u n e p a s s i o n , l e b o i s
ASSEMBLY
NOTICE
Notice de montage
Montage handleiding
Montageleitung
Manuale d'instruzione
Instrucciones de montaje
Instruções de montagem
Pergola
WARRANTY NUMBER
3×4m
ref 30175-T00
A _ _ _ _ - _ _ _ _
Made in Belgium
www.decoretjardin.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Décor et Jardin 30175-T00
Summary of Contents for Décor et Jardin 30175-T00
- Page 1 , l e b o i s ASSEMBLY NOTICE Notice de montage Montage handleiding Montageleitung Manuale d’instruzione Instrucciones de montaje Instruções de montagem Pergola WARRANTY NUMBER 3×4m ref 30175-T00 A _ _ _ _ - _ _ _ _ Made in Belgium www.decoretjardin.com...
- Page 2 Pergola 3×4m 30175-T00 3000 4000 2580 3580 2760 3760 ×4 (EN) not inclued (FR) non inclus (NL) niet inbegrepen (DE) nicht einbegriffen (IT) non incluso (ES) non incluida (PT) non incluido Laying on concrete slabs (not included) (EN) Pose sur dalle béton (non incluse)
- Page 3 Pergola 3×4m 30175-T00 502805X : ×7 30×70/3000mm 502806X : ×2 40×90/4000mm 502802X : ×4 29×59/390mm 502807X : ×4 90×90/2400mm 502805X : × 7 502802X : × 4 502806X : × 2 3000mm 390mm 4000mm × × × 502807X : × 4 2400mm ×...
- Page 4 Pergola 3×4m 30175-T00 502806X 120mm 120mm 502807X 3045 : ×4 ø5×80 ø5mm 502802X ø4mm 3027 : ×2 ø4×60 3045 : ×1 ø5×80 ø5mm ×2 ×2 502805X 3027 : ×1 ø4×60 ø4mm ×14 Assembly notice - keep for later reference. (EN) Notice de montage à...
