Summary of Contents for StellaX zoomx X-007
- Page 1 CREATED BY STELLAX COMPANY -007 Instruction Manual for Binoculars BINOCULARS 10x42 waterproof...
-
Page 2: Table Of Contents
CONTENTS Instructions for use • Information for Your Safety • Risk of Swallowing • Eyecup Adjustment • IPD (distance) Adjustment • Focus and Diopter Adjustment • Objective Lens Covers Care and Maintenance Waterproof/Fog-proof Information Warranty Setting up the Smartphone Adapter How to Attach the Neck Strap... -
Page 3: Instructions For Use
Instruction for use Congratulations on purchasing your new ZoomX «X-007» binoculars. Enjoy the sharp, bright, high resolution view offered by these outstanding optics. Follow the instructions for use and your product will be a reliable companion for many years to come. Information for your safety Do not, under any circumstances, look through the binoculars at the sun or laser light sources! - Page 4 Ocular Lens (Eyepiece) Eyecup (Twist-Up) Center Focus Knob Tripod Adapter Socket (under cap) Objective Lens...
-
Page 5: Eyecup Adjustment
Eyecup Adjustment Eyecup in «Up» Position Eyecup in «Down» Position (for use without eyeglasses) (for use with eyeglasses) Pic. 1 Pic. 2 Your ZoomX «X-007» binoculars are fitted with twist-up eyecups that provide a comfortable view of the full image and help to exclude extraneous light. For use without eyeglasses or sunglasses, twist the eyecups upwards, rotating them counter-clockwise until they lock into the fully «Up»... -
Page 6: Ipd (Distance) Adjustment
IPD (Interpupillary Distance) Adjustment Narrow IPD Wide IPD Pic. 3 Interpupillary Distance Adjustment Point the binoculars at a white wall or blank area of the sky. Hold them and gaze through them as you normally would. Don’t worry about focus yet. Grasp each side of the binoculars firmly. -
Page 7: Focus And Diopter Adjustment
Focus and Diopter Adjustment Center Focus wheel Diopter Adjustment Ring Close your right eye and sight an object with your left eye. Focus the binoculars by rotating the center focus wheel until the image is sharp and clear. Open your right eye and close your left eye. Rotate the right eyepiece until the object sighted is sharp and clear (Note the setting of the diopter scale for later use.) -
Page 8: Objective Lens Covers
Objective Lens Covers When using your «X-007» binoculars, flip open the objective lens covers. To prevent accidental loss, the covers are tethered to (removable) rubber security rings. When you have finished using the binoculars, put the covers back in place to protect the binoculars' lenses. -
Page 9: Care And Maintenance
Care and Maintenance First, blow or brush away any dust or debris on the lens (using «canned air» or a soft lens brush). To remove dirt or finger prints, clean with the supplied soft storage bag (made of washable micro-fiber cloth), rubbing in a circular motion. -
Page 10: Waterproof/Fog-Proof Information
Waterproof/Fog-proof Information Your ZoomX «X-007» bbinoculars have been designed and built utilizing the latest waterproof and fog-proof technology. Fog-proof protection achieved from dry nitrogen purging that removes all internal moisture. Warranty Your ZoomX product is covered by our warranty and guaranteed to be free from manufacturing defects in materials and workmanship for the life of the product. - Page 11 Smartphone Adapter How to use the Smartphone Adapter with iPhone Align the camera Tighten the locking bolt Set your smartphone Align the hole of the adapter to Smartphone Adapter. with the camera of your smartphone. Tighten the locking bolt.
- Page 12 Attach the smartphone adapter Remove the front cover caps to the binocular eye socket. from the binoculars' lenses. Turn on the camera Zoom in a little on your smartphone of your smartphone. to get a rectangular image.
-
Page 13: Setting Up The Smartphone Adapter
Setting up the Adapter for Dual-Camera Smartphones Some smartphones have two or more cameras on the back of the device. For example: Apple iPhone 8 Plus, Apple iPhone XS Max To connect your smartphone to the smartphone adapter, you need to use the main camera. -
Page 14: How To Attach The Neck Strap
How to Attach the Neck Strap Push a few inches of the strap through the strap attachment on the binoculars. Hold the buckle and thread the end of the strap through buckle. Adjust overall length, then pull tight until strap secured within the buckle.
Need help?
Do you have a question about the zoomx X-007 and is the answer not in the manual?
Questions and answers
Left side is blurry. How to fix.
To fix a blurry left side on the StellaX ZoomX X-007 binoculars:
1. Close your right eye and keep your left eye open.
2. Rotate the center focus wheel until the image is sharp and clear for your left eye.
3. Then open your right eye and close your left eye.
4. Rotate the right eyepiece (diopter adjustment) until the image is sharp for your right eye.
5. From now on, use only the center focus wheel to focus on other objects.
If the left side remains blurry after step 2, check for dust or smudges on the left lens and clean it using the soft storage bag in a circular motion.
