Suntronic GSCAT5-AV User Manual

Features:

Through the VGA Extender, you can use one PC
to display identical image and extension of VGA
signal up to 180/300 meter on monitors.
Equalization length is adjustable.
VGA signal gain is adjustable.

Package Contents:

VGA-L+-PRO Local Unit
VGA-R-PRO Remote Unit
1 user manual
2 power adapter DC 12V/600mA
1 VGA 1.2M cable (HD-15 Male to Male)

Specifications:

Function
VGA In Connector
VGA Out Connector
RJ-45 Connector
Max. Resolution
Cable Distance
Power Adapter (Min.)
Housing
Weight
Dimensions (LxWxH) mm
GSCAT5-AV
HD-15 Female x 1
HD-15 Female x 1
1
1920x1440 60Hz
300 m (Max.)
DC 12V 600mA
Metal
290g
118x75x29
EMAIL: sales@suntroniclcd.com WEB: www.SuntronicLCD.com
•
