Techly IDATA HDMI2-RIP4KT Manual

EN
Dear Customer,
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating
or adjusting this product. Please keep this manual for future reference.
IMPORTANT SAFETY INSTRUCTION
INTENDED USE
We do not permit using the device in other ways like
described in this user's manual. Use the product only
in dry interior rooms. Not attending to these
regulations and safety instruction might cause fatal
accidents, injuries, and damages to persons and property. The
manufacturer/supplier assumes no liability for damages caused by
failure to comply with the intended use.
C A U T I O N
RISK OF ELECTRIC SHOCK
DO NOT OPEN
service is required. Disconnect the product from mains and other
equipment if a problem should occur. Do not expose the product
to water or moisture.
• Your product is not a toy and is not meant for children, because it contains
small parts which can be swallowed and can injure when used
inappropriately!
• Please install the system and devices attached to it in a way that persons
cannot be injured, or objects not be damaged for example by dropping
or stumbling.
• Please remove the packing materials, because children may cut
themselves on them while playing. Furthermore, there is a risk
of swallowing and inhalation of incidentals and insulating material.
• Avoid places with high temperatures, or humidity, or places which might
come into contact with water. Do not install the product close to openings
of air conditioners, or at places with an excessive amount of dust
or smoke. Keeps distance from flammable and explosive devices
• Do not install the product at places subject to vibration, or oscillation
• Do not modify and alter the product and any accessories!
Do not use any damaged parts.
• Keep enough space around all devices for a good ventilation
and free motion and to avoid damages.
• Do not plug-in/out the cables when it is in using.
INTRODUCTION
This HDMI Repeater can realize signal enhancement by signal equalization and
reorganization so that the signal transmission can reach longer distance. This
HDMI Repeater can support maximum resolution up to 3840 x 2160 / 60 Hz.
FEATURES
1. Supports HDMI 4K 60Hz
2. Supports 3D video format
3. Supports high resolution up to: 3840 x 2160 / 60Hz
4. Supports highest rate of 18G and TMDS clock can be up to 600 MHz
5. Supports 8/10/12/16 bit deep color
6. Using standard AWG26 cable, the input transmission distance can reach
40m (3840 x 2160 / 30Hz)
PACKAGE CONTENTS
HDMI Repeater 4K@60Hz * 1
User manual * 1
To reduce risk of electric
shock, this product should
ONLY be opened by an
authorized technician when
CONNECTION AND OPERATION
1. Connect the HDMI signal source and the input port of the repeater through
one HDMI cable
2. Connect the repeater output to the display device through HDMI cable
Attention: Insert / Extract cable gently!
SPECIFICATION
HDMI resolution Up to 3840*2160/60Hz
Support video format 8/10/12/16 bit Deep Color
Support audio format DTS HD/Dolby-trueHD/DTS/Dolby-AC3 / DSD
Maximum bandwidth 600 MHz
Max baud rate 3 x 6 Gbps
Input 5m, output 5 m (4K@60Hz), input 20m,
Input cable distance
output 20m (4K@30Hz/1080p)
Maximum working current 300 mA
Working temperature -15°C to 55°C
Operating humidity range 5% to 90% RH (no condensation)
Dimension (L x W x H) 51 x 28 x 13 mm
Weight 25 g
Maintenance: clean only with a dry cloth. Do not use cleaning solvents
or abrasives.
Warranty: no guarantee or liability can be accepted for any changes and
modifications of the product or damage caused due to incorrect use of this
product.
In compliance with EU Directive WEEE this product is marked with this
symbol. It means that used electrical and electronic products should not be
mixed with general household waste.
There is a separate collections system for these products in compliance with
WEEE directive, otherwise contaminative and hazardous substances can
pollute the environment.
With the CE sign, Techly ® ensures that the product is conformed to the basic
European standards and directives.
WWW.TECHLY.COM
HDMI REPEATER 4K@60HZ
