LIGMAN Mic 3 Installation And Service Manual

INSTALLATION AND SERVICE MANUAL
For Installation of Mic 3 medium indirect light column LED.
Model. MI-21071 and MI-21111
Product drawing (dimensions)
IP65 IK04 CLASS I
1,195
1,000
4,000
80
310
■ LIGMAN standard products are supplied with the control gear 220-240V 50/60Hz.
The control gear for other voltages and frequencies is available upon request, please consult us for more details.
■ LIGMAN luminaires are designed to conform IEC 60598 2-1 standard.
Technical amendments and modifications techniques reserved.
L i g m a n L i g h t i n g
Europe Headquarters
Ligman Europe s.r.o.
VGP Park Usti nad Labem, P 2
Prestanov 113
403 17 Prestanov
Czech Republic
Tel. +420 608 740 504 sales.cz@ligman.com
|
www.ligman.com
4,5
TOOL
963
Ø114x150
SPIGOT POST TOP
15
300
240
22
170
37
MOUNTING DETAIL
Weight : 33.9Kg.
Windage Area :0.67m².
Thailand Headquarters
Ligman Lighting Co., Ltd.
17/2 Moo 4, Monthong, Bangnampreaw
Chachoengsao 24150 Thailand
Tel : +66 (2) 7339140
info@ligman.com
Torque :4.5Nm.
Torque :2.0Nm.
M MI-21071/12/12/16/REV.2
1/2
1
Torque :2.0Nm.
4
L N
20 30
6
Torque :3.0Nm.
²
CABLE SIZE : 3x1.0mm
Ligman Ltd
Regus House, Victory Way
Crossways Business Park
Dartford DA2 6QD
Tel. 0800 975 0622
sales.uk@ligman.com
FM-TS-13-1/13-03-2561/REV.4
2
Torque :4.5Nm.
3
v+
v-
5
