Summary of Contents for Mira 935.82
- Page 1 Shower Seat Installation & User Guide...
- Page 3 Introduction Important Points The Mira shower seat has been designed for installation inside a shower cubicle, over a bath or within the drying area. The shower seat must be secured to a flat, sound and solid wall surface (‘solid’ means constructed of brick or high density concrete block).
- Page 4 Pack Contents Checklist Tick the appropriate boxes to familiarise yourself with the part names and to confirm that the parts are included. 1 x Wallplate 2 x Grub Screws 5 x Wall Plugs 1 x 2 mm Hexagon Wrench 5 x Fixing Screws 2 x Grommets 5 x Washers 1 x Shower Seat...
- Page 5 Installation WARNING! AN INCORRECTLY FITTED SEAT MAY RESULT IN INJURY TO THE USER. Place the wallplate against the wall, with the 3 screw holes at the top of the plate Mark through the 5 screw holes, as shown in Figure 3. Use a spirit level to ensure the wallplate is level.
- Page 6 Spare Parts Part No. Description 935.82 Wallplate and Fixing Screws 935.82 935.82...
- Page 7 Notes...
- Page 8 (2 years for Mira Select and 3 years for Mira Excel Spare Parts ranges).
