Summary of Contents for Axdia DYON SMART 24 VX

Page 1: Table Of Contents
DYON SMART 24 VX V1.0.0 Content Important Safety Instructions ..............3 Support Information ................8 Appropriate use ..................8 Notes on energy efficiency ..............9 Conformity ..................11 Montage ..................... 12 Stand mounting ..................12 Wall mounting ................... 13 Controls and connections ..............14 The buttons on the device ................
Page 2 DYON SMART 24 VX 13.5 Menu Accessibility ..................38 13.6 Menu System .................... 39 13.7 Menu Support ................... 40 14 Smart Functions ................. 41 15 CI+ Information ................... 42 16 USB Devices ..................44 16.1 Connecting USB devices ................44 16.2 Video Playback ..................
Page 3: Important Safety Instructions
DYON SMART 24 VX Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings, install in accordance with the instructions.
Page 4 DYON SMART 24 VX 13) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Page 5 DYON SMART 24 VX The symbol indicates that dangerous voltages constituting a risk of electric shock are present within this unit. The symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit. Warning High voltages are used in the operation of this television receiver.
Page 6 DYON SMART 24 VX Caution Do not trap the power supply cord under the television. Never stand on, lean on, or suddenly push the television or its stand. You should pay special attention to children. Serious injury may result if it should fall.
Page 7 DYON SMART 24 VX Tips regarding environmental protection At the end of its operating life, this product may not be disposed of by way of your normal household waste. Instead it must be delivered to a collection point for recycling electrical and electronic equipment. The icon on the product, in the operating instructions or on the packaging, indicates this.
Page 8: Support Information
DYON SMART 24 VX Support Information See our website for the latest information on this device, on other products by our company and on our company itself. If you have questions or problems, please read the FAQs on our website or contact our customer support service.
Page 9: Notes On Energy Efficiency
DYON SMART 24 VX Notes on energy efficiency The device has facilities for reducing the energy requirement. Make the appropriate settings as required. Usage Mode During initial installation and via the menu: MENU button – Settings – System Adapted illuminance for home use.
Page 10 DYON SMART 24 VX Important! The device switches to standby mode independently after 4 hours without operations. Please note, this is NOT a defect. It is a legal requirement. A note occurs shortly before the device turn in the off- mode.
Page 11: Conformity
DYON SMART 24 VX Conformity We, Axdia International GmbH, hereby declare that this device corresponds to the basic requirements and relevant regulations outlined in guidelines 2014/53/EU, 2014/30/EU, 2014/35/EU and 2009/125/EC. The CE declaration of conformity for this product may be found on the following link: https://www.axdiaservice.de/konform...
Page 12: Montage
DYON SMART 24 VX Montage Stand mounting Fix the feet in the device as described in the picture and fix them with the enclosed mounting screws.
Page 13: Wall Mounting
DYON SMART 24 VX Wall mounting Fasten your wall bracket to the threads on the back and observe the hole spacing. For the wall mounting two persons are required. Please follow the mounting instructions of the wall mount used and the length of the screws used.
Page 14: Controls And Connections
DYON SMART 24 VX Controls and connections The buttons on the device VOL+ Increase the volume VOL- Decrease the volume Next channel Previous channel MENU Open the menu SOURCE Input source POWER On / Off Note The illustrations in this manual serve to describe the device functions...
Page 15: Connections
DYON SMART 24 VX Connections 1. LAN (Ethernet) 6. CI+ slot 2. Digital Auto Output 7. Headphone jack (optical) 8. 2x USB 2.0 3. AV-IN 9. HDMI 1 (ARC) 4. DVB-S (LNB IN) 10. HDMI 2 5. DVB-T2/-C (Cable) 11. HDMI 3 Please use only connection cables that are not longer than 1,5m.
Page 16: Ci/Ci+ Slot
DYON SMART 24 VX CI/CI+ Slot Note according the CI Slot Please take care to insert the CI-Module (CAM) in the correct way. The Top side of the module must face against the wall behind. This device is equipped with a CI+ slot for use with CAM modules and Smart cards which allow for the viewing of encrypted Pay-TV channels.
Page 17 DYON SMART 24 VX   Please note Module and smart card are not including. Install the CI+ module after the channel scan has been accomplished and all other settings have been set. The activation of the card may take several minutes for the first time it is used.
Page 18: Remote Key Function
DYON SMART 24 VX Remote Key Function POWER: to switch the device to on or standby INPUT: Select the input source NUMBER KEYS: used to select channel numbers or input numbers in menus GUIDE: Display program information of the current program and the following programs CH.LIST: in TV mode: open the channel list...
Page 19 DYON SMART 24 VX Inserting the battery into the remote control Remove the battery cover. Insert two AAA 1.5V batteries. Make sure that the polarity (+ or -) is correct. The polarity is indicated. Reinsert the battery cover. Note on batteries Alkaline Batteries are recommended.
Page 20: Antenna Connection
DYON SMART 24 VX Antenna connection Connection for DVB-T2 reception or cable TV Connect the signal cable (e.g. the antenna cable) to the antenna input (DVB-T27-C(Cable)) on the back of the device. After connection, turn on the device. Press the MENU button, select Settings, select Channel and select Auto Scan.
Page 21 DYON SMART 24 VX The CI+ module has the corresponding functions of a smart card already integrated. Therefore, you only need the CI+ module in Germany. Connection to the satellite receiver Connect the signal cable to the DVB-S (LNB IN) input on the back of the device.
Page 22: Initial Setup
DYON SMART 24 VX Initial setup Note Before you proceed, please make sure that the satellite, antenna or cable is connected. This screen is displayed only when the TV is turned on for the first time or reset to factory default.
Page 23: Network
DYON SMART 24 VX Network Select the desired network connection by using the /buttons, confirm your selection with the OK button. Press the BACK button to return to the previous menu. Wi-Fi Network Wireless network connection Wired network Connection via network cable...
Page 24: Terms & Conditions, Privacy Policy
DYON SMART 24 VX Terms & Conditions, Privacy Policy Use the /buttons to select "Accept all" or "View details" to obtain additional information about the data acquisition. Confirm your selection with the OK button and select OK. Press the BACK button to return to the previous menu.
Page 25: Tuning Type
DYON SMART 24 VX Tuning Type Select Begin scanning and confirm the selection with the OK button. Now select the desired reception mode, confirm your selection with the OK button and press the  button to proceed. Use the /buttons to select the desired settings and confirm your selection with the OK button.
Page 26: Tv Features
DYON SMART 24 VX 10 TV Features 10.1 EPG (Electronic Program Guide) In the Electronic Program Guide, you have the option of displaying the daily program of the current channel. To enter the EPG menu, press the GUIDE button. Use the arrow buttons to select the desired channel or program.
Page 27: Reminder
DYON SMART 24 VX 10.2 Reminder In the Electric program guide, you can set a reminder for a selected program. Use the arrow buttons to select the desired program and press the OK button. Now select Reminder and press the OK button.
Page 28 DYON SMART 24 VX Advanced functions In a TV mode, press the CH.LIST button or the OK button and press the button, to open the advanced functions. Overview of the individual functions in the channel list 1. Reception mode: Antenna, Satellite, Cable 2.
Page 29: Edit Menu
DYON SMART 24 VX Edit menu 10.3.1 In the edit menu you can delete programs, move them, etc. Move Select the channels you want to edit by using the / buttons. Press the OK button to confirm the selection. Press the button and use the /...
Page 30: Hbbtv
DYON SMART 24 VX 10.4 HbbTV Many digital channels offer additional information that can be displayed if you have an Internet connection. First select the channel whose HbbTV function you want to use. Press the red button on the remote control to open the function overview of the respective channel.
Page 31: Teletext
DYON SMART 24 VX 10.5 Teletext Teletext is an information system broadcast by certain channels which can be consulted like a newspaper. It also offers access to subtitles for viewers with hearing problems or who are not familiar with the transmission language (cable networks, satellite channels, etc.)
Page 32: Hotel Mode
DYON SMART 24 VX 10.6 Hotel Mode To enter the Hotel mode, press the MENU button and select Settings.
Page 33 DYON SMART 24 VX Select the sound menu, select speakers and now mark Balance and now enter the password 0548 directly. The Hotel Mode settings will be displayed directly. Press the / buttons to open the setting (On/Off) and then select "On".
Page 34: Edit Menu
DYON SMART 24 VX Clone Copy to USB, Restore via Hotel Info web page On / Off Edit Menu In the Edit menu, you can assign an input source or app to the Custom button (Edit1). Press and hold the Custom button until the edit menu opens.
Page 35: On-Screen Menu
DYON SMART 24 VX On-Screen Menu Quickly and easily adjust small settings. Press the MENU button to open the on-screen menu. Press the / buttons to select a setting and then press the OK button to open the setting. 13 Menu Settings Press the MENU button and use the /buttons to select a...
Page 36: Menu Sound
DYON SMART 24 VX Overview of the individual menu items Picture Mode Standard, Cinema Day, Cinema Night, Dynamic, Sports Aspect Ratio 16:9, 4:3, Panoramic, Movie Zoom, Direct Game Mode Off / On Picture Mode Settings Adjust display settings for each Picture Mode 13.2 Menu Sound...
Page 37: Menu Network
DYON SMART 24 VX 13.3 Menu Network You can make settings of the network connection here. Press the / buttons to select a setting, press the/ buttons to change the setting and OK button to confirm. Press the BACK button to return to the previous menu.
Page 38: Menu Accessibility
DYON SMART 24 VX Note After the initial installation, only channels of the currently selected input source can be edited here. Note All saved channels are deleted and overwritten during the automatic channel scan. After the automatic channel search, the first DTV station is displayed.
Page 39: Menu System
DYON SMART 24 VX 13.6 Menu System You can make settings such as language, system pin, Usage mode, etc. here. Press the / buttons to select a setting, press the/ buttons to change the setting and OK button to confirm.
Page 40: Menu Support
DYON SMART 24 VX 13.7 Menu Support Press the / buttons to select a setting, press the/ buttons to change the setting and OK button to confirm. Press the BACK button to return to the previous menu. Overview of the individual menu items...
Page 41: Smart Functions
DYON SMART 24 VX 14 Smart Functions Press the HOME button to open the Smart Functions. Netflix, Prime Video and YouTube can be opened directly via the respective buttons. Navigation is possible via the arrow buttons and the OK button to confirm.
Page 42: Ci+ Information
DYON SMART 24 VX 15 CI+ Information The TV set contains a Common Interface CI+ Slot. Different CAM cards with Smart card reader can be found at local dealers for different Pay-TV provider. • Set in: Turn off the TV. Now insert the module.
Page 43 DYON SMART 24 VX Important Menu options and existing setting points depend on the CI+ module you are using. The CI+ module (not included in the scope of delivery) is necessary to be able to receive encrypted stations using a smart card (not supplied).
Page 44: Usb Devices
DYON SMART 24 VX 16 USB Devices 16.1 Connecting USB devices This device is provided with USB ports for updating the software and playing media files. Please connect USB media directly to the USB interface of the device. If this is not possible, please use only connection cables that are not longer than 25cm.
Page 45: Picture Playback
DYON SMART 24 VX Note on Video Playback Please note that due to the variety of video formats, you can not guarantee that all files will be played back even if the actual file format is supported. Video and audio format within the file may differ from the standard and lead to incompatibility with the device.
Page 46: Troubleshoouting
DYON SMART 24 VX 17 Troubleshoouting If you have any problems with this device or installation, please refer again carefully to the relevant section in this manual and read details in the table below. 17.1 Error Notes Display Possible cause...
Page 47 DYON SMART 24 VX Check the input The reception is source using the disturbed, the antenna SOURCE button. cable is not Check the antenna connected, an unused cable. No Signal reception path has In TV mode, press been selected, or the...
Page 48: No Sound / No Picture
DYON SMART 24 VX 17.2 No sound / no picture Trouble phenomenon Symptom Inspection Check Picture Audio antenna position, direction Snow Noise or connection antenna position, direction or connection Ghost Normal audio electronic equipment, car/motorcycle, fluorescent light Interfere Noise Volume (check if mute is...
Page 49: Specifications
DYON SMART 24 VX 18 Specifications Frequency Range 48.25MHz ~ 863.25MHz 75Ω Input impedance Video System PAL, SECAM, NTSC Sound System BG, DK, I, L, MN NICAM/A2 (PAL, SECAM) Teletext 1000Pages Max. Number of 99CH channels Frequency Range VHF (50MHz ~ 230 MHz) UHF (474MHz ~ 862 MHz) 75Ω...
Page 50 DYON SMART 24 VX The terms HDMI and HDMI High-Definition Multimedia Interface and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries. Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio and the double-D symbol are trademarks of Dolby Laboratories.
Page 51 DYON SMART 24 VX Product information about the energy efficiency of this device according to EU regulation (EU) 2019/2013 can be found on the following website of the European Union from 1 of March 2021. To open, please scan the following QR code with your...
Page 52 DYON SMART 24 VX Maximum transmission power Function Frequency (MHz) Output power (dBm) 2412-2472 (802.11b/g) Wi-Fi 16,2 2412-2472 (802.11n(HT20)) 2412-2472 (802.11n(HT40)) Note on transmission power This device complies with CE limits. The device should be installed and operated with a minimum distance of 20cm between the device and your body.
Page 53: Glossar
DYON SMART 24 VX 19 Glossar DiSEqC Digital Satellite Equipment Control Digital system, with which the receiver can control different components of the external unit. It is especially used for selecting from multiple satellite positions (for example Astra and Eutelsat).
Page 54: Warranty Condition
20 Warranty Condition Axdia International GmbH, Hanns-Martin-Schleyer-Straße 36-38, 47877 Willich, hereinafter referred to as AXDIA, grants to consumers for products of the brands ODYS and DYON hereinafter referred to as product a limited warranty represented by the following warranty conditions. By this warranty, AXDIA...
Page 55 2. AXDIA Service Center will try to diagnose and solve your problem. If it is determined that a warranty claim exists, you will be given an RMA number (Return Material Authorization) and you will be asked to send the product to AXDIA.
Page 56 Service outside of warranty AXDIA can refuse any service claim made that is not covered by the warranty. If AXDIA agrees to provide a service outside the warranty, the customer will be invoiced for all repair and transport costs.
