Rotasoc
16A infeed and UK sockets shown for illustration purposes.
Coloured busbar shields
Standard Earth
White
White
Red
When connecting modules together, ensure that the coloured busbar shields
are colour matched and correctly aligned. Do not connect modules if shields
are of different colours.

Connecting modules

On the rear face, release
Connect the male and
the lever with a small
female ends together.
screw driver.
Both ends must be
colour matched.

Mounting to a surface

Flip up the rubber screw
Insert a No.8 pozi-pan
covers with a suitable
screw or M4 bolt of the
tool.
required length into the
hole and tighten.
Part No: 134264 Issue No: 001
Clean Earth
Dual Circuit
Red
Red
Once connected, push
back the lever so it sits
flush with the surface to
lock modules together.
Once the module is
secured to the surface
push down the rubber
screw caps to finish.

Rotating the sockets

The power sockets can be freely rotated by hand in both clockwise and anti-
clockwise directions.

Replacing fuse - infeed

Isolate power then pull
up the fuse carrier with
the tabs on either side
of it.

Replacing fuse - circuit protection module

White
Isolate power and with
a suitable tool turn anti-
clockwise to release the
fuse carrier.

Replacing fuse - fused socket

1/4
turn
Isolate power then 1/4
turn the fuse carrier
anti-clockwise with a
suitable tool.
Resetting the RCD/RCBO
Open the spring loaded
cover to access RCD.
Support the cover as it
opens.
Installation, user and care guide
Remove the fuse.
Push down the fuse
Replace with fuse type
carrier until closed.
ceramic IEC 60127-2
(10A max).
Remove fuse carrier and
Re insert the carrier and
fuse. Replace with fuse
lock in place by turning
type BS1362. (13A max).
clockwise.
1/4
turn
Lift carrier and remove
Re insert the carrier and
fuse. Replace with fuse
lock in place with a 1/4
type ceramic IEC 60127-
clockwise turn using the
2 (5A max).
screw driver.
(if applicable)
TEST
Push trip to 'off' position
Close the spring loaded
then to 'on' to reset
cover to protect the
RCD.
RCD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rotasoc and is the answer not in the manual?

Questions and answers

Summary of Contents for CMD Rotasoc

  • Page 1 Rotasoc Installation, user and care guide Rotating the sockets The power sockets can be freely rotated by hand in both clockwise and anti- clockwise directions. Replacing fuse - infeed Isolate power then pull Remove the fuse. Push down the fuse...
  • Page 2 • Fuse replacement only to be carried out by a skilled or competent person. • Should the supply cable need replacing, contact CMD. Product care • Clean using a dry cloth. No abrasives or solvents to be used on the product.
