MS3C-300TWC

Battery Operated Stair Climbing Trolley for Wheelchairs

Deploying Wheelchair Stair Chair:

1. To unfold chair, grasp backrest with one hand

and grasp the seat with other hand. Slowly

guide chair into a fully open position.

2. Chair will automatically lock when it reaches

its fully open position. You may now roll chair.

1. Align battery power along battery support

rail located on the back of chair.

2. Slide battery into place.

3. Lock battery onto rail by turning locking key.

4. Chair is now ready for use.

IMPORTANT: Follow all local safety protocols

1. Position wheelchair in front of trolleys red wheel supports to

have a visual reference of the distance needed between the

supports

2. Pull red knob out and up to release locking mechanism on

trolleys wheel supports

3. Slide the red wheel supports in or out to the distance

necessary to allow for wheelchairs wheels to slide onto locking

wheel supports.

User Manual

toll free: 1-877-706-4480

international/local: 713-706-4480

fax: 713-706-4161

www.MS3C.co

Table of Contents

Do you have a question about the MS3C-300 and is the answer not in the manual?

Page 1 1-877-706-4480 international/local: 713-706-4480 fax: 713-706-4161 www.MS3C.co MS3C-300TWC Battery Operated Stair Climbing Trolley for Wheelchairs User Manual Deploying Wheelchair Stair Chair: 1. To unfold chair, grasp backrest with one hand and grasp the seat with other hand. Slowly guide chair into a fully open position.
Page 2 1-877-706-4480 international/local: 713-706-4480 fax: 713-706-4161 www.MS3C.co Note: Adjust wheelchair so that it is centered on the trolley before locking the wheel support knob. Wheelchair should be all the way back, with trolley frame centered between the wheelchair push handles.
Page 3 1-877-706-4480 international/local: 713-706-4480 fax: 713-706-4161 www.MS3C.co 1. Operator will roll the evacuation chair to top of the staircase. 2. Turn on battery with red button located on the bottom of the battery pack. 3. Operator will LOCK rear casters.
Page 4 1-877-706-4480 international/local: 713-706-4480 fax: 713-706-4161 www.MS3C.co position making sure front wheels are securely placed on ground. 7. Operator will then disengage track by pushing red release bar located on the back of chair and pushing in. Make sure track is in closed locked position.
