Leisure UNITY 2018 Owner's Manual
  1. Manuals
  2. Brands
  3. Leisure Manuals
  4. Automobile
  5. UNITY 2018
  6. Owner's manual

Leisure UNITY 2018 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UNITY 2018 and is the answer not in the manual?

Questions and answers

Madalyn Blake
April 21, 2025

How to turn on the water pump in the unity

0
1 comments:
Mr. Anderson
May 11, 2025

To turn on the water pump in the Leisure UNITY 2018:

1. Locate one of the three water pump switches. They are found:
- On the system monitor panel above the coach entrance,
- In the bathroom,
- In the rear utility compartment.

2. Press any one of the switches. The light above the switch will turn on, indicating the pump is powered.

The pump will automatically activate when using the shower, toilet, or any faucet. To turn it off, press any switch again; the light will go off.

This answer is automatically generated

0
Dennis Lee Knowlton
June 8, 2025

location of water pump on a 2018 Unity Twin Bed

0

Related Manuals for Leisure UNITY 2018

Summary of Contents for Leisure UNITY 2018

  • Page 1 Owner’s Manual...

  • Page 3: Table Of Contents

    UNITY MOTORHOME TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS INTRODUCTION Overheating ���������������������������������������������������������������� Owner’s Manual ������������������������������������������� Parking �������������������������������������������������������� Motorhome Information Kit �������������������������� Parking ����������������������������������������������������������������������� Options and Equipment ������������������������������� Backing Up ����������������������������������������������������������������� Vehicle Certification Labels ������������������������� Extended Occupancy ��������������������������������� Leveling the Motorhome ����������������������������� Reference Number Codes �������������������������������������������...
  • Page 4 HDMI Switch Box ������������������������������������������������������� Wifi Extender (Optional) ��������������������������������������������� Exterior Lighting ��������������������������������������������������������� Entertainment System Schematics ��������������������������� Interior Lighting ����������������������������������������������������������� Satellite Pre-wire Schematic �������������������������������������� Leisure Lounge Plus System ������ WATER AND PLUMBING SYSTEM (optional) Water Supply��������������������������������������������� Lowering the Murphy Bed ������������������������������������������ Fresh Water System ���������������������������������...
  • Page 5 UNITY MOTORHOME TABLE OF CONTENTS Waste Systems ����������������������������������������� Interior Care ���������������������������������������������� Grey Water Waste Holding Tank ���������������������������� Carpets �������������������������������������������������������������������� Black Water Waste Holding Tank ��������������������������� Upholstery ��������������������������������������������������������������� Dumping Holding Tanks ������������������������������������������ Spots and Stains ����������������������������������������������������� Black Water Waste Tank Rinse ������������������������������ Vinyl Fabrics ������������������������������������������������������������...
  • Page 6 TABLE OF CONTENTS UNITY MOTORHOME...

  • Page 7: Introduction

    Your motorhome been designed manufactured to enhance your travel and camping Your Leisure Travel Vans Dealer or Triple E RV experience and to provide you with safe, efficient Customer Service at: and trouble-free operation� Email: info@tripleerv.com Before your first drive, become familiar with the...

  • Page 8: Motorhome Information Kit

    DESIGNATED SLEEPING CAPACITY The manufacturer’s designated number of sleeping positions� OPTIONS AND EQUIPMENT Leisure Travel Vans are available in various sizes GROSS AXLE WEIGHT RATING (GAWR) and floor plan configurations and with differing The value specified as the load carrying capacity of optional equipment.

  • Page 9: Certification Label Samples

    UNITY MOTORHOME INTRODUCTION COLD TIRE INFLATION PRESSURE Inflation pressures recommended (while cold) for the tires originally installed on your motorhome. These tire pressure levels must be maintained to ensure proper handling, safety and fuel economy. LOCATED ON DRIVER-SIDE DOOR FRAME (CANADA MODELS) CARGO CARRYING CAPACITY(CCC)(CANADA) Equal to GVWR minus each of the following: UVW, full fresh (potable) water weight (including water...

  • Page 10: Unity Floor Plans

    INTRODUCTION UNITY MOTORHOME UNITY FLOOR PLANS U24MB PASSENGER SIDE VIEW Light Entrance Step Furnace Exhaust Refrigerator Vents BBQ Hook-Up Generator Compartment External Receptacle Storage Compartment Ladder Option Awning Inverter and Storage Compartment U24MB DRIVER SIDE VIEW Awning Diesel Fill Shore Power Connection Slide Out Room Storage Compartment Utility Center...
  • Page 11 UNITY MOTORHOME INTRODUCTION U24MB TOP VIEW Solar Panel Air Conditioner WiFi Antenna Roof Vent Radio Antenna Satellite Sky Light TV Antenna Stack Vent U24MB LEISURE LOUNGE FLOOR PLAN...
  • Page 12 INTRODUCTION UNITY MOTORHOME U24MB LEISURE LOUNGE PLUS FLOOR PLAN...
  • Page 13 UNITY MOTORHOME INTRODUCTION U24CB PASSENGER SIDE VIEW Light BBQ Hook-Up Entrance Step Inverter and Storage Compartment Storage Compartment Ladder Option External Receptacle Furnace Exhaust Water Heater Awning U24CB DRIVER SIDE VIEW Slide Out Room Diesel Fill Shore Power Connection Awning Generator Compartment Utility Center Refrigerator Vents...
  • Page 14 INTRODUCTION UNITY MOTORHOME U24CB TOP VIEW Solar Panels Stack Vent Radio Antenna Roof Vent Satellite TV Antenna Skylight WiFi Antenna U24CB BOOTH DINETTE FLOOR PLAN...
  • Page 15 UNITY MOTORHOME INTRODUCTION U24CB U-LOUNGE FLOOR PLAN...
  • Page 16 INTRODUCTION UNITY MOTORHOME U24IB PASSENGER SIDE VIEW Light BBQ Hook-Up Awning Inverter and Storage Compartment Storage Compartment Entrance Step External Receptacle Furnace Exhaust Ladder Option Generator Compartment Refrigerator Vents U24IB DRIVER SIDE VIEW Water Heater Storage Compartment Sewer Termination Sewer Hose (Behind Doors) Utility Center Diesel Fill Shore Power Connection...
  • Page 17 UNITY MOTORHOME INTRODUCTION U24IB TOP VIEW Solar Panels Stack Vent Radio Antenna Roof Vent Satellite TV Antenna Skylight WiFi Antenna U24IB FLOOR PLAN...
  • Page 18 INTRODUCTION UNITY MOTORHOME U24TB PASSENGER SIDE VIEW Light BBQ Hook-Up Awning Inverter and Storage Compartment Storage Compartment Entrance Step External Receptacle Furnace Exhaust Ladder Option Generator Compartment Refrigerator Vents U24TB DRIVER SIDE VIEW Water Heater Storage Compartment Sewer Termination Sewer Hose (Behind Doors) Utility Center Diesel Fill Shore Power Connection...
  • Page 19 UNITY MOTORHOME INTRODUCTION U24TB TOP VIEW Solar Panels Stack Vent Radio Antenna Roof Vent Satellite TV Antenna Skylight WiFi Antenna U24TB FLOOR PLAN...
  • Page 20 INTRODUCTION UNITY MOTORHOME U24FX PASSENGER SIDE VIEW Light Generator Compartment Furnace Exhaust Inverter and Storage Compartment BBQ Hook-Up Water Heater External Receptacle Storage Compartment Ladder Option Awning Entrance Step U24FX DRIVER’S SIDE VIEW Refridgerator Vents Storage Compartment Utility Center Awning Sewer Hose Hatch (Behind Doors) Slide Out Room Diesel Fill...
  • Page 21 UNITY MOTORHOME INTRODUCTION U24FX TOP VIEW Solar Panels Roof Vent Stack Vent Radio Antenna Skylight Satellite TV Antenna WiFi Antenna U24FX FLOOR PLAN...

  • Page 22: Service Assistance

    INTRODUCTION UNITY MOTORHOME SERVICE ASSISTANCE REPORTING SAFETY DEFECTS Your dealer will assist you with any additional If you suspect your motorhome has a safety defect information you need and will answer any questions that could cause injury or death, immediately contact you have about the operation of your motorhome.

  • Page 23: Coach Specifications

    UNITY MOTORHOME INTRODUCTION COACH SPECIFICATIONS Chassis 3500 Sprinter Engine - 3.0L V6 Blue TEC Diesel 188hp / 325 lb-ft Torque Transmission - 5 Speed Automatic U24MB U24CB U24IB U24TB U24FX Turning Circle - 52.5' Axel Ratio - 3.92:1 Tires - LT215/85R16 11,030 (5003) 11,030 (5003) 11,030 (5003)
  • Page 24 INTRODUCTION UNITY MOTORHOME...

  • Page 25: Safety

    UNITY MOTORHOME SAFETY the motorhome or operates any of its components, SAFETY devices or subassemblies must be familiar with Safety, comfort and ease of operation are key this manual and the manuals in the Motorhome considerations during the design and manufacture of Information Kit.

  • Page 26: Alarms

    SAFETY UNITY MOTORHOME ALARMS WARNING All models are equipped with a combination LP gas, If you smell gas, immediately follow these carbon monoxide, and smoke alarm as standard steps: safety equipment� 1. Extinguish open flames, pilot lights and all smoking materials. 2.

  • Page 27: Fuel And Propane Safety

    UNITY MOTORHOME SAFETY PROPANE GAS ALARM WARNING The Red Gas LED will Flash and the alarm will sound a steady tone whenever a dangerous level Test this alarm’s operation after each storage of propane gas is detected� Immediate action is period, before each trip and at least once per required.

  • Page 28: Fire Prevention

    SAFETY UNITY MOTORHOME • Open doors, windows and roof vents to air out FIRE PREVENTION motorhome and silence the alarm� Identify and eliminate the source of the smoke. Fires can start in a variety of ways including, but • Replace the battery at least once per year, and not limited to, smoking, malfunctioning appliances test the battery after replacement.

  • Page 29: Fire Extinguisher

    UNITY MOTORHOME SAFETY FIRE EXTINGUISHER EMERGENCY ESCAPE - The fire extinguisher is located at the motorhome EGRESS WINDOWS entrance. In case of fire, use the following PASS Use the side entry doors or rear emergency egress method to extinguish the flames: window exit (if equipped) as emergency escape routes.
  • Page 30 SAFETY UNITY MOTORHOME WARNING Use of the motorhome is not recommended without a working fire extinguisher installed. FUNCTION Fire extinguishers are designed to put out a fire in its initial stages. Once you cannot get within 10 feet (3 m) of the fire, it is out of control and too big to fight with your extinguisher�...

  • Page 31: Motorhome Operation

    UNITY MOTORHOME MOTORHOME OPERATION MOTORHOME OPERATION weight in occupants, cargo, water, and trailer tongue weight that can be added to the motorhome without exceeding the GVWR. Refer to the Certification MOTORHOME PREPARATION Labels Samples sectin on page 7 for visual Before beginning an extended trip, ensure you are appearance and relevant locations in the motorhome thoroughly familiar with your motorhome’s condition,...

  • Page 32: Towing

    MOTORHOME OPERATION UNITY MOTORHOME TOWING AUXILIARY VEHICLE TOWING Towing a trailer can affect the handling, durability, If you are planning to tow another vehicle or a trailer performance and fuel economy of your motorhome� with your motorhome, contact your local department The factory-installed class III towing hitch is rated as of transportation for towing information�...

  • Page 33: Pre-Trip Inspection

    UNITY MOTORHOME MOTORHOME OPERATION DANGER DANGER PRE-TRIP INSPECTION 1� Ensure the motorhome and all of its components, Turn off all appliances while refueling any devices, systems and subsystems are serviced motorhome or LP gas tanks. Do NOT smoke and ready for travel. while refueling.

  • Page 34: Final Checks

    MOTORHOME OPERATION UNITY MOTORHOME FINAL CHECKS WARNING 1� Secure all objects in the motorhome. Tie, latch or All occupants must be in seats equipped lock all loose objects as appropriate. with lap or shoulder harness seatbelts with the seatbelt fastened when the motorhome is in motion.
  • Page 35 UNITY MOTORHOME MOTORHOME OPERATION LAP BELTS CAUTION The dinette is equipped with lap belts (not available on all models). Never allow occupants to travel in a Placing a child or child restraint system in seat that is not equipped with a lap or shoulder belt� a rear-facing or side-facing seat is not safe under any circumstances.

  • Page 36: Driver/Passenger Seat Controls

    MOTORHOME OPERATION UNITY MOTORHOME 3� Pull the swivel lock lever (located behind the DRIVER/PASSENGER SEAT seat) to the left, and swivel the seat slowly toward CONTROLS the center line of the motorhome to prevent damage to the seat, door panel and post. SWIVEL FUNCTION 1�...

  • Page 37: Travelling

    UNITY MOTORHOME MOTORHOME OPERATION BACK REST ADJUSTMENT GENERAL HANDLING Turn the back rest adjustment knob clockwise or counterclockwise to adjust the angle of the seat The motorhome power-to-weight ratio is lower than back. that of the average automobile. It is essential to compensate for slower acceleration when moving into traffic or when passing another vehicle.

  • Page 38: Driving Safety Tips

    MOTORHOME OPERATION UNITY MOTORHOME CAUTION DRIVING SAFETY TIPS Extended brake applications can cause 1� When backing the motorhome, have a person excessive wear, overheating and under stand to the rear on the driver’s side to guide you. extreme conditions, brake failure that could 2�...

  • Page 39: Severe Weather Information

    UNITY MOTORHOME MOTORHOME OPERATION and allow for adequate clearance� SEVERE WEATHER 3� Use your mirrors while driving to determine INFORMATION whether you are crowding the centre line or the outside edge of the highway. Remember, your motorhome requires a much different driving As a motorhome traveler, you may want to explore style than your family car�...

  • Page 40: Emergencies While Driving

    MOTORHOME OPERATION UNITY MOTORHOME chassis� EMERGENCIES WHILE DRIVING 7� If the ground is soft or unstable, carefully move the Your motorhome is designed with features that motorhome to a safe location before attempting allow the driver and occupants to resolve some to lift with the jack.

  • Page 41: Overheating

    UNITY MOTORHOME MOTORHOME OPERATION WARNING PARKING BATTERY BOOST WARNING: Consult the PARKING chassis manual in the Motorhome Information proper jump starting/boosting You can stop and park your motorhome much like an procedures. automobile; however, always remember that the unit is longer, wider and higher than a typical automobile and requires more room and clearance�...

  • Page 42: Extended Occupancy

    MOTORHOME OPERATION UNITY MOTORHOME BACK-UP MONITORING SYSTEM EXTENDED OCCUPANCY Your motorhome is equipped with a rear camera monitoring system. The rear camera view will Your motorhome is designed for recreational automatically display on the in-dash entertainment and short-term occupancy� In case of extended system display when you shift the vehicle into occupancy, there are a few things to keep in mind...

  • Page 43: Stabilizers

    UNITY MOTORHOME MOTORHOME OPERATION CAUTION REFUELING THE VEHICLE CHASSIS Exercise care and caution when parking and leveling your motorhome. Make sure all pets and people, especially children, are clear of WARNING the motorhome until leveling is complete and the motorhome is stable. Make sure all LP Gas tanks and appliances are shut off before refueling.

  • Page 44: Removing The Fuel Cap

    MOTORHOME OPERATION UNITY MOTORHOME DOOR LOCKS REMOVING THE FUEL CAP The fuel tank filler cap is located behind a flap Separate keys are required for the ignition switch adjacent to the driver’s door. Slowly remove the fuel installed in the chassis and motorhome door locks. cap to release any built up pressure�...

  • Page 45: Keys

    UNITY MOTORHOME MOTORHOME OPERATION INSIDE THE MOTORHOME ENTRY DOOR STEP Your motorhome can be locked/unlocked from the inside using the button located under the in-dash The entry system is equipped with a magnetic entertainment system. Press the button to unlock all interlock system that activates the lowering and entrance doors;...

  • Page 46: Entry Step Electrical Diagram

    MOTORHOME OPERATION UNITY MOTORHOME ENTRY STEP ELECTRICAL DIAGRAM STEP OVERRIDE SWITCH STEP COVER (ON SPECIFIC MODELS) Depress the top of the step override switch , located When the coach door is closed, you can lower inside the coach entrance, to prevent the steps from hinged plate by releasing the latch .This plate...

  • Page 47: Lighting

    UNITY MOTORHOME MOTORHOME OPERATION LIGHTING NOTICE Turn the battery disconnect switch to internal CAB ENTRY LIGHT 12 volt DC power to operate the interior A light is located above each cab door and comes roof lights. Refer to the “Electrical System on when the door is opened�...

  • Page 48: Slide Out Room

    MOTORHOME OPERATION UNITY MOTORHOME baggage doors are closed and there are no SLIDE OUT ROOM obstructions� Your motorhome may be equipped with an 9� Make sure all bystanders are clear of the area expandable slide out room , which provides extra before operating the slide out room controls�...

  • Page 49: Extending The Slide Out Room

    UNITY MOTORHOME MOTORHOME OPERATION EXTENDING THE SLIDE OUT ROOM SLIDE OUT ROOM EMERGENCY The slide out control switch is located in the OPERATION cabinet above the coach entrance doorway. If the slide out room fails to extend or retract Depress and hold the bottom of the slide out control electrically, you can manually operate the slide out switch until the slide out room is fully extended,then...
  • Page 50 MOTORHOME OPERATION UNITY MOTORHOME 7� Remove foil covering the access panel on the CAUTION right side� If you have unplugged the motor electrical connectors ( & ) from the control module , do NOT move the motorhome unless the slide out room and the slide out room motors electrical connectors &...
  • Page 51 UNITY MOTORHOME MOTORHOME OPERATION 11� Peel back the exterior sweep gasket from the ACCESSING THE MOTOR WHEN SLIDE OUT IS top corners of the slide out, and lift the slide out motor about 1/2'' to release. 1� Turn the battery disconnect switch to the “OFF” position, and disconnect the shore power.

  • Page 52: Awning

    MOTORHOME OPERATION UNITY MOTORHOME 5� Remove the mounting screws on either side � AWNING EXTENDING THE AWNING 1� Depress and hold the awning switch , located on the passenger side seat base, in the “OUT” (extend) position until the awning has fully extended and the lead rail is accessible�...

  • Page 53: Retracting The Awning

    UNITY MOTORHOME MOTORHOME OPERATION NOTE: Ensure that the support leg feet have 5� Lift the retaining pin on the coach awning been properly locked into the tabs on the lead support bracket and insert the support foot plate rail end caps when retracting the awning� .
  • Page 54 MOTORHOME OPERATION UNITY MOTORHOME...

  • Page 55: Appliance And Equipment Operation

    UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION APPLIANCE AND OPERATING THE REFRIGERATOR Press and hold the power button to turn the EQUIPMENT OPERATION refrigerator on and off. After the refrigerator has been Appliances and equipment may vary according to turned on, press one of buttons , or to select your motorhome model, specifications and floor...

  • Page 56: Refrigerator Operating Tips

    APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME STOVE TOP REFRIGERATOR OPERATING TIPS 1� Ensure the refrigerator is cold before placing The stove top operates on LP Gas. It must be lit items in it� manually using the integrated igniter� Ensure the LP 2�...

  • Page 57: Microwave/Convection Oven

    UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION extended period of time without placing cookware MICROWAVE/CONVECTION above the flame. Overheating the burner grates OVEN may cause damage� 5� Turn on the roof vent and open a window to ensure proper ventilation when operating the OPERATING THE MICROWAVE/ stove top.

  • Page 58: Exterior Bbq Connection

    APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME EXTERIOR BBQ CONNECTION LP GAS FURNACE Your motorhome is equipped with an exterior supply OPERATING THE LP GAS FURNACE source to furnish LP Gas to your own barbeque (BBQ). The connection point is located at the rear on The LP Gas furnace is controlled by the single-zone the passenger side�...
  • Page 59 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION 2� Do not attempt to manually light the furnace. The ROOF AIR CONDITIONER furnace does not have a pilot light. It is ignited by WITH HEAT PUMP a direct spark ignition system. NOTE: Simultaneously hold the thermostat The roof air conditioner is controlled by the same plus (+) and minus (-) buttons to switch...
  • Page 60 APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME COACH POWER ROOF VENT MAINTAINING THE ROOF AIR The coach power roof vent is used to provide CONDITIONER/HEAT PUMP controlled air flow throughout the coach cabin. Use the Clean or change the air conditioner filter at least every vent fan in conjunction with an open window to two weeks when the air conditioner is in operation.
  • Page 61 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION VENT HOOD HEIGHT CONTROL BATHROOM ROOF VENT The rotary knob controls the height position of the vent hood. Turn the knob clockwise to pull the hood The bathroom roof vent provides air flow and venting down and close it.
  • Page 62 APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME SIDE WINDOW VENTS MANUAL ROOF VENT Turn the knob counterclockwise to open the Use the manually operated roof vent in conjunction window vent and clockwise to close the window vent. with the power roof vent to provide adequate air flow throughout the motorhome�...
  • Page 63 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION CLOSING THE ROOF VENT ADJUSTING THE TENSION 1� Lift the handle to release it from the seat � INCREASING TENSION 2� Pull down the roof vent down using the handle � To increase the spring tension remove the end cap, 3�...
  • Page 64 APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME ENTERTAINMENT SYSTEMS U24CB AND U24FX FLOOR PLANS The TV is stowed in the following locations: In these floor plans, TVs are located in the bedroom area and in the front of the couch beside the entrance door .
  • Page 65 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION U24MB FLOOR PLAN TV OPERATION The TV is stowed in the coach passenger side Refer to the TV manual in the Motorhome Information countertop and is accessed by pulling the release Kit for detailed operating instructions� lever located at the coach entrance�...
  • Page 66 APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME TV UTILITY PANEL EXTERNAL CABLE TV CONNECTION The TV utility panel (location varies depending Your motorhome is equipped with an external cable on floor plan) is equipped with a TV antenna booster TV hookup connector located in the rear utility switch .
  • Page 67 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION HDMI SWITCH BOX Your motorhome may be equipped with an HDMI audio/video switch box . This enables HD quality viewing for your DVD player or satellite receiver (not supplied). Refer to the "Entertainment System Schematics" section in this manual and the HDMI switch box manual in the Motorhome Information Kit for further details�...
  • Page 68 APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME ENTERTAINMENT SYSTEM SCHEMATICS U24MB ENTERTAINMENT SYSTEM SCHEMATIC...
  • Page 69 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION U24CB/FX ENTERTAINMENT SYSTEM SCHEMATIC...
  • Page 70 APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME U24 IB/TB ENTERTAINMENT SYSTEM SCHEMATIC...
  • Page 71 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION HDMI MATRIX SWITCH SCHEMATIC HDMI MATRIX (3D Ultra HD 4Kx2K HDMI 4x2) User Manual 1.0 INTRODUCTION HDMI Matrix is a perfect matrix product with detached external audio output ports, which can connect 4 different HDMI signal sources and 2 displays. It can easily OUTPUT B SIGNAL OUTPUT A...
  • Page 72 APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME SATELLITE PRE-WIRE SCHEMATIC Your motorhome is pre-wired for satellite dish installation (location varies according to floor plan).
  • Page 73 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION from bed by lifting and holding the lock button LEISURE LOUNGE PLUS while you swivel the seat. Release the lock SYSTEM (OPTIONAL) button when the chair is slightly rotated to ensure the seat locks into the next position.
  • Page 74 APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME CAUTION RAISING THE MURPHY BED 1� Pull the adjustable headboard/backrest Failure to pull the release strap will cause toward you for desired comfort. To collapse damage to the Murphy bed. headboard/backrest, pull it out all the way and it will release.
  • Page 75 : You can rotate the chairs LEISURE LOUNGE PLUS SEATING by lifting and holding the lock button on the Leisure lounge recliners can be configured as follows: side of the chair and releasing the lock when the chair is at the desired angle� •...
  • Page 76 APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME BOOTH DINETTE BED U LOUNGE U24CB SEATING/SLEEPING CONVERSION (Varies According to Floor Plan) BOOTH DINETTE BED CONVERSION 1� Pull the table release handles and lower the table until it is level with the seating base. 1�...
  • Page 77 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION U24TB SLEEPING U24IB/TB SEATING TWIN BED CONVERSION INSTALLING THE REMOVABLE TABLE 1� Fold out the cushion support � ASSEMBLY 1� Locate the table leg and table top stored in the bedroom cabinet/bed base� 2� Engage the table leg into the floor plate install the table top onto the leg�...
  • Page 78 APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME 4� Bed down with the headboard tilted out as LEISURE LOUNGE SEATING backrest � (Available in U24MB and U24FX) 1� Bench configuration � 5� Rear seating (lock ottoman to prevent movement while the vehicle is in motion) �...
  • Page 79 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION ELECTRICAL SYSTEM SHORE POWER To operate using shore power, connect the 120 volt OPERATION AC power supply cable (stored in the driver’s side rear exterior storage compartment) to the external ELECTRICAL SUPPLY receptacle located on the driver’s side of the Your motorhome is equipped with two electrical motorhome�...
  • Page 80 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME WIRING SCHEMATIC U24MB 30 AMP 120V WIRING SCHEMATIC U24CB 30 AMP 120V WIRING SCHEMATIC...
  • Page 81 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION U24IB 30 AMP 120V WIRING SCHEMATIC U24TB 30 AMP 120V WIRING SCHEMATIC...
  • Page 82 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME U24FX 30 AMP 120V WIRING SCHEMATIC U24MB 12V WIRING SCHEMATIC...
  • Page 83 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION U24CB 12V WIRING SCHEMATIC U24IB 12V WIRING SCHEMATIC...
  • Page 84 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME U24TB 12V WIRING SCHEMATIC U24FX 12V WIRING SCHEMATIC...
  • Page 85 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION WATER HEATER SWITCH SYSTEM MONITOR This switch controls the power to the water heater. The system monitor panel, located in the cabinet Turn the switch counterclockwise from the "OFF" above the coach entrance doorway, monitors the position for water heater function or clockwise from following systems: the "OFF"...
  • Page 86 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME If a circuit breaker “trips,” allow a brief cool down POWER DISTRIBUTION PANEL period of 30–90 seconds, then reset the breaker by The power distribution panel , located in a lower turning it “OFF” and then “ON.” If a circuit breaker cabinet fascia, contains the 120 volt breakers for the “trips”...
  • Page 87 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION 12 VOLT DC CHASSIS FUSES Refer to the chassis operator’s manual for chassis fuse functions� DRIVER SEAT PEDESTAL FUSES Fuse #11: 10 amp fuse powers the following components: • Electric step safety retract • Stabilizer jack safety retract •...
  • Page 88 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME OPERATING THE AUXILIARY LP STARTING THE AUXILIARY LP GAS GAS GENERATOR GENERATOR Turn on the LP Gas valve by depressing the top of 1� Depress and hold the top of either of the two the LP Gas shut off switch located in the utility generator start buttons until the generator starts center in the driver’s side exterior compartment.
  • Page 89 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION GENERATOR HOUR METER STARTING THE AUXILIARY DIESEL This meter is for tracking usage of the generator. GENERATOR 1� Depress red “Display ON” button to waken NOTICE the generator set display screen and start the There is a breaker on the side of the unit.
  • Page 90 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME NOTICE STOPPING THE AUXILIARY DIESEL Overloading the generator for long periods GENERATOR of time can cause the generator windings rior to stopping the generator, turn off all large to overheat. Keep electrical loads within the appliances and let the generator run for two minutes recommended wattage ratings.
  • Page 91 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION GENERATOR SAFETY AUTOMATIC POWER TRANSFER ELECTRICAL SWITCH WARNING AUTOMATIC SWITCH OVER Starting the generator will automatically switch power Exercise extreme care and caution when from 120 volt AC shore power to generator power. handling the generator and its components. Carelessness can be dangerous and even BUILT-IN DELAY fatal.
  • Page 92 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME 12 VOLT DC SYSTEM The 12 volt DC power system in your motorhome consists of the following two distinct, but interconnected, battery systems CHASSIS BATTERY The chassis battery operates the vehicle starter, vehicle accessories and all vehicle controls on the instrument console, such as the heater fans, exterior lights, horn, speed control, windshield wipers, etc.
  • Page 93 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION NOTICE COACH BATTERY CONDITION METER A surge protection fuse is installed inside the For voltage readings, refer to Magnum Inverter coach batter storage compartment . If the Remote Control Status display � coach batteries fail to operate, inspect this fuse and replace if necessary.
  • Page 94 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME flush with clean water. Foaming around terminals LONG-TERM STORAGE or on top of the battery is normal during the Turn off the coach battery disconnect during extended cleaning process� periods of storage. Hook up a battery charger at least once a month, or connect the 120 volt AC shore line NOTICE to a suitable power source�...
  • Page 95 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION necessary to change some internal settings� Please CAUTION refer to the Inverter / Remote Control manual for Remove rings, metal watchbands and other setting or contact the manufacturer. The Magnum metal jewelry before working around a battery. ME-MR controls the invert and charge features of Use caution when using metal tools.
  • Page 96 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME SURGE GUARD (OPTIONAL) INVERTER REMOTE CONTROL PANEL The Inverter Remote Control Panel is located in the cabinet above the coach entrance doorway. The Inverter Remote Control Panel is equipped with an Inverter Function - ON/OFF switch .
  • Page 97 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION TROUBLESHOOTING GUIDE Error Code Chart In order to help troubleshoot the problem(s) you are Normal Operating Condition. experiencing and render the best possible solution, Reverse Polarity (hot and neutral wires reversed). it is necessary you be at your motorhome when you place your call�...
  • Page 98 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME SIDE MARKER LIGHTS NOTICE The solar power unit is intended to charge the coach batteries only. It does not generate enough power to run the motorhome’s electrical system. LIGHTING MAINTENANCE The following procedures detail replacement of the coach interior and exterior lights�...
  • Page 99 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION 3� Unclip the electrical connector from the light INTERIOR LIGHTING you are replacing� CEILING AND OVERHEAD CABINET LIGHTS 4� Remove the two nuts securing the support bracket to the light assembly and remove the support bracket. 5�...
  • Page 100 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME READING LIGHTS EXTERIOR UTILITY CENTER LIGHT The coach reading lights are not serviceable. If the The exterior utility center light is controlled by reading light stops working, have the entire unit the exterior storage and utility center light switch replaced by a qualified service technician.
  • Page 101 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION BAGGAGE COMPARTMENT LIGHT The baggage compartment light is controlled by the exterior storage and utility center light switch inside the coach� Refer to the "Exterior/Interior Light Switches" section in the “Motorhome Operation” section for instructions� NOTE: This is a sealed LED unit and must be replaced as complete unit�...
  • Page 102 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME...
  • Page 103 UNITY MOTORHOME WATER AND PLUMBING SYSTEM WATER AND PLUMBING CITY WATER SUPPLY The city water source supplies your motorhome’s SYSTEM water system with water at pressure of the external source when the water pump is switched off� WATER SUPPLY Your motorhome is designed with fresh water, grey CONNECTING THE EXTERNAL WATER SUPPLY water and black water systems and the associated 1�...
  • Page 104 WATER AND PLUMBING SYSTEM UNITY MOTORHOME DISCONNECTING THE CITY WATER SUPPLY position � 1� Turn off the city water supply. 6� Turn on the water pump switch � 2� Relieve the water pressure in the line by opening 7� Slowly open the cold water tap until the water a faucet in the motorhome�...
  • Page 105 UNITY MOTORHOME WATER AND PLUMBING SYSTEM DISINFECTING THE WATER TANK WATER PUMP SWITCH To power the water pump one of the three switches Periodically disinfect the fresh water system. Disinfect needs to be turned on. The light above the water when the system is new or has not been used for an pump switch will light up.
  • Page 106 WATER AND PLUMBING SYSTEM UNITY MOTORHOME WATER PUMP WATER PUMP INITIAL STARTUP The water pump is designed to supply on-demand 1� Make sure all drain valves are closed. water from the fresh water tank to the various water 2� Turn off the water pump switch �...
  • Page 107 UNITY MOTORHOME WATER AND PLUMBING SYSTEM IF WATER PRESSURE DROPS 1� Check faucets and connections for leaks. 2� Make sure faucet aerators and filters are clean. 3� Make sure there is water in the tank. 4� Make sure the chassis battery is not discharged. 5�...
  • Page 108 WATER AND PLUMBING SYSTEM UNITY MOTORHOME DRAINING THE FRESH WATER DRAINING THE HOT AND COLD SYSTEM WATER SYSTEMS To drain the fresh water tank , open the fresh 1� Disconnect the city water supply if connected water tank drain valve located either under the 2�...

  • Page 109: Waste Systems

    UNITY MOTORHOME WATER AND PLUMBING SYSTEM WATER FILTER WASTE SYSTEMS The water filter is located below the kitchen or GREY WATER WASTE HOLDING TANK bathroom sink (location varies depending on floor plan). Replace the water filter at least annually to The drainage from the kitchen sink and shower pan is ensure water quality.

  • Page 110: Dumping Holding Tanks

    WATER AND PLUMBING SYSTEM UNITY MOTORHOME DUMPING HOLDING TANKS BLACK WATER WASTE TANK RINSE 1� Connect the sewer hose to the tank outlet The motorhome is equipped with a black water located on the rear driver’s side underbody. The waste tank flushing system to improve draining and sewer hose is stored on the driver’s side under to reduce odor.

  • Page 111: Macerator

    UNITY MOTORHOME WATER AND PLUMBING SYSTEM Refer to the macerator manual located in the MACERATOR Motorhome Information Kit for further information� Your motorhome may be equipped with a macerator . The macerator breaks down the solid matter in WASTE WATER HOLDING TANK - the black water holding tank.

  • Page 112: Using On-Site Sewer Hook-Ups

    WATER AND PLUMBING SYSTEM UNITY MOTORHOME WATER HEATER USING ON-SITE SEWER HOOK-UPS When staying at a campsite where sewer hook-up is WATER HEATER OPERATION available, the sewer hose may be attached and left in place for the duration of the stay� The water heater is accessible from outside the coach.

  • Page 113: Winterizing

    UNITY MOTORHOME WATER AND PLUMBING SYSTEM 3� Turn the propane "shut off" switch to ON� TRUMA AQUAGO WATER ® HEATER SWITCHING ON THE APPLIANCE 1� Open the access door� 2� To switch on the appliance, switch the POWER switch to one of the two “ON” positions. Both ON positions on the POWER switch have the same function�...

  • Page 114: Led Rotary Switch Ecoclean

    WATER AND PLUMBING SYSTEM UNITY MOTORHOME WATER FIXTURES LED ROTARY SWITCH ECOCLEAN With the rotary switch you can choose between the FRESH WATER TOILET following operating modes: The toilet in your motorhome operates much like a residential toilet except it uses much less water� Your motorhome is equipped with either a manual flush or macerator toilet.

  • Page 115: Macerator Toilet

    UNITY MOTORHOME WATER AND PLUMBING SYSTEM WATER FILL SPRAY NOZZLE The manual flush toilet is equipped with a hand held Press and release button to raise the water in spray nozzle � the toilet� NORMAL FLUSH Press and release button to flush.

  • Page 116: Showers

    WATER AND PLUMBING SYSTEM UNITY MOTORHOME 5� If the operation of the manual flush valve is EXTERIOR SHOWER diminished or becomes stiff, lubricate the toilet plunger� Keep the toilet plunger lubricated by Your motorhome is equipped with an exterior shower leaving a small amount of water in the toilet or unit located in the exterior utility center�...

  • Page 117: Liquid Propane Gas System

    UNITY MOTORHOME LIQUID PROPANE GAS SYSTEM LIQUID PROPANE GAS SAFE USE OF LP GAS The LP Gas system is designed and built to adhere SYSTEM to federal government and industry regulatory LP (Liquid Petroleum) Gas is a colorless gas requirements� compressed into liquid form for easy transportation and storage.

  • Page 118: How Lp Gas Works

    LIQUID PROPANE GAS SYSTEM UNITY MOTORHOME HOW LP GAS WORKS There are two types of LP (liquid petroleum) Gas: propane and butane. Both are compressed into a liquid state for easier transportation and storage� Common names used for LP Gas are tank gas, bottle gas, or simply LP.

  • Page 119: After Refilling The Lp Gas Tank

    UNITY MOTORHOME LIQUID PROPANE GAS SYSTEM LP Gas stations are found in all parts of the country� AFTER REFILLING THE LP GAS TANK Check the yellow pages in your telephone book or on-line if you have trouble finding a station. Look 1�...

  • Page 120: Lp Gas Tank Regulator

    LIQUID PROPANE GAS SYSTEM UNITY MOTORHOME CAUTION LP GAS TANK REGULATOR The LP Gas tank regulator has a plastic cover to Do not use an open flame or a heat lamp to protect it from the weather. Only qualified service thaw the regulator.

  • Page 121: Avoiding Asphyxiation

    UNITY MOTORHOME LIQUID PROPANE GAS SYSTEM change or when the underbody of the motorhome AVOIDING ASPHYXIATION makes contact with an object or becomes 1� Do not use portable fuel-burning equipment such damaged� as wood or charcoal grills, heaters or stoves 7�...
  • Page 122 LIQUID PROPANE GAS SYSTEM UNITY MOTORHOME...

  • Page 123: Motorhome Maintenance

    UNITY MOTORHOME MOTORHOME MAINTENANCE surface of the motorhome, it is time to polish and wax MOTORHOME MAINTENANCE it� EXTERIOR CARE AND This will not only improve the appearance of your MAINTENANCE motorhome, but will also protect the painted surfaces from oxidation and corrosion making it easier to wash�...

  • Page 124: Solar Panels

    MOTORHOME MAINTENANCE UNITY MOTORHOME INTERIOR CARE SOLAR PANELS Solar panels should be cleaned monthly using water Dirt and dust accumulation can not only detract from and a soft sponge or cloth. If required, a mild non- the motorhome’s appearance, but can also shorten abrasive cleanser can be used for more stubborn the life of carpets and fabrics.

  • Page 125: Draperies, Curtains And Bedspreads

    UNITY MOTORHOME MOTORHOME MAINTENANCE more stubborn stains, Fantastik™ or Mr. Clean™ SINKS diluted 3:1 with water are recommended.” The sinks can be cleaned with warm water and soap. Wipe dry to avoid streaks. For stubborn stains, a DRAPERIES, CURTAINS AND mild abrasive may be necessary.

  • Page 126: Microwave/Convection Oven

    MOTORHOME MAINTENANCE UNITY MOTORHOME STORAGE AND WINTERIZATION MICROWAVE/CONVECTION OVEN Keep the door and inside of your microwave/convection Inspect all systems, components and appliances oven clean. Do not allow grease, spatter or solid matter prior to storing your motorhome� to build up. An accumulation of solid matter can absorb microwave energy and increase cooking time.

  • Page 127: Cold Temperature Storage

    UNITY MOTORHOME MOTORHOME MAINTENANCE COLD TEMPERATURE STORAGE WATER SYSTEM WINTERIZATION - DRAINING 1� Drain the fresh water tank by opening the fresh water tank drain valve � Refer to the “Water and Plumbing System” section for location details. 6� Attach the blow out plug to the city water hookup in the utility center�...

  • Page 128: Spring Startup

    MOTORHOME MAINTENANCE UNITY MOTORHOME 14� For Unity U24TB and U24IB models only: With protect the holding tanks from freezing. Be sure to the termination valves closed, run the macerator add a sufficient amount of non-toxic RV antifreeze to (if equipped) for 10 seconds or until the pump is protect the total volume of the holding tanks.

  • Page 129: Winterizing The Water Systems

    UNITY MOTORHOME MOTORHOME MAINTENANCE connection in the utility compartment and attach CAUTION the blowout plug to the San-T-Flush connection. Ensure no air pressure or winterization fluid Blow compressed air through the San-T-Flush enters the water heater as part of this process. connection for about 15 seconds, remove the blowout plug and replace the cap on the SanT- 7�...
  • Page 130 MOTORHOME MAINTENANCE UNITY MOTORHOME NOTICE WINTERIZING COMFORT PLUS No Air PSI / Winterizing fl uid is to enter water WATER HEATER heater. 1� Ensure water heater is turned OFF and valves are open� 7� Make sure that valve remains in the closed position�...

  • Page 131: Maintenance And Servicing

    UNITY MOTORHOME MOTORHOME MAINTENANCE 13� Open valve (leave valve open after clearing the system with compressed air). 14� Remove air supply chuck. 15� Wait until winterizing fluid is leaving the drain line. Collect escaping fluid in a suitable container. 16� Close valve after winterizing fluid is seen.

  • Page 132: Entry Door Step

    MOTORHOME MAINTENANCE UNITY MOTORHOME Refer to the stabilizer installation guide located the Motorhome Information Kit for further details on adjustment and maintenance. ENTRY DOOR STEP Periodically lubricate the electric entry door step mechanism � Refer to the electric step manual in the Motorhome Information Kit for details�...

  • Page 133: New Vehicle Limited Warranty

    UNITY MOTORHOME NEW VEHICLE LIMITED WARRANTY such defective structural parts. For purposes NEW VEHICLE LIMITED of structural warranty coverage, structural parts shall include only the metal structure of the WARRANTY coach and all metal members welded to it, studs TRIPLE E CANADA LTD. and framing in the walls of the coach, roof rafters (REVISED SEPTEMBER 2017) and delamination of the fiberglass body parts of...
  • Page 134 NEW VEHICLE LIMITED WARRANTY UNITY MOTORHOME or service, adjustments, tune ups, alignments, cases warranty extension programs) covering its respective Component(s). Triple E RV assigns road service or failure to protect the Motorhome to the first purchaser of the Motorhome each from further damage if any initial indication of and every such separate warranty with respect damage has occurred.
  • Page 135 UNITY MOTORHOME NEW VEHICLE LIMITED WARRANTY than an authorized Triple E RV service center or sole and only warranties issued by Triple E RV in respect of your Motorhome, and Triple dealer. All such repairs performed at a site other E RV hereby expressly disclaims all other than an authorized Triple E RV service center warranties, including implied warranties of...
  • Page 136 NOTES UNITY MOTORHOME NOTES...
  • Page 137 LTV Roadside Assistance 4287 Beltline Road, Box #198 Addison, TX 75001 for EMERGENCY ROADSIDE CALL 1•877•219•3831...
  • Page 138 Triple E Recreational Vehicles and Leisure Travel Vans are brands and trademarks of Triple E Canada Ltd. 301 Roblin Blvd., Box 1230 Winkler, MB Canada R6W 4C4 Telephone: 204-325-4361 Fax: 204-325-5241 US Address: P.O. Box 68 Walhalla, ND 58282 www.tripleerv.com • info@tripleerv.com • www.leisurevans.com • general@leisurevans.com Product improvement is a continuing process at Triple E Recreational Vehicles.

Table of Contents

Save PDF
