CPC/MITX7ixY-Azzz
Document Ordercode: DOC/MITX7ixY
Revision
Date
0.1
02.02.18
1.0
25.05.18
1.1
30.05.18
Author
Modification
D. Lagler
Preliminary
D. Lagler
Initial version
D. Lagler
Technical Data added

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPC/MITX7i A Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for syslogic CPC/MITX7i A Series

  • Page 1 u s e r d o c u m e n t a t i o n CPC/MITX7ixY-Azzz Document Ordercode: DOC/MITX7ixY Revision Date Author Modification 02.02.18 D. Lagler Preliminary 25.05.18 D. Lagler Initial version 30.05.18 D. Lagler Technical Data added...
  • Page 2: Table Of Contents

    SATA Power (internal) 3.2.5 M.2 Slot (internal) 3.2.6 Micro SD Card (internal) 3.2.7 Serial Ports 3.2.8 USB Interface Front 3.2.9 USB Interface internal 3.2.10 Ethernet LAN Interface 3.2.11 Power supply 3.2.12 Power button © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 3 Cabling of communication links 7 Service Replaceable Parts 8 Firmware Software Structure 8.1.1 BIOS (Basic Input/Output System) 8.1.2 OS (Operating System) 8.1.3 Application Programs Firmware Functions Application Programming Interface (API) 9 Manufacturer Information Contact Warranty © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 4 Tab. 9 USB3/4 Interface Connector (Dual Type A) ..................17 Tab. 10 USB7/8 on interface connector X16 ....................18 Tab. 11 USB9/10 on interface connector X15 ....................18 Tab. 12 Power supply connector........................19 © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 5 Additional grounding of the cable shields at the entry point of a cabinet......... 25 Fig. 3 Non-isolated communication link with common chassis potential ..........26 Fig. 4 Isolated communication link ......................26 Fig. 5 Drawing COMPACTc7 system ......................22 © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 6: Introduction

    Note that the documentation for the products is constantly revised and improved. The right to change this documentation at any time without notice is therefore reserved. Syslogic is grateful for any help referring to errors or for suggestions for improvements. The following registered trademarks are used:...
  • Page 7: Items Delivered

    The output voltage of the external power supply shall be SELV and shall be limited power source according to clause 2.5 EN 60950-1. Please read the safety instructions of the power supply before installing/connecting the device. © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 8: Emc

    Observe the EMI-precautions against static discharge. Carefully read the assembly and installation documentation (see chapter 6) before unpacking the products. Make sure that you have all the necessary items ready (including all the small parts). Follow the assembly guidelines in chapter 6 strictly. © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 9: Operation

    The main functionality of the COMPACTc7 system is defined by the application programs running on the processor board. The application programs are not part of the delivery by Syslogic but are defined, developed and tested by the customer or a system-integrator for each specific application. Refer to the respective documentation for more information.
  • Page 10: Product Description

    1x M.2 interface (already used for hard drive memory) 1x PCIe x4 slot (gen. 3) 1x mPCIe slot 2x SATA interfaces (6Gbps) 4x USB 2.0 1x microSIM card slot 1x microSD card slot © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 11 CPC/MITX7ixY-Azzz: user documentation DOC/MITX7ixY; V1.1 Fig. 1 Block diagram miniITX-Board (all functions) Important Note Check the product variant carefully for the supported functions. © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 12: Product Variants

    Micro SD PCIe (X8) PCIe (X8) PCIe (X8) mPCIe PCI e x4 (X7) PCI e x4 (X7) PCI e x4 (X7) PCIe RTC Backup Li battery Li battery Li battery Tab. 1 Product Variants © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 13: Hardware Description

    DOC/MITX7ixY; V1.1 Hardware Description Overview The COMPACTc7 hardware may be configured by software (CMOS setup). Custom BIOS configuration can be programmed into the BIOS flash on request (ask Syslogic technical support for custom BIOS configuration). Peripheral Devices 3.2.1 DisplayPort Interface The DisplayPort signals (DP++) are available on the DisplayPort connectors DP1 and DP2 for direct connection of DisplayPort compatible monitors.
  • Page 14: Sata Interface (Internal)

    Tab. 4 X12: 15-pin standard SATA power connector Important Note Do not power more than two devices at the same time. The +3.3V, +5V and +12V voltage rails have maximum current of 2A each. © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 15: Slot (Internal)

    PET1- UIM_PWR PET1+ DEVSLP GNSS_SCL PER0-/SATA_B+ GNSS_SDA PER0+/SATA_B- GNSS_IRQ PET0-/SATA_A- PET0+/SATA_A+ RESET# CLKREQ# REFCLK- PEWAKE# REFCLK+ RESET# SUSCLK CONFIG_1 + 3.3V + 3.3V + 3.3V CONFIG_2 Tab. 5 X10: M.2 type 3042/2242 interface © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 16: Micro Sd Card (Internal)

    250 kbps with worst-case loads of 3kΩ, in parallel with 1nF. Connector type: DSUB-9 male Pin Number Signal Pin Number Signal Tab. 7 Serial Ports COM1/2 on DSUB-9 male X1, X2 © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 17: Usb Interface Front

    Port 3 (right bottom) Port 4 (right top) Pin Number Signal Pin Number Signal VBUS VBUS StdA_SSRX- StdA_SSRX- StdA_SSRX+ StdA_SSRX+ GND_DRAIN GND_DRAIN StdA_SSTX- StdA_SSTX- StdA_SSTX+ StdA_SSTX+ Tab. 9 USB3/4 Interface Connector (Dual Type A) © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 18: Usb Interface Internal

    The COMPACTc7 features two Gigabit Ethernet ports. The Ethernet interface drives two LED’s (yellow and green) integrated into the RJ45 connector for status information. LAN1 (Intel i219 Ethernet controller) and LAN2 (Intel i211 Ethernet controller) both support 10/100/1000Mb/s, Auto Negotiation and Auto MDIX functions. Connector type: RJ45 © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 19: Power Supply

    To turn on the system the power has to be applied and then the power button can be pressed once. A blue illuminated power button indicates a running system. The function of the power button can be defined in the OS as a “normal” power button in any other PC system. © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 20: Technical Data

    Maximum cable length Interface Maximum Length Comment RS232 <30m USB (2.0) <3m USB (3.0) <3m Ethernet <100m Tab. 15 Maximum cable length 100% CPU Load, 1 x GBit Ethernet, 1x DP++, 2x USB device, Ptot<29W © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 21: Emi / Emc Specification

    1 x ETH, 1xDP++, 2xUSB, 0% CPU load 1 x ETH, 1xDP++, 2xUSB, 100% CPU load 1 x ETH, 1xDP++, 2xUSB, 0% CPU load 1 x ETH, 1xDP++, 2xUSB, 100% CPU load Peak consumption during boot up phase © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 22: Mechanical Data

    CPC/MITX7ixY-Azzz: user documentation DOC/MITX7ixY; V1.1 Mechanical Data Fig. 2 Drawing COMPACTc7 system © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 23: Programming Information

    The Ethernet interfaces use the Intel i219 and the Intel i211 Ethernet controller. For detailed programming information and drivers check www.intel.com 5.1.4 USB Interface The USB interfaces use the standard OHCI/EHCI/XHCI register set. Legacy support and low-level programming is handled by the BIOS and standard OS drivers. © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 24: Installation And Cabling

    EMI/RFI "CE"-certification. Cabling the interfaces Use appropriate cabling for all interfaces. Shielded cabling is required to meet the EMI/EMC limits. © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 25: Grounding

    It is better to clamp the shields onto a grounded copper rail. IIndustrial PC System Cabinet Clamping screw nonisolated Chassis shield Cables Fig. 3 Additional grounding of the cable shields at the entry point of a cabinet. © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 26: Cabling Of Communication Links

    100E 100E Abschirmung/Shield Unisolated Node Unisolated Node Potential-Ausgleichsleitung min. 10 mm Kupfer Copper-wire for Potential Adjustment, min. 10 mm Zentraler Erdpunkt am Chassis Zentraler Erdpunkt am Chassis Central Grounding Point Central Grounding Point © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 27: Service

    SSD may be removed. When inserting a new flash card be sure that it is fully compliant with the M.2 standard. Syslogic highly recommends M.2 flash cards specified for industrial use by the card manufacturer. Check temperature range and durability to comply with your requirements.
  • Page 28: Firmware

    Application Programming Interface (API) The COMPACTc7 system does not contain any special API beside the installed BIOS. Refer to the BIOS and Operating System documentation for API specifications. © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
  • Page 29: Manufacturer Information

    The warranty does not include damage due to errors in firmware or software delivered with the products. © Syslogic Datentechnik AG, Switzerland, ht tp://www.syslogic.com...
