U.S. Patent No's. 5,755,099 • 5,946,912
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
adveRTenCIa
!
• Leer, comprender, y seguir las instrucciónes antes
de utilizar el aparato.
• El manual de instrucciónes y la información de
seguridad deben estar comunicado en lengua del
operador antes del uso.
• No seguir estas indicaciónes puede causar daños
personales o materiales.
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
Owner's Manual
Model
SJ-3PTL
Pump to Load
Service Jack
Capacity
3 Ton
WARNING
!
To avoid crushing and related injuries:
• neveR work on, under or around
a load supported only by a hydraulic
jack.
• aLWaYS use adequately rated jack
stands.
Printed in China
SJ-3PTL-M0 rev 10/08
Advertisement
Table of Contents
Related Manuals for JohnDow Industries SJ-3PTL
Summary of Contents for JohnDow Industries SJ-3PTL
- Page 1 • aLWaYS use adequately rated jack • No seguir estas indicaciónes puede causar daños stands. personales o materiales. Read this manual and follow all the Safety Rules and Operating Instructions before using this product. Printed in China SJ-3PTL-M0 rev 10/08...
- Page 2 NEVER place any portion of your body beneath the vehicle when lifting OR lowering! SPeCIFICaTIOnS Model Capacity Jack Size (L x W x H) Min. Height Max. Height Saddle Dia. SJ-3PTL 3 Ton 27-1/2" x 13-3/8" x 6-3/8" 5-3/4" 20" 5-1/2"...
- Page 3 Pump 6 to 8 full strokes. This will help release any pressurized air which may be trapped within the reservoir. Reinstall the oil filler plug. Handle Saddle Lifting Arm Front Wheel Handle Sleeve Oil Filler Plug (on reservoir) Parts Tray Caster Figure 1 - Model SJ-3PTL Components...
- Page 4 WARNING WARNING • Study, understand, and follow all printed materials provided with/on this product before use. • do not exceed rated capacity. • Use only on hard, level surface. To avoid crushing and related injuries: • This is a lifting device only! •...
- Page 5 MaInTenanCe Important: Use only good grade hydraulic jack oil. Avoid mixing different types of fluid and never use brake fluid, turbine oil, transmission fluid, motor oil or glycerin. Improper fluid can cause failure of the jack and the potential for sudden and immediate loss of load.
- Page 6 Call or write for current pricing: SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A. CustomerService@johndow.com Tel: (888) 332-6419 Fax: (816) 891-6599 Replacement Parts Illustration for model SJ-3PTL Figure 2 - Replacement Parts Illustration for Model SJ-3PTL...
- Page 7 Replacement Parts List for model SJ-3PTL Item Part no. description F36100-0001 Oil Filler Plug G59510-0004 Pump Piston G48900-0004 Release Valve G59305-0002 Snap Ring f16 G80800-0002 Saddle G62000-1003 Return Spring G58900-0002 Handle Sleeve G48900-0015 G59305-0003 Nut M10 G48900-0016 Release Valve Gear...
- Page 8 One YeaR LIMITed WaRRanTY For a period of one (1) year from date of purchase, SFa Companies will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage. This limited warranty is a consumer's exclusive remedy.
