RP902 MFi
Bluetooth UHF Pocket Reader
Quick Start Guide
Differentiate RP902/RP902 MFi (Continued)
Product Label Color
RP902 Standard
• White
Operating Mode in the Setting Page
RP902 Standard
• Supports "USB SPP, BT SPP, BT HID, Buffer & BLE HID"
RP902 MFi
• Only supports "USB SPP, BT SPP & Buffer"
Bluetooth Name Format on the Host Device
(During Bluetooth Pairing)
RP902 Standard
• RP902_XXXX
V1.2
RP902 MFi
• Yellow
RP902 MFi
• RP902_i_XXXX
Differentiate RP902/RP902 MFi
There are five ways to differentiate between
RP902 Standard Version and RP902 MFi Version:
Gift Box Outlook
RP902 MFi version will have the MFi mark on
the gift box (please refer to the picture below).
P/N on the Product Label
(in the battery compartment)
RP902 Standard
• RP902-33E8S0G
• RP902-43A8S0G
• RP902-43F8S0G
Package
Please make sure the following contents are in
the RP902 MFi gift box. If something is missing
or damaged, please contact your Unitech
representative.
The Package Contents
• RP902 MFi Terminal
• Battery (PN#1400-900066G)
• USB Type-C Cable (PN#1550-905908G)
Optional Accessories
• One-Slot Charging Cradle
(PN#5000-900096G)
• Wrist Lanyard (PN#5500-900007G)
• Neck Lanyard (PN#3210-900019G)
• Power Supply (PN#1010-900067G)
• RFID tags/labels
RP902 MFi
• RP902-33EMS0G
• RP902-43AMS0G
• RP902-43FMS0G
Advertisement
Table of Contents
Related Manuals for Unitech RP902 MFi
Summary of Contents for Unitech RP902 MFi
- Page 1 There are five ways to differentiate between RP902 Standard Version and RP902 MFi Version: RP902 MFi Gift Box Outlook RP902 MFi version will have the MFi mark on Bluetooth UHF Pocket Reader the gift box (please refer to the picture below). P/N on the Product Label...
-
Page 2: Product View
Product View Install the Battery 1. Turn the terminal to its rear side, and push the battery lock to the right to unlock the battery. 2. Grab two protrusions on both sides of the battery cover, and lift upward to remove it. 1. -
Page 3: Specifications
Enable Turning on RP902 MFi for the first time Auto Power-off 2 min 1. Short press the power/trigger key to power on RP902 MFi. Note: LED Indication Power on RP902 MFi for the first time, the communication LED will show green flash first then “flashing blue light” to... -
Page 4: Power Up/ Shut Down
1-3/5/10 min (*2 min) Information MAC Address Factory Default Enable/Disable SKU ID Temperature Note: For more details, please refer to RP902 MFi User’s Manual which can be download through Note: SKU ID: 1 = EU, 2 = US, 3 = JP https://www.ute.com/en/products/detail/RP902MFi... -
Page 5: Operating Mode
Long press (about 3 - 5 secs.) the two buttons at the and environmental conditions. bottom of RP902 MFi at the same time to release the BT Reading range is 1m when power is 22dBm, and the connection between the host device and RP902 MFi. -
Page 6: Remove The Battery
If the connector is damaged, please ensure the connector is fully repaired before using the unit to avoid short circuiting. 3. Pull the battery strap upward to remove. http://www.ute.com/ Copyright 2023 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
