SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.

PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE

PELLET STOVE

Alliance

(EF3)

TECHNICAL MANUAL

PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE

OF THIS PELLET BURNING ROOM HEATER. FAILURE TO FOLLOW THESE

INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY

OR EVEN DEATH.

Contact your building or fire officials about restrictions and installation

inspection requirements in your area.

50-919

Table of Contents

Need help?

Do you have a question about the Enviro Alliance EF3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sherwood Industries Enviro Alliance EF3

Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE PELLET STOVE Alliance (EF3) TECHNICAL MANUAL PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
Page 2: Table Of Contents
Table of Contents Table of Contents......................2 Introduction......................3 Rating Label Location..................3 Important Safety Data..................3 Safety Warnings And Recommendations............3 Operating Instructions....................5 Thermostat Installed (Circuit Board Model Only)..........5 Optional Slider/Damper Installation..............6 Slider/Damper Operation................6 Deciding Where to Locate your Pellet Appliance..........7 Removing Your New Stove From the Pallet............7 Installation.......................8 Vent Termination Requirements...............8 Clearances to Combustibles................9...
Page 3: Introduction
Introduction atIng abeL ocatIon The rating label is located on the hopper lid. mportant afety TO PREVENT THE POSSIBILITY OF A FIRE, THIS APPLIANCE MUST BE PROPERLY INSTALLED BY FOLLOWING THE INSTALLATION INSTRUCTIONS. PLEASE READ THIS ENTIRE OWNER’S MANUAL BEFORE INSTALLING OR OPERATING YOUR ENVIRO PELLET STOVE.
Page 4 If you have any questions with regards to your stove or the above-mentioned information, please feel free to contact your local dealer for further clarification and comments. SINCE SHERWOOD INDUSTRIES LTD. HAS NO CONTROL OVER THE INSTALLATION OF YOUR STOVE, SHERWOOD INDUSTRIES LTD. GRANTS NO WARRANTY IMPLIED OR STATED FOR THE INSTALLATION OR MAINTENANCE OF YOUR STOVE.
Page 5: Operating Instructions
Operating Instructions hermoStat nStaLLeD IrcuIt oarD oDeL This control board can be placed into two different modes: When the jumper J2 is not jumped then the control board is in a HI / LOW mode operation. If the control board is placed with J2 jumped (factory setting) then the control board is in a ON / OFF mode of operation.
Page 6: Optional Slider/Damper Installation
Operating Instructions ptIonaL LIDer amper nStaLLatIon This is used to regulate the airflow through the pellet stove. 1. Remove the slider rod (short rod with knob and nuts) and the two nuts from their package and open the left side panel. 2.
Page 7: Deciding Where To Locate Your Pellet Appliance
Operating Instructions ecIDIng here to ocate your eLLet ppLIance 1. Check clearances to combustibles. 2. Do not obtain combustion air from an attic, garage or any unventilated space. Combustion air may be obtained from a ventilated crawlspace. 3. Do not install the stove in a bedroom. 4.
Page 8: Installation
Installation ermInatIon equIrementS 1. Do not terminate the vent in any enclosed or semi-enclosed areas such as a carport, garage, attic, crawlspace, narrow walkway, closely fenced area, under a sundeck or porch, or any location that can build up a concentration of fumes such as stairwells, covered breezeway, etc.
Page 9: Clearances To Combustibles
Installation LearanceS to ombuStIbLeS This unit can be installed on a combustible floor due to the built in pedestal hearth pad (for example linoleum, hardwood flooring). If combustible flooring is underneath the unit 6 inches (153 mm) on either side and to the front must be protected by non-combustible material. If this unit is to be installed onto a carpeted surface, a hearth pad must be used for stability.
Page 10: Exhaust And Fresh Air Intake Dimensions
Installation xhauSt anD reSh ntake ImenSIonS (A) EXHAUST. Base to center of flue 20 ⅜ inches (51.75 cm) Side to center of flue 6 ½ inches (16.51 cm) (B) FRESH AIR INTAKE. Base to center of intake 14 ⅝ inches (37.15 cm) Side to center of intake 11 ¼...
Page 11: Horizontal Through Wall Installation
Installation orIzontaL hrough nStaLLatIon The ENVIRO Alliance (EF3) can be vented by a couple of different methods. 1. NOTE: Use only listed type “PL” or “L” pellet venting products. Failure to use listed components may cause damage or personal injury or death. 2.
Page 12: Through Wall Installation
Installation hrough nStaLLatIon...
Page 13: Freestanding Inside Vertical Installation
Installation reeStanDIng nSIDe ertIcaL nStaLLatIon Choose a stove location that is ideal. See the section Deciding Where to Locate Your Pellet Appliance. Place a non-combustible hearth pad where necessary. Place the unit on the hearth pad and space it in a manner so when the pellet vent is installed vertically, it will be 3”...
Page 14: Freestanding Outside Vertical Installation
Installation reeStanDIng utSIDe ertIcaL nStaLLatIon To accomplish a freestanding outside vertical installation, follow steps 1 through 9 in the Freestanding Inside Vertical Installation section and then finish it by performing the following. Install a tee with clean out on the outside of the house. Install PL vent upward from the tee.
Page 15: Mobile Home Installation
Installation obILe nStaLLatIon •Secure the heater to the floor using the two bolt holes supplied in the pedestal. CAUTION: THE STUCTURAL INTEGRITY OF THE MANUFACTURED HOME FLOOR, WALL, AND CEILING/ROOF MUST BE MAINTAINED. •Ensure the unit is electrically grounded to the chassis of your home (permanently). •Do not install in a room where people sleep.
Page 16: Troubleshooting
Troubleshooting This toubleshooting is for both Timer Control and Circuit Board style Alliance. It will be stated if the troubleshooting relates only to one model. DO NOT: Hold the ON / OFF BUTTON down for circuit board model or hold the start-up switch down for timer control.
Page 17 Troubleshooting  If the unit still does not start, contact your local service dealer for service. 2. The stove will not operate when hot. General  Check the hopper for fuel.  Incorrect air damper setting - Excessive air may consume the fire too quickly before the next drop of fuel, leaving completely unburned fuel in the burn pot liner.
Page 18 Troubleshooting  If the convection motor will not run, apply 220 V to the motor directly. If the motor runs, replace the fan controller. If the motor does not run, the convection blower has failed. Replace the blower. If the convection blower runs on high at all times (no control with the fan controller), check the ...
Page 19 Troubleshooting If the auger still does not work, then apply 220 V directly to the auger motor. If the auger motor  does not work, replace it. By-pass the 200°F (93°C) temperature sensor with a jumper wire; check the auger. If the auger ...
Page 20 Troubleshooting Circuit Board  If the unit will not shut off, ensure that the thermostat (if equipped) is turned down below the room temperature (thermostat mode in the ON / OFF position).  If the unit is in the HI/LOW mode the unit will not shut off but will go to an idle setting (LOW). Press the ON/OFF button to turn the unit off.
Page 21: Wiring Diagram
Wiring Diagram Imer ontroL...
Page 22: Circuit Board
Wiring Diagram IrcuIt oarD...
Page 23: Parts List
Parts List Part Description Part Description Number Number EF-001-220V 220 Volt Auger Motor EF-068 Heat Exchanger Knob EF-069 Auger Collar Screw Set EF-002-220V 220 Volt Convection Blower EF-068 Slider Damper Knob 20-036 Log Set EF-004 220 Volt Convection Blower Impeller EF-092 EF3Bi Gold Door Complete EF-094...
Page 24: Parts Diagram - Components
Parts Diagram - Components...
Page 25: Parts Diagram - Steel
Parts Diagram - Steel...
Page 26: Warranty
Warranty Sherwood Industries Ltd. gives a five-year limited warranty on all steel manufactured parts. A one-year warranty is provided on all electrical components. The above limited warranties are extended only to the original purchaser. There is no warranty on the following parts: ●...
Page 27: Installation Data Sheet
SERIAL NUMBER:___________________________ _________________________________________ DATE OF PURCHASE: _____________ (dd/mm/yyyy) DATE OF INSTALLATION:___________ ADDRESS: (dd/mm/yyyy) MAGNEHELIC AT INSTALL:___________________ _________________________________________ INSTALLER’S SIGNATURE: _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.envirofire.biz August 13, 2003 C-10071...
