Summary of Contents for FORSTA FILTERS 180 Series
- Page 1 180 S ERIES PERATION AND AINTENANCE ANUAL Forsta Filters Inc | www.forstafilters.com | (310) 837-7177...
-
Page 2: Table Of Contents
Particle Remover ............................. 8 Figure 10: 180 Series Filter – Particle Remover ................8 Spare Parts ............................... 9 Figure 11: 180 Series Filter – 2- 5-year Parts Maintenance ............9 Hydraulic Piston ............................. 10 Figure 12: 180 Series Filter – Hydraulic Piston ................ -
Page 3: Filter Basics
FILTER BASICS The Forsta 180 Series is a self-cleaning screen water filter. The major components include the Filter Housing (1), Coarse Screen pre-filter (11), Fine Screen filter element (2), Particle Remover (3), Hydraulic Piston (8), and Backwash Valve (12). N3: Flush Outlet... -
Page 4: Quickstart Guide
2. INLET PRESSURE MUST REMAIN 2.00 ABOVE 40 PSI (2.5 BAR) DURING BACKWASH Filter FLUSH Isolation Isolation 3. INSTALLATION OF ISOLATION AND BYPASS Valve VALVES STRONGLY RECOMMENDED Valve INLET OUTLET Bypass Valve Figure 4: 180 Series Filter – Quick Start Guide... -
Page 5: Installation Requirements
INSTALLATION REQUIREMENTS 180 Series filters may be mounted directly on the inlet (N1) and outlet (N2) flanges, and positioned in any orientation. As shown below in figure 4, isolation valves should be installed at the inlet and outlet, and a bypass valve should be installed between the flanges. -
Page 6: Hydraulic Connections
Hydraulic Connection Each flanged connection nozzle (N1 & N2) on the 180 Series filter has two ¼” threaded couplings. One may be used to install a pressure gauge or other sensor equipment. The other ¼” coupling will be used to connect hydraulic tubing from the differential pressure switch to the filter. -
Page 7: Backwash Cycle
HYDRAULIC MOTOR CHAMBER (LOW PRESSURE) Figure 7: 180 Series Filter – Backwash Cycle Water flows through the suction nozzles, down the interior of the particle remover, and out the hydraulic motor. The rapid flow of water through the hydraulic motor forces the entire particle remover to rotate, enabling each suction nozzle to cover a radial strip of screen. -
Page 8: Flow & Pressure Requirements
MAINTENANCE & SPARE PARTS Startup When pumping water through the Forsta 180 Series for the first time or after it has been empty, it is important to follow a correct sequence of valve actuation in order to prevent damage to the filter components. -
Page 9: Periodic Maintenance
12 of the manual. Furthermore, an animated video of the individual parts being assembled and disassembled will be provided in the “180 series” link on our website... -
Page 10: Particle Remover
Particle Remover 3.5 Suction Nozzle 3.8 Retainer 3.4 Hydraulic Motor 3.3 Casing 7 Hex Spacer 3.1 Rod 3.2 Rod Counter-Nut 3.7 End-Cap Figure 10: 180 Series Filter – Particle Remover... -
Page 11: Spare Parts
Cover Seal (5) Screen O-rings (6) Hex Spacer (7) Hydraulic piston (8) Shaft tip (8.9) Piston Seal Kit (8K) Valve (12) Mini-Filter (16) Differential Pressure Gauge (18) Tubing & fitting Figure 11: 180 Series Filter – 2- and 5-Year Parts Maintenance... -
Page 12: Hydraulic Piston
Shaft O-Ring Pin Holder Position Pin Shaft Tip 8.10 Piston Shaft 8.11 U-Cup Holder 8.12 Casing U-Cup 8.14 Casing 8.15 Casing Cap 8.16 Piston Head 8.10 Head Gasket 8.17 Figure 12: 180 Series Filter – Part List – Hydraulic Piston... -
Page 13: Piston Seal Replacement Instructions
7. Replace shaft U-cup (8.3) 8. Replace head O-ring (8.4) 9. Before reassembling, lubricate internal surfaces using silicone grease 10.Ensure everything is clean and lubricated before reversing the steps to assemble Figure 13: 180 Series Filter – Piston Seal Replacement... -
Page 14: Troubleshooting Guide
There should be HYDRAULIC MOTOR CHAMBER clearance between the suction nozzles and the screen. (LOW PRESSURE) c) Check for any severe damage or wear on any of the components. Figure 14: 180 Series Filter – Troubleshooting... -
Page 15: Screen Removal/Installation Instructions
Screen Removal Instructions Figure 15: 180 Series Filter – Screen Removal... - Page 16 Screen Installation Instructions Figure 16: 180 Series Filter – Screen Installation...
-
Page 17: Installation & Wiring
DP CONNECTIONS H - K1 (High Pressure Inlet) L - K2 (Low Pressure Outlet) DP WIRING 1: P 2: D Differential Filter Pressure Gauge Isolation Isolation Valve Valve INLET OUTLET Bypass Valve Figure 17: 180 Series Filter – EC-2 Wiring... -
Page 18: 2X180 Series Filters In Parallel
L - K2 (Low Pressure Outlet) R(left). ------- RED R(right). ----- BLACK 1. -------------- WHITE Filter DP WIRING 1: P 2: D Isolation Isolation Differential Valve Valve Pressure Gauge Bypass Valve Figure 18: 180 Series Filter – 2x180 in Parallel... -
Page 19: Warranty
Liability is limited to replacement or repair of products provided by Forsta Filters, and no agent or sales representative has authority to extend the warranty period without the express written consent of Forsta Filters, Inc. Shipping...
