Elkay EZFMK Installation Manual

Filter maintenance kit

Download this manual

TOOLS REQUIRED

BUT NOT PROVIDED:

INSTALLER

To insure you install this Kit easily and correctly, PLEASE READ THESE

SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK

YOUR INSTALLATION FOR COMPLIANCE WITH PLUMBING, ELECTRICAL, AND

OTHER APPLICABLE CODES.

EZ FILTER MAINTENANCE KIT

IMPORTANT

THIS IS AN INDOOR APPLICATION ONLY. ALL SERVICE TO BE

PERFORMED BY AN AUTHORIZED SERVICE PERSON.

GLOVES

SAFETY GLASSES

5/16 NUT DRIVER (HIGHLY RECOMMENDED)

OR FLAT HEAD SCREWDRIVER

IMPORTANT! INSTALLER PLEASE NOTE.

EZFMK

INSTALLATION MANUAL

Page 1

2000000888 (Rev. A - 04/23)

Need help?

Do you have a question about the EZFMK and is the answer not in the manual?

Page 1 EZFMK INSTALLATION MANUAL EZ FILTER MAINTENANCE KIT IMPORTANT THIS IS AN INDOOR APPLICATION ONLY. ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON. TOOLS REQUIRED BUT NOT PROVIDED: GLOVES SAFETY GLASSES 5/16 NUT DRIVER (HIGHLY RECOMMENDED) OR FLAT HEAD SCREWDRIVER IMPORTANT! INSTALLER PLEASE NOTE.
Page 2 EZFMK EZFMK Rough in WALL COMPATIBLE ON SINGLE-LEVEL SPACE RECOMMENDATION: AT LEAST 36” (915MM) EZ COOLERS ONLY OF SPACE ON LEFT SIDE OF DRINKING WATER UNIT IS RECOMMENDED TO CONDUCT FILTER REPLACEMENT 2000000888 (Rev. A - 04/23) Page 2...
Page 3 EZFMK 1. Installation Procedure Note: While the side access wrapper is being 1. Remove existing lower wrapper on the cooler by secured, verify the upper profile (left, front, and removing the (4) screws using a 5/16 nut driver. right side) of the wrapper frame slides up and under the plastic basin shroud assembly for a tight fit (as shown).
