SKY-HERO SIGYN Mk I Quick Start Manual

QUICK S T ART GUIDE
An operator friendly robot that provides teams
with superior scouting through two ultra-sensitive
Day-Night cameras. While 150-degree views allow
for an impressive scope, dimmable IR LEDs on the
front, back, and top of the vehicle provide video
clarity and NVG lighting.
2
1
FRONT MASK
3
4
5
UPPER FRAME
|
S YS TEM COMPONENTS
Camera
1
Front IR LEDs
2
Upper IR (L/R) and status LEDs
3
Binding button
4
with rubber cap
Payload connector
5
with rubber cap
Lower IR LEDs
6
ON/OFF Button
7
Battery cover
8
Sigyn MkI related elements
8
7
6
LOWER FRAME
SIG YN
T actical Ground Robot
A small remote ground controller with highly
intuitive cybersecure interface that simultaneously
handles the control and monitoring of multiple
unmanned vehicles, including the operation of
their sensors and plug-in payloads* (*in option).
2
6
4
1
FRONT MASK
7
UPPER BUTTONS
9 10 11
LOWER PORTS
ON/OFF Button
1
Left Joystick/J1
3
2
Right Joystick/J2
3
Device buttons
4
Action buttons
5
5
Display Screen
6
Action button Left
7
Action button Right
8
Push-to-Talk Port
8 9
Headphone Port
10
Audio/Video ouptut Port
11
Micro SD Card Slot
12
USB-C Port
13
LED Charging indicator
14
GCS MkII related elements
This Quick Start Guide is not
a substitute for reading the
operator's manual. To reduce the
risk of injury or device misuse,
14
user must read and understand
operator's manual before using
12 13
these products.
