- Page 1 File version: V1.1 SR-EOS Energy Storage Battery User Manual V1.1 SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 1 of 29 F: +86 0755-27325578 W: www.srnesolar.com...
-
Page 2: Range Of Application
If you have any suggestions during the use, please do not hesitate to give us feedback. 1.1 Range of Application The installation and user manual of SR-EOS series is applicable to the installation and use of the following products:... -
Page 3: Safety Precautions
Do not touch the product in 5mins after shutdown Comply with RoHS standard The Energy storage system should not be disposed together with the household waste. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com... -
Page 4: General Safety
DANGER! weather, such as thunder, rain, snow, and gale level 6. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com... -
Page 5: Personnel Safety
● Never place the battery in the fire to avoid explosion and prevent the personal safety from being endangered. ● Do not place the battery module in water or other liquids. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com... -
Page 6: Personnel Requirements
Never install or remove any power cables when the power is on. The electric arcs or sparks may be generated at the moment when the power cable contacts with the conductor, which may cause fire or personal injuries. DANGER! SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com... -
Page 7: Grounding Requirements
● Do not place any inflammable or explosive items around the device. ● When the device is running, do not block the ventilation vent or heat dissipation system to prevent fire caused by high temperature. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com... -
Page 8: Product Introduction
Lithium Battery Standard EN61000-3-2,EN61000-3-3 Storage time / temperature 6 months @25℃;3 months @35℃;1 months @45℃; Charging temperature range 0～45℃ SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 8 of 29 F: +86 0755-27325578... -
Page 9: Appearance Description
⑥ Version number 0: Version 0 3.3 Appearance Description 3.4.1 Dimentions Overall dimensions（L*W*H）:620*450*140.2mm Mounting dimensions（L*W）:400*300mm SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 9 of 29 F: +86 0755-27325578 W: www.srnesolar.com... -
Page 10: Interface Introduction
⑩ Grounding screw ⑪ LED(ALM) ⑫ LED( CAPACITY) ⑬ Battery Positive ⑭ Battery Negative ⑮ Breaker switch SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 10 of 29 F: +86 0755-27325578... -
Page 11: Application Scenarios
BMS system, which can be easily expanded and can be combined into 20Kwh battery pack at most. The battery storage can be combined with SRNE brand inverter to form an off-grid photovoltaic system, which can solve the problem of electricity consumption in areas without electricity. -
Page 12: System Installation
Power Cable 25mm Signal cable RJ45,1m Installation auxiliary board 400*500mm M12-800160-125A/1000V, Parallel Power Cable 2(option) 25mm SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 12 of 29 F: +86 0755-27325578 W: www.srnesolar.com... - Page 13 Therefore, do not install it outdoors in areas with salt damage. The areas with salt damage are defined as the areas which are not 500m away from shore or will be affected by sea breezes. The areas affected by SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
-
Page 14: Installation Space Requirements
5.4.1 Installation Location Selection Determine the installation position, put the installation auxiliary board in the proper position, and mark the place where the holes need to be punched. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com... - Page 15 Drill 6 holes according to the hole position, it is φ8 with depth of 45~50mm.Hammer the M8 screws to the above holes, and screw the nut. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
- Page 16 The battery pack is very heavy, which requires multiple people to install. CAUTION Keep the battery balanced, and then slowly hang the battery on the frame through the match hooks. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
-
Page 17: Electrical Connection
Cable between AC output and power Cable diameter Prepare by the user AC output line module 10mm /7AWG itself SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 17 of 29 F: +86 0755-27325578 W: www.srnesolar.com... -
Page 18: Connecting Grounding Wire
6.2.3 Connecting Signal Line The signal line shall be used to connect RS485 interface for battery module and inverter. The communication port of the SRNE brand inverter needs to be connected to the RS485-2 interface. Signal Cable SRNE Solar Co., Ltd. - Page 19 When connecting the inverter, the communication line must be connected and the communication protocol must be consistent. DANGER! The communication cable connected to the SRNE brand inverter is not a standard network cable. If you use a standard network cable, please cut off pins 1 and 2 for connection. NOTICE...
- Page 20 If there are multiple batteries, you need to connect the power cord of each battery. Parallel connection cable of battery modules are optional products. If necessary, please contact your local dealer. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
- Page 21 The address should be set as 1~4, and the address of each module cannot be repeated. The address of the battery connected to the inverter must be set as 1. NOTICE SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
-
Page 22: System Debugging
Secondly, turn on the battery switch button and the battery starts to work.If there are multiple modules, please turn on the power switch one by one according to the address sequence. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com... -
Page 23: System Status Indication
Steady Alarm Blinking1 Blinking3 Normal Alarm Blinking3 Charging Over Charge Protection High temperature, Over Current SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 23 of 29 F: +86 0755-27325578 W: www.srnesolar.com... -
Page 24: Capacity Indicator
Step 1 Turn off the breaker switch between the inverter and AC output (If installed). Step 2 Turn off the breaker switch between the inverter unit and AC input(If installed). SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com... -
Page 25: Routine Maintenance
Battery overcurrent protection Check whether there is a short circuit in the battery wiring. fault Check whether the load power exceeds the maximum SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 25 of 29 F: +86 0755-27325578 W: www.srnesolar.com... - Page 26 45% to 60% of the battery capacity and disconnect the battery output to avoid the battery runs out; 10. Do not touch the battery pack with wet hands. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
-
Page 27: Device Cleaning
The product shall not be cleaned with organic solvents, corrosive liquids and other cleaning products. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com... -
Page 28: Product Dimensions
The energy storage battery module and PCS module are packed in wooden cases with the size of 1,300*1,300*1,180, the number of packs is 16PCS, and the total weight is 900Kg. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com... - Page 29 Signal cable Standard Installation auxiliary board Standard Parallel Power Cable 2(option) option User Manual Standard SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 29 of 29 F: +86 0755-27325578 W: www.srnesolar.com...
