MANUAL FOR CONSTRUCTION AND OPERATION OF

TEZPAZ STOVE

www.geres.eu

Need help?

Do you have a question about the TEZPAZ and is the answer not in the manual?

Questions and answers

Summary of Contents for GERES TEZPAZ

Page 1 MANUAL FOR CONSTRUCTION AND OPERATION OF TEZPAZ STOVE www.geres.eu...
Page 2 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE www.agencynau.tj...
Page 3 The authors of this manual propose a solution to these risks: the Tezpaz Stove greatly reduces the amount of fuel required to cook, thus mitigating the risk of erosion, deforestation, and low- crop yields. The stove presented in this manual is easy to use and requires 50% less fuel.
Page 4 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE 1. “TEZPAZ” STOVE The “Tezpaz” - saves time and money! This stove is designed to make cooking easi- er and faster during the cold season. The advantages of the Tezpaz stove are listed below.
Page 5 2. CONSTRUCTION OF “TEZPAZ” STOVE The Tezpaz is built differently from traditional stoves. Construction of Tezpaz stove consists of the follow- The Tezpaz is made from galvanized sheet metal and ing steps: armature, whereas traditional stoves are made out of mud bricks.
Page 6 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE 2.1. DRAWING DESIGN OF THE “TEZPAZ” STOVE The “Tezpaz” stove consists of two parts Part 2. Part 1. “Tezpaz” stove Cylinder shaped burner for placing cooking pots. www.agencynau.tj...
Page 7 “Tezpaz” stove “Tezpaz” stove Lid, galvanized sheet t= 0,7mm, see D-1,2 View from the View from front handle, galvanized sheet Elbow Combustion Chamber t= 0,7mm, see D-1,2 Iron t= 2mm, see D-1.5, 1.6 side Lid, galvanized sheet □110х110 t= 0,7mm, see D-1,2 Inside size PART 1.
Page 8 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE Cylinder shaped Cylinder shaped Ø105 Elbow shaped pipe galvanized sheet burner, burner, t= 0,7mm, se D-3.2 Wall galvanized sheet View from the Curved edge, View from front Ø105 t= 0,7mm, see D-1.3 Н=10mm...
Page 9 2.2. MEASUREMENT AND PREPARING SEPARATE PARTS OF “TEZPAZ” STOVE “Tezpaz” stove consists of the following parts and subparts: Part 1. «Tezpaz” stove: Part 2. Cylinder shaped burner: ▪ ▪ Parts of Tezpaz stove lid: Leg; ▪ ▪ lid; Iron foot (foot, clamp, console);...
Page 10 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE Lid of “Tezpaz” stove View from the side □115х115 Inside size Curve line Full view of lid Frame 45º View from above □110х110 Inside size □115х115 Inside size 10.5 Curving line Full view of frame 1352 www.agencynau.tj...
Page 11 Full view of foundation View from above 45º Curving line Damper View from the side Ø4mm, 2 piceces 2х10,5 15,5 Full view of Tezpaz stove walls Curving line Full view of handle Curving line □115х115 2х10 10,5 10 2х10 60,5 1360 www.geres.eu...
Page 12 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE L shaped chamber of Tezpaz stove General view View from above Sides from angel ∟25*25, 4pieces L=140mm 112,5 232,5 Chamber parts View from the side View from front Corner sides Corner sides □110х110...
Page 13 Iron grate of Tezpaz stove ash-box View from above View from front Iron holders for woods Grates Armature Ø7А-1, L=920mm, 1piece. Armature Ø10А-2, L=130mm, 4 pieces Iron rod Armature Ø10А-2, L=230mm, 1 piece Support 1. armature Ø7А-1, L=150мм, 1 piece.
Page 14 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE Parts of ash-box grate 41.4 3 D view www.agencynau.tj...
Page 15 Metal body stovepipe t=0,7mm Galvanized sheet t=0,7mm, Ø105 Side walls, 2 pieces Galvanized sheet t=0,7mm, View of open leg Stove pipe, galvanized sheet t=0,7mm Trunk, galvanized sheet t=0,7mm, Curving line Side walls, galva- nized sheet, Curving line t=0.7mm, 2 pieces www.geres.eu...
Page 16 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE View from above Iron made stove foot Support, L=150mm, 4pieces Armature Ø6A-1 Foot 2.2. Clamp Armature Ø8А-1, L=130mm Armature 08A-1, L=464 Foot L=170mm, 4дона Armature Ø8A-1 Connecting with welding 10º Electrode 3mm Clamp Armature Ø8А-1,...
Page 17 Open view of cylinder shaped burner walls Bottom of cylinder shaped burner. Curving line www.geres.eu...
Page 18 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE 2.3. CONNECTING THE PARTS OF THE STOVE The first part of “Tezpaz” stove is made in the following order: Order of attach- ing the first part of Tezpaz stove. First of all, construct the lid of stove from galvanized Also, built the under lid frame and bend the sides sheet, (а) bend its sides downward.
Page 19 Then, attach the lid to the frame, which was prepared in previous section. This way, the lid of the Tezpaz stove is made. (а) Lid , view from inside; (b) Lid from outside. Foundation (bottom) of Tezpaz stove is made form galvanized metallic sheet. For this, cut the galvanized me- tallic sheet in accordance with the design and bend its all four sides as shown in the picture.
Page 20 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE Walls of Tezpaz stove is made from galvanized sheet Then attach walls to foundation (picture 4) (picture (а) attach it and (b) bend the lower sides. After attaching walls to foundation, attach two knobs (handles) (а) of the stove with rivet (а) to the...
Page 21 Attach 4 pieces of corner braces to Then place the L shaped cham- between the left (b) and right wall (c) the upper part of chamber wall (а) ber (а) inside the Tezpaz stove through welding. by welding (b). www.geres.eu...
Page 22 (b) The sides of L shaped chamber (c) must stand out from the holes little bit. This way, the first part of Tezpaz stove is finished. Then, place the iron grate of ash-box (а) inside the L shaped chamber (b).
Page 23 Begin construction of second part of Tezpaz stove from «Leg». It is made from galvanized sheet in accord- ance with design, (а) bend the edges of two sides in a way so that, next you can attach the side walls (b) the edges of the front side must be cut in a way so that next you can bend it.
Page 24 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE (а) Bend the trunk, to which the stove pipe is Weld the bent sides of wall (а) to bent side of trunk. attached; (b) Bend the left and right side walls. Curved...
Page 25 The foot is placed under the hole of cylinder. Stretch the bent of support (legs) (b) made from armature (c) by edges of cylinder bottom (а) through the hole between the welding. clamp (b) and support (c) and attach it with pin (nail) (d). www.geres.eu...
Page 26 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE View from View from above below After having finished constructing cylinder walls (а) and the bottom of stove (b) attach them in bent lower edges (c). This way, the second part of Tezpaz stove is finished.
Page 27 After having made the two parts of the stove, place Cylinder shaped burner must be placed on top of the cylinder shaped burner (а) on top of Tezpaz stove Tezpaz stove in a way so that iron foot (c) must fully (b). fit inside L shaped chamber (d).
Page 28 Tezpaz stove for operation. Tezpaz stove is a stove to be used outside in summer. Open the lid (а) clean and fill any part of the combustion For easy maintenance and keeping Tezpaz stove in chamber (b) with insulation materials such as good condition, it is recommended to keep it in one “Agloportit”...
Page 29 Rules for opera- tion of Tezpaz stove In order to fire the wood, choose dry woods in small Watch the process of burning woods. If the wood sizes.
Page 30 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE Thanks to insulation materials such as “Agloportit” Keep the Tezpaz stove away from rain. It can easily and “Keramzit”, stove can keep the heat 3 hours break from excessive moisture. after turning the stove off. Therefore, after cooking your meal, you can also boil water for tea or other use.
Page 31 Common Future Zusammenarbeit (GIZ) ronnement et Solidarités GmbH www.geres.eu This information is made possible by the support of the European Union. The contents are the sole responsibility of GERES and do not necessarily reflect the views of the European Union.
Page 32 MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE GERES - TAJIKISTAN Address: 79 Hamza Hakimzoda Street, Dushanbe, Tajikistan Phone: (+992) 37 880 65 64 E-mail: tajikistan@geres.eu Web: www.geres.eu Agency for Support Development Process Nau Address: 20-34 Lenin Street, Khujand, Tajikistan Phone: (+992 34) 224-53-20;...
