- Page 1 ECX332 Multimodal Face Recognition All-in-one Terminal Quick Start Guide v1.0...
- Page 2 With our unremitting efforts, we contribute to opening a wonderful and infinite life experience for all ECX332 users. We always strive to provide you with intimate and comfortable experience in all-round way, from products to services.
-
Page 3: Getting Started
1. Getting Started 1.1 Registration Instruction When using multimodal face recognition terminal, please follow the steps below for operation involving registration or identification: (1) Stand in front of the multimodal face recognition terminal, and look at the screen of the terminal; (2) Make sure the eyes are within the preview box at the top of the screen. - Page 4 User’s Manual for ECX332 Multimodal Face Recognition All- in-one Terminal Local: the data can be saved locally without need to connect to network. Click Skip in the upper right corner of the page (as shown in Fig. 2) to enter the local version.
- Page 5 User’s Manual for ECX332 Multimodal Face Recognition All- in-one Terminal Fig. 5 Step 1: Click "Skip" to enter the local version and select the date and time. (As shown in Fig. 3) Step 2: Set the door opening password and administrator password: enter and confirm the new password, and click "Confirm".
-
Page 6: Add Users
User’s Manual for ECX332 Multimodal Face Recognition All- in-one Terminal Set door opening password and administrator password Please enter a new password Please confirm password Confirm Fig. 8 Fig. 9 Step 1: Select wired network, open Ethernet, insert the network cable, and connect the wired network (as shown in Fig. - Page 7 User’s Manual for ECX332 Multimodal Face Recognition All- in-one Terminal Administrator Enter name Enter phone number M1 card No. Next step Fig. 12 Fig. 13 (1) Enter the setting interface: Swipe the screen upward in the main identification interface, and the screen shows the input button of...
- Page 8 User’s Manual for ECX332 Multimodal Face Recognition All- in-one Terminal the identification box at an distance about 55mm. The door opens when the legal face and iris are captured and identified. 3.2 Door Opening by Password Get close to multimodal face recognition terminal,...
-
Page 9: Basic Setting
User’s Manual for ECX332 Multimodal Face Recognition All- in-one Terminal 4.2 Basic Setting Basic setting Language Language setting 中文 Time setting English Wifi setting Ethernet setting Fig. 15 Fig. 16 Date and time WLAN Automatically confirm time Eyecool and date... -
Page 10: Password Management
User’s Manual for ECX332 Multimodal Face Recognition All- in-one Terminal Fig. 18), Ethernet (as shown in Fig. 19) in basic setting (as shown in Fig. 15). 4.3 Logging Logging Identification log Operation log Warning log Fig. 20 You can view the identification log, operation log and warning log in logging. - Page 11 User’s Manual for ECX332 Multimodal Face Recognition All- in-one Terminal opening password and administrator password. (As shown in Fig. 21) 4.5 Comparison Mode Setting Comparison mode setting Confirm Device comparison mode Local comparison Network comparison Local + network comparison Feature comparison mode...
-
Page 12: Parameter Setting
User’s Manual for ECX332 Multimodal Face Recognition All- in-one Terminal 4.6 Parameter Setting Parameter setting Confirm User synchronization Rotation calibration Opening time Light brightness Anti-disassembly warning switch Card swiping switch Iris reality switch Domain name setting Network certificate setting Fig. 23... - Page 13 User’s Manual for ECX332 Multimodal Face Recognition All- in-one Terminal Restore factory setting? Cancel Confirm Fig. 24 Click to restore factory setting, and a prompt will pop up to confirm whether to restore factory settings. Click "Confirm", and the system will restore to the factory setting. (As shown in Fig.
-
Page 14: Warranty Card
5. Warranty Card Warranty Card Dear customer, thank you for purchasing Eyecool products. In order to offer you with better service, please carefully read, fill in and properly keep this warranty card after purchasing. Customer name Customer address Product name... - Page 15 ●Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications made to this device not expressly approved by Beijing Eyecool Technology Co., Ltd. may void the FCC authorization to operate this device. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment.
- Page 16 This equipment should be installed and operated with a Minimum distance of 20cm between the radiator and any part of your body. Tel: 010-59713131 Fax: 010-59713031 Email: 6s@eyecool.cn Address: 8F, Building 1, Brilliant International, Shangdi 10 Street, Haidian District, Beijing www.eyecool.cn...
