  • Page 1 Product Instruction Manual System Monitoring Terminal AP-KS9302 Shangh ai Anping Static Technology Co., Ltd. Website : www.ap-static.com Address : 3/F,Building 27,No.69,Guiqing Road,Shanghai,China Tel : +86-21-64517676 Fax : +86-21-64517673...
  • Page 2: Product Description

    Product Description AP-KS9302 system monitoring terminal is the monitoring display of the static electricity monitoring and elimination system produced by Anping Company (AP&T) which is used to monitor the working status of pulsed DC ionizing blowers, pulsed AC ionizing bars, and electrostatic sensors.
  • Page 3: Function Introduction

    Function introduction Function diagram M4 mounting hole Temperature and humidity detection window 2.4G communication antenna Wireless connection Temperature and humidity display Electrostatic eliminator running time setting IMS Smart Controller NEXT NEXT Electrostatic sensor monitoring settings Electrostatic eliminator monitoring settings Work/Link: SCAN SCROLL LINK...
  • Page 4 Function description table Antenna(2.4G) Temperature and humidity sensor Four electrostatic sensors P1-P4 Two electrostatic sensors, two electrostatic eliminators Short press - select product (an electrostatic sensor that must be linked) NEXT NEXT Product - Electrostatic Sensor Long press - search for products SCAN SCAN Short press - select time(10S、20s、30S、60S、90S、120S、360S)...
  • Page 5 Installation Guide • Search equipment Long press the SCAN button to search for equipments after turning on the power, and the online connected equipments will be displayed after 10S. Connect two electrostatic sensors and two power elimination equipments as shown in the figure below and press to display (Sensor-001/Sensor-003/ Bar-001/Blower-001).
  • Page 6: Maintenance

    Dimensions IMS Smart Controller NEXT NEXT SCAN SCROLL LINK Wrok/Link Red-V ACT/Clean-Green P1-P4 : 1/2-VCC 3-RS485_B 4-RS485_A 5/6-GND 7-C_V 8-C_ACT/Clean 9-PE(Metal shield) WAN/LAN POWER 87.5 Maintenance It should be stopped and repaired by professional maintenance personnel if the display or working status indicator on the panel is off when the system monitoring terminal is confirmed to be connected to the equipment correctly and the power supply is normal.
