OPERATOR'S MANUAL
TURBO MILL FOR GREEN &
DRY MATERIAL
AGRICULTURAL MILL FOR
GREEN & DRY MATERIAL
With this practical mill you will be able to
grind green and dry corn canes as well as
corn grains "Produce the fodder for your
cattle by yourself".
MODELS
610205,
610355, 610305,
610375, 610385
Printed in Mexico
BN610205-0423NA
R00
Advertisement
Table of Contents
Summary of Contents for swissmex TURBO 610205
- Page 1 OPERATOR’S MANUAL TURBO MILL FOR GREEN & DRY MATERIAL 610205 610355 610305 (sin motor) AGRICULTURAL MILL FOR GREEN & DRY MATERIAL With this practical mill you will be able to grind green and dry corn canes as well as corn grains "Produce the fodder for your cattle by yourself".
-
Page 2: Safety Information
4.1 What to do before starting up the equipment INTRODUCTION Thank you for buying a Swissmex agricultural mill, we guarantee that the product you have purchased has unsurpassed quality since it was developed with state-of-the-art technology, following the required quality standards. -
Page 3: Safety Measures
2.2 SAFETY MEASURES Avoid accidents due to lack of knowledge and not following the safety rules described in this manual. Before putting your equipment into operation, read this instruction manual carefully. Incorrect handling by untrained persons can cause serious accidents. Do not make adaptations or improvisations;... -
Page 4: General Information
This information will be useful in case of processing a warranty or requiring spare parts. Write down the data of your equipment so you always have the information at hand. Calle Swissmex No. 500 Col. Las Ceibas 47440 Lagos de Moreno Jalisco 3.2 MAIN COMPONENTS... - Page 5 1. CHASSIS: made of structural iron coated with baked epoxy paint that protects it from corrosion. 2. SUPPORT LEG: keeps equipment stability as a foothold. 3. DISCHARGE OUTLET: allows the output of shredded fodder. 4. FEEDING PORTS: they are tilted so the material slides with the least operator’s effort. Each port measures 115 X 180 mm with safety gate (for model 610200 it is 110 X 80 mm).
-
Page 6: Technical Data
3 3 . TECHNICAL DATA These models are versatile and can be easily transported by their hitch point. SPECIFICATIONS DESCRIPCIÓN Artícle 610205 610305 610355 610375 610385 DESCRIPCIÓN Wheelbarrow Wheelbarrow Wheelbarrow Pull Type Trailer Pull Type Trailer Chassis Feeding 110 X 80 mm Doble boca de 115 x 180 mm con puertas de seguridad Output 130 X 195 mm... -
Page 7: Starting Procedure
These steps are for an engine such as the SWISSMEX one. In case you have purchased equipment without an engine and have installed one yourself, be sure to follow the steps mentioned in the NOTE: manufacturer's manual for that engine. -
Page 8: Maintenance
4. Grease the bearings after each working day. NOTE: We have repair and maintenance service for SWISSMEX equipment. Request it if you don't know how to do it, otherwise go to a professional. To ensure a better performance use NOTE: SWISSMEX-RAPID original spare parts. -
Page 9: Major Maintenance
5.2 MAJOR MAINTENANCE The equipment must be repaired by an expert mechanic when it presents a major fault. 5.3 MAINTENANCE SCHEDULE MAINTENANCE SCHEDULE ACTIVITY After first 25 hours. Change the engine oil. Daily. Clean the air filter. - Replace the air filter. - Change the engine oil. - Page 10 SPARE PARTS (model 610355, 610375) (model 610355, 610375) Model 610355 610375 MODELS 610305, 610355, 610375 y 610385 Wear parts and consumables always available Medium-wear Parts available at our discretion No. Code Quantity Qty. per Quantity Qty. per Description No. Code Description per unit package...
- Page 11 MODEL 610205 Wear parts and consumables always available. Medium-wear Parts available at our Quantity Qty. per Quantity Qty. per Código Description package Código per unit Description per unit package E2000610347 Counterpart E2888610555 Rowlock E2000610372 Rotor E2888610556 Iron pulley 2A87X1” E2888612002 Belt E2000610348 Tensor...
-
Page 12: Warranty Term
Any claim made under this warranty must adhere to the Warranty Policy described below: The warranty will be granted by SWISSMEX RAPID SA DE CV, free of charge, when the parts and compo- nents present manufacturing or assembly defects and after conclusive analysis in the plant (Lagos de Moreno, Jalisco).
