Tel+AM_MD40920_UK.fm Seite 2 Mittwoch, 7. April 2004 9:52 09
1
LINE:
Socket for telephone cable
2
DC 9 Volt:
Socket for AC adaptor
3
HI-LO:
Volume for ringing sound
4
Volume Control: Volume for messages on answering machine
5
RING
and count backward
6
CODE
and count forward
7
Display for answering machine
8
ON/OFF:
Switch answering machine on and off
9
MEMO:
Record and play memos
10 OGM1:
Out-going message type 1
11 OGM2:
Out-going message type 2
12 2 WAY:
Record the current conversation
13 SPEAK:
On: OGM's and ICM's are heard / OFF: Mute OGM's and ICM's
14 STOP/TIMER
15
/II
Play and pause
16 DEL:
Delete
17 MEM:
Press for indirect memory (before pressing numeric key)
18 STORE:
Store
19 PAUSE:
Pause
20 FLASH:
Call waiting function (depending on telephone provider)
21 REDIAL:
Repeat last entered telephone number
22 H/F:
"Hands free" key
23 Number keys
24 Loudspeaker
25 M1, M2, M3: Direct memory
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD40920 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Medion MD40920

  • Page 1 Tel+AM_MD40920_UK.fm Seite 2 Mittwoch, 7. April 2004 9:52 09 LINE: Socket for telephone cable DC 9 Volt: Socket for AC adaptor HI-LO: Volume for ringing sound Volume Control: Volume for messages on answering machine RING and count backward CODE and count forward Display for answering machine ON/OFF: Switch answering machine on and off...

  • Page 2: Table Of Contents

    Tel+AM_MD40920_UK.fm Seite 3 Mittwoch, 7. April 2004 9:52 09 ABLE OF ONTENTS Safety Instructions ....... . 4 Installation .

  • Page 3: Safety Instructions

    Tel+AM_MD40920_UK.fm Seite 4 Mittwoch, 7. April 2004 9:52 09 AFETY NSTRUCTIONS About this manual Please observe the following safety instructions carefully be- fore putting the unit into operation. Take note of the warnings in this manual. Always keep the instruction manual near at hand. If you sell or pass on the product, make sure to include this manual together with the unit.

  • Page 4: Installation

    Tel+AM_MD40920_UK.fm Seite 5 Mittwoch, 7. April 2004 9:52 09 NSTALLATION Inserting the back-up batteries You can insert 4 LR-06 (SUM4, AAA) batteries as back-up batteries. They are only needed if you want to save the memory when you unplug the device: a.

  • Page 5: Telephone Operation

    Tel+AM_MD40920_UK.fm Seite 6 Mittwoch, 7. April 2004 9:52 09 ELEPHONE PERATION Making phone calls To answer the phone, pick up the handset or press the H/F button. To make a phone call, pick up the handset or press the H/F button and listen for a dial tone.
  • Page 6 Tel+AM_MD40920_UK.fm Seite 7 Mittwoch, 7. April 2004 9:52 09 ELEPHONE PERATION Please note that this function must be supported by the caller’s tele- phone company. To turn the bleeping tone off or on, press FLASH. Setting Ringing Volume Set the ring switch to the HI (High) or LO (Low) position to adjust the vo- lume of the ringing tone.

  • Page 7: Operation Of Answering Machine

    Tel+AM_MD40920_UK.fm Seite 8 Mittwoch, 7. April 2004 9:52 09 PERATION OF NSWERING ACHINE Setting the clock Press and hold the STOP/TIMER button for 2 seconds. The 2-digit display shows the current day. 7 for Sunday, 1 for Monday and 2 for Tuesday etc. Press the CODE or RING button to adjust the day.
  • Page 8 Tel+AM_MD40920_UK.fm Seite 9 Mittwoch, 7. April 2004 9:52 09 PERATION OF NSWERING ACHINE To record a new outgoing message, please repeat these steps. Recording OGM2 To record this message, proceed as described in the passage „Recording OGM1“, however, use the OGM2 button. (Make sure to add in you OGM that the caller cannot leave a message.) The maximum recording time of an incoming message is 90 seconds.

  • Page 9: Setting The Unit To Answering Mode Answer/Record Mode

    Tel+AM_MD40920_UK.fm Seite 10 Mittwoch, 7. April 2004 9:52 09 PERATION OF NSWERING ACHINE Setting the unit to answering mode ANSWER/RECORD MODE Answer/Record mode In the Answer/Record mode, the unit will play the OGM1 and then record a message. Make sure the OGM1 is recorded. Press the ON/OFF button once; the unit will emit 2 short beeps and then play OGM1.

  • Page 10: Recording A Personal Memo

    Tel+AM_MD40920_UK.fm Seite 11 Mittwoch, 7. April 2004 9:52 09 PERATION OF NSWERING ACHINE 4: Unit set to answer after 4 rings t : Unit set to toll-saver mode. Press the RING button and/or CODE button to change the ring setting. When the desired ring setting appears, press the STOP/TIMER button.

  • Page 11: Deleting Incoming Messages Or Personal Memos

    Tel+AM_MD40920_UK.fm Seite 12 Mittwoch, 7. April 2004 9:52 09 PERATION OF NSWERING ACHINE The maximum recording time for an ICM (Incoming Message) is 90 seconds. If the memory is full, the unit will change to Answer-only mode, play OGM2 and not allow a message to be recorded. Deleting incoming messages or personal memos To erase a single message while playing it back, press the DEL button and the unit will delete the current message and play the next message.

  • Page 12: Remote Function

    Tel+AM_MD40920_UK.fm Seite 13 Mittwoch, 7. April 2004 9:52 09 EMOTE FUNCTION This answering machine in this unit can be operated from almost any touch- tone phone. Changing the security code The Security Code is preset to "19". You can operate the unit remotely with this code, but we suggest you set your own new code.

  • Page 13: Playing Incoming Messages (Icm's)

    Tel+AM_MD40920_UK.fm Seite 14 Mittwoch, 7. April 2004 9:52 09 EMOTE FUNCTION When finished, press the "9" pad and then the new OGM1 will play back. If satisfied, press the "?" pad to end the call or repeat this step to record a new OGM1 again.

  • Page 14: Selecting The Answer Mode

    Tel+AM_MD40920_UK.fm Seite 15 Mittwoch, 7. April 2004 9:52 09 LEANING THE UNIT Press "7" and the unit will monitor the situation for 90 seconds, beep and then stop, if you want to continue monitoring, immediately press "7" again. To stop monitoring, press "9". Selecting the answer mode Call the answering machine from a separate line.

  • Page 15: Technical Data

    Tel+AM_MD40920_UK.fm Seite 16 Mittwoch, 7. April 2004 9:52 09 ECHNICAL Power supply: 230 V ~ 50 Hz Back-up batteries: 4 x LR-06 (SUM4, AAA) CONFORMITY INFORMATION This phone is tested for an opreation with analogue telephone networks and complies with the European directive for radio systems and telecommunica- tion facilities - R&TTE 1999/5/EG.

  • Page 16: Remote Access Code Card

    Tel+AM_MD40920_UK.fm Seite 17 Mittwoch, 7. April 2004 9:52 09 REMOTE ACCESS CODE CARD Cut out this card and keep it in your wallet as a reference guide when remotely calling. Your personal access code: _________ Play OGM1 Play OGM2 #+1 Record OGM1 #+2 Record OGM2 #+3 Record MEMO Repeat current Message...
