TEKSENS THL1203-E Quick Start Manual

THL1203-E Submersible Level Transmitter
Features
■
Piezoresistive diffused
silicon pressure sensor
■
Probe insertion measurement
method, easy to install
■
For level measurement
■
Multiple protective structure
design, high protection ability
■
LCD option
■
Variety of styles, suitable for
various industrial applications
■
Anti-corrosion stainless steel
material adopted, suitable for
many occasions
Applications
■
Static pressure level
■
Liquid tanks
■
Sewage
■
Industrial water
■
Pools
■
Wells
■
Rivers
■
Seawater
■
Lakes
Notes:
1 Do not touch the diaphragm with
hard objects, which may cause damage
to the diaphragm.
2 Please read the Instruction Manual of
the product carefully before installation
and check the relevant information of
the product.
3 Strictly follow the wiring method for
wiring, otherwise it may cause product
damage or other potential faults.
4 Misuse of the product may cause
danger or personal injury.
Product overview
THL1203-E Submersible Level Transmitter accurately measures
static pressure of the liquid proportional to the level depth using
high performance piezoresistive diffused silicon pressure sensor as
the measuring element. The result is converted to standard current
or voltage signal output through signal conditioning circuit,
establishing the linear corresponding relation between the output
signal and liquid depth to complete the measurement of the liquid
depth. The product has advantages of high precision and small
volume. Submerse it directly into liquid, the height between the end
of the transmitter to the liquid surface is measured easily. The
product is applicable to the measurement and control of the liquid
level in the petroleum, chemical industry, power plant, urban water
supply and hydrological exploration fields.
THL1203-E has passed long-term aging and stability screening
with stable and reliable performance and can be used in harsh
outdoor environment. Meanwhile, it can display liquid level on site.
Zero shift and full scale span shift available.
Notes:
1 Do not misuse documentation.
2 The information presented in this product sheet is for reference only. Do
not use this document as a product installation guide.
3 Complete installation, operation, and maintenance information is provided
in the instructions of the product.
4 Misuse of the product may cause danger or personal injury.
