cord Secure with the securing band when wiring power cord.

  • Page 7: Product Specifications

    Product Specifications Item Information SMPS AC FAIL(+,-)1Port, NON_BATT(+,-)1Port, CONTROLLER/INTERFACE Terminal Interface (+,-)2Port, LOCK(+,-)2Port, STROBE/HORN(+,-)2Port, CHARGE(+,-)1Port Operation Temperature 0°C ~ +45°C (+32°F ~ +113°F) Input Power Rated 100~240VAC(50Hz/60Hz) / 2.0A Power Consumption Rated 13.5V±5%, 4.7A (However, DC 12.5V ±5% is used for strobe and horn terminal) Compatible battery 12V, 18Ah, Rechargeable In the event of a power outage, make a battery backup by converting the power supply...
